- Page 1 Installation Manual Guide to Intelligent Alarm Immobiliser 9001 ISO 9001 QS 9000 Manufacturer: COMMERCIAL ELECTRONICS 264 HAYDONS ROAD, WIMBLEDON, LONDON SW19 8TT. UK TEL: +44 020 8404 7105 FAX: +44 020 84047104 http://www.hawkcaralarm.com e-mail: info@hawkcaralarm.com...
- Page 2 Installing HAWK® Motorcycle Alarm System (General Guidance) We think youʼve made an excellent choice in allowing HAWK® to protect your bike. Now the question is: “How in the world am I going to install this – there are so many wires.” What seems like a hard task is actually not too bad;...
- Page 3 Using a Multi-meter and Testing Wires A digital multi-meter is your safeguard when doing a motorcycle alarm. Testing wires before you make a connection is a sure fire way to make sure you are making a proper connection. Your multi- meter should have a DC setting with 2 leads, red and black: positive (+) and negative (-).
- Page 4 The meter should only read power and ground on accessory items when they are activated. Install Your HAWK compact Motorcycle Alarm System LOCATION OF MAIN SYSTEM COMPONENTS Before commencing with the installation, plan where to secure the main components.
-
Page 5: Mounting The Siren
INSTALLATION OF MAIN SYSTEM COMPONENTS Great care has been take in the design and manufacture of HAWK products, Correct installation and good working practices will enhance the operation of the alarm system and give long term benefit to the user. - Page 6 ALARM WIRING INSTALLATION IMPORTANT Make sure that you have planned the wiring connections before adapting / cutting the alarm loom or the motorcycle loom. Connect RED wire to constant power input (+) 12v supply from the battery. Connect BLACK/RED wire to any wire in the ignition system which becomes live when the ignition is switched ON, and remains live when the starter is pressed e.g.
- Page 7 POWER + AND WIRES STEP 1 Connecting the Red & Green wires GREEN x2 GREEN x1 Important: Remove fuse from alarm wire harness (Red wire) 1. Connect RED wire to the positive (+) of battery terminal 2. Connect GREEN (1) wire to the negative (-) of battery terminal. 3.
- Page 8 INDICATOR WIRES INDICATOR WIRES STEP 2 STEP 2 Connecting the Orange & Light Blue wires Connecting the Orange & Light Blue wires Bike Bike Left Indicator Left Indicator Right Indicator Right Indicator Honda Honda Orange wire Orange wire Light Blue wire Light Blue wire Kawasaki Kawasaki...
- Page 9 IGNITION SWITCH WIRES STEP 3 Connecting the Black wire Bike Ignition Switch Honda Black/Red wire Kawasaki Brown wire Suzuki Orange wire Yamaha Brown wire BLACK/RED This wire must be connected to wire that gives positive (+) 12 volt when the ignition key is turned on and this wire should not show any voltage when ignition turned off.
- Page 10 BASIC ALARM INSTALLATION BASIC ALARM INSTALLATION Model: X50 Model: X50 white/ white/ green green black black black/ black/ yellow yellow grey grey white white /red /red light light black/ black/ orange orange black black blue blue Rear view of Rear view of wiring loom wiring loom BLACK...
- Page 11 FULL ALARM INSTALLATION FULL ALARM INSTALLATION Model: X50 Model: X50 white/ white/ green green black black black/ black/ yellow yellow grey grey white white /red /red light light black/ black/ orange orange black black blue blue Rear view of Rear view of wiring loom wiring loom HERE...
- Page 12 ENGINE IMMOBILISATION CONNECTING DIAGRAM ENGINE IMMOBILISATION CONNECTING DIAGRAM Connecting the White/Black & Black/White wires Connecting the White/Black & Black/White wires Most large motorcycles with Most large motorcycles with four-stroke engines use this system. four-stroke engines use this system. Fig. 1a Fig.
- Page 13 ENGINE IMMOBILISATION CONNECTING DIAGRAM ENGINE IMMOBILISATION CONNECTING DIAGRAM Connecting the White/Black & Black/White wires Connecting the White/Black & Black/White wires Most large motorcycles with Most large motorcycles with four-stroke engines use this system. four-stroke engines use this system. Fig. 1b Fig.
- Page 14 ENGINE IMMOBILISATION CONNECTING DIAGRAM ENGINE IMMOBILISATION CONNECTING DIAGRAM Connecting the White/Black & Black/White wires Connecting the White/Black & Black/White wires Most large motorcycles with Most large motorcycles with four-stroke engines use this system. four-stroke engines use this system. Fig. 1c Fig.
- Page 15 ENGINE IMMOBILISATION CONNECTING DIAGRAM ENGINE IMMOBILISATION CONNECTING DIAGRAM Connecting the White/Black & Black/White wires Connecting the White/Black & Black/White wires Most small motorcycles with two-stroke engines Most small motorcycles with two-stroke engines use this system, i.e. Scooters/Mopeds. use this system, i.e. Scooters/Mopeds. Fig.
- Page 16 REMOTE START WIRE Connecting the Yellow/Red wire STARTER SWITCH YELLOW/RED FUSE BOX STARTER MOTOR Start Circuit Relay This wire to be connected to output of start switch or start relay. Note: Bike with Positive Starter connect RED wire to RED/WHITE wire (factory default) Bike with Negative Starter connect GREEN wire to RED/WHITE wire Most Yamaha Bikes are negative, all other bikes positive (check polarity).
-
Page 17: Installation
TILT SENSOR (OPTIONALEXTRA) Connecting the Blue/White wire BLUE/WHITE BLUE Blue or white TILT (TRIGGER INPUT) SENSOR BLACK INSTALLATION: The sensor control module must be mounted at an angle no greater than 45 degrees, with respect to the horizontal plane of the vehicle, and it must be mounted with the case top facing upward. - Page 18 MICROWAVE SENSOR (OPTIONALEXTRA) Connecting the Blue/White wire BLUE/WHITE BLUE Blue or white MICROWAVE (TRIGGER INPUT) SENSOR BLACK INSTALLATION: Fit the HA-MW 01 with its backside always pointed on the metal part of the bike. Avoid the presence of any metal objects between the module itself and the area to protect. The high frequency generated by the module, emitted on the front part can easily go through any surface (plastic covers, dashboard, windows, chairs, etc), metal parties excluded.
- Page 19 Battery Backup Siren (optional extra) BATTERYBACKUPSIREN (OPTIONALEXTRA) Connecting the White wire WHITE WHITE FUSE Mounting the Siren Ensure that the siren is not installed in a position prone to excessive heat, water or mud splashes! The siren should be facing slightly down so that water will not pool. Fasten the Siren in place using double sided tape provided with the alarm.
- Page 20 CONNECTING THE ALARM WITH SPECIFIC HARNESS (OPTIONAL EXTRAS)
- Page 21 CONNECTING THE ALARM WITH SPECIFIC HARNESS (OPTIONAL EXTRAS)
- Page 22 NOTES...
-
Page 23: Consumer Warranty
The warranty does not cover damage to the unit caused by installation or removal of the unit. HAWK, in its sole discretion, will determine what constitutes excessive damage and may refuse the return of any unit with excessive damage. TO THE... - Page 24 264 Haydon’s Road Wimbledon London SW19 8TT Telephone: 0208 404 7105 Fax: 0208 404 7104 Web: www.hawkcaralarm.com www.hawkcaralarm.com info@hawkcaralarm.com Manufactured By Commercial Electronics . Great Britain . © Commercial Electronics 2011...
