Installation and
Operation Manual
TANDOOR - CE
Speciality Ovens
Gas-Fired, Round, Square, Octagonal,
Barrel European Models
TANDOOR 31" WS-GFT-31-CE
TANDOOR 35" WS-GFT-35-CE
BARREL TANDOOR WS-GFT-35-CUS-CE
WOOD STONE CORPORATION
1801 W. Bakerview Rd.
Bellingham, WA 98226 USA
www.woodstone-corp.com
Toll Free 800.988.8103
Tel 360.650.1111
Fax 360.650.1166
DOC NO M0054.05
REVISED April 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WS-GFT-31-CE and is the answer not in the manual?

Questions and answers

Summary of Contents for TANDOOR WS-GFT-31-CE

  • Page 1 Installation and Operation Manual TANDOOR - CE Speciality Ovens Gas-Fired, Round, Square, Octagonal, Barrel European Models TANDOOR 31" WS-GFT-31-CE TANDOOR 35" WS-GFT-35-CE BARREL TANDOOR WS-GFT-35-CUS-CE WOOD STONE CORPORATION Toll Free 800.988.8103 1801 W. Bakerview Rd. Tel 360.650.1111 Bellingham, WA 98226 USA Fax 360.650.1166...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS TANDOOR � � � � � � � � � � � � � � � � � � � � � � � � � �3 CAUTIONS AND WARNINGS � � � � � � � � � � � � �4 GFT-31-CE SPECIFICATIONS �...
  • Page 3: Tandoor

    TANDOOR CE Tandoor CE Installation and Operation Manual INSTALLATION AND OPERATION MANUAL FOR THE WOOD STONE TANDOOR GAS-FIRED TANDOOR OVEN WS-GFT-31 (ROUND, SQUARE AND OCTAGONAL), WS-GFT-35 (ROUND, SQUARE, OCTAGONAL) WS-GFT-35-CUS (BARREL) CE MODELS ADDITIONAL COPIES AVAILABLE UPON REQUEST Square model (shown with...
  • Page 4: Cautions And Warnings

    Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DO NOT THROW THIS MANUAL AWAY Wood Stone's gas-fired Tandoor was tested and approved by Intertek Testing Services, to the requirements of BS-EN 203-1:2014. 0359-14 WOOD STONE CORPORATION M0054.05 APRIL 2017...
  • Page 5: Gft-31-Ce Specifications

    37 3/4" Bellingham, WA 360/650-1111 www.woodstone-corp.com 37 3/4" 960mm 960mm 21 1/2" Square and Octagonal 21 1/2" 550mm 31" Tandoor. All Shape 550mm DIMENSIONS ARE IN INCHES models� TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2° General Arrangement UNLESS NOTED OTHERWISE 31" 31"...
  • Page 6: Gft-35-Ce Specifications

    Bellingham, WA 360/650-1111 www.woodstone-corp.com 40 3/4" 40 3/4" models� 1040mm 1040mm 24 1/2" 24 1/2" 35" Tandoor. All Shape 620mm 620mm DIMENSIONS ARE IN INCHES 33 3/4" 33 3/4" TOLERANCES: LINEAR ±1/2 [±10mm], ANGULAR ±2° 860mm 860mm General Arrangement UNLESS NOTED OTHERWISE 14 1/4"...
  • Page 7: Gft-35-Cus-Ce (Barrel) Specs

    Gas: 19mm (3/4") BPT gas inlet (female threaded) Bellingham, WA 360/650-1111 www.woodstone-corp.com ellingham, WA 360/650-1111 www.woodstone-corp.com Bellingham, WA 360/650-1111 www.woodstone-corp.com 3521 - Barrel Tandoor 3521 - Barrel Tandoor 3521 - Barrel Tandoor See Gas Ratings in the GAS SPECIFICATIONS section of this manual�...
  • Page 8: Clearances & Venting

    VENTING The Wood Stone gas-fired Tandoor must be installed under an appropriate grease rated exhaust hood� Refer to local and/or national codes for hood specification requirements� The hood must be designed for the removal of the combustion products of gas, as well as the cooking vapors related to the intended use of the oven�...
  • Page 9: Gas Specifications

    The Wood Stone gas-fired Tandoor is equipped with a 19mm (3/4") BPT female gas connection, located on the underside of the rear of the unit� Anchor points for the restraining means are provided on the underside of the Tandoor; these are holes punched in the rear portion of the drip/debris pan rails�...
  • Page 10: Lower Flashing Install (Barrel)

    LOWER FLASHING INSTALL (BARREL) Tandoor CE Installation and Operation Manual DO NOT LOWER STRIP FLASHING UNTIL TANDOOR IS LOCATED IN ITS FINAL INSTALLED POSITION Leveling the Tandoor Position Tandoor in its final installed position� With the Flashing still in the UP position, level the Tandoor using the four adjustable feet�...
  • Page 11: Operation

    5. Use the Temperature Control Knob on top of the Tandoor to control the height of the cooking flame. For Barrel models, temperature control is located on the control box at the front end of the oven�...
  • Page 12: Daily Operation

    Do not operate the unit with the lid on, except during heat-up or overnight. Partially covering the opening with the lid while cooking will damage the top of the Tandoor. Heat damage caused by operating the Tandoor with the lid partially on will not be covered by the warranty.
  • Page 13 CLEANING Debris that falls in the Tandoor will accumulate in the bottom of the chamber� Push the debris towards the center and under the circular flame deflector, using the supplied Tandoor Naan Hook, where it will fall into the drip/debris pan under the unit� This pan should be checked daily and emptied as necessary�...
  • Page 14: Limited Warranty

    LIMITED WARRANTY Tandoor CE Installation and Operation Manual WOOD STONE WARRANTS ITS EQUIPMENT TO THE ORIGINAL PURCHASER AGAINST DEFECTS IN MATERIAL OR MANUFACTURE FOR A PERIOD OF ONE YEAR FROM THE ORIGINAL DATE OF PURCHASE, SUBJECT TO THE FOLLOWING EXCLUSIONS AND LIMITATIONS.
  • Page 15 M0054.05 APRIL 2017...
  • Page 16 WOOD STONE CORPORATION 1801 W. Bakerview Rd. Tel +1.360.650.1111 Bellingham, WA 98226 USA Fax +1.360.650.1166 www.woodstone-corp.com An ongoing program of product improvement may require us to change specifications without notice. M0054.05 APRIL 2017...
