  • Page 1 DOUBLE MITER SAW IM-300 PL/ IM-300PL AL !!! For your safety !!! Read the manual instructions. Http://www.inmes.com.br SAP: 370/371 05040235...
  • Page 3 Visit our website and check out our range of products. http://www.inmes.com.br We kindly ask you to right in block below the serial number of your machine. Obs.: INMES Industrial LTDA reserves the right to change this manual without previously notice. INMES Industrial Ltda – Double Miter Saw IM-300PL...
  • Page 4 INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 5: Table Of Contents

    6.2 – Safety Shields Adjustment..............................17 6.3 - Clamping System ................................... 17 6.4 - Blades Descent Speed Adjustments ..........................18 6.5 – Lubricant Spray (only for IM-300PL AL) ........................19 6.6 – Cutting the profile ................................20 6.6.1 – Recommendations ................................22 7 –...

  • Page 6: Inmes Industrial Ltda – Double Miter Saw Im-300Pl

    23 – SPARE PARTS LIST................................. 63 Part Drawing ....................................... 64 24 – ASSEMBLING THE DUST COLLECTOR ..........................65 25 – SPARE PARTS LIST................................. 66 Part Drawing ....................................... 67 Warranty Term ....................................68 INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 7: Safety Instructions

    The instructions described in this manual it is for both, IM-300P and IM-300PL. The model IM-300P was exclusively developed for cutting plastic or wood, while the model IM-300P AL was developed for cutting only aluminum.. INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 8: Blade Requirements

     In order to move the machine make sure to use a forklift as shown in fig. 02.  Inmes Industrial does recommend to install a circuit breaker* of 15A (IEC Standard) for machines 220/380V threephases, and a circuit breaker* of 25A (IEC Standard) for machines singlephas- es/Dualphases.

  • Page 9: To Reduce Risk Of Injury

     Properly adjust the protection entrance when you cut different mouldings (see page 16 item 6.2);  After replacing the blade, make sure it be rotating on the right direction as shown in Fig. 05 and 06. INMES Industrial Ltda – Double Miter Saw IM-300PL...
  • Page 10 D A N G E R  Any operator must receive full training by an specialized operator before starting working with this equipment; INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 11: Protections

    This way it can be easy loaded or unloaded with a standard forklift. Make sure that all items are included with your machine: 01 Double Miter Saw IM-300PL or IM-300PL AL; 01 Allen Key 6 mm; 01 Molding Stop ;...

  • Page 12: Optional Accessories

    02. 2. 2 - Optional accessories  Dust Colector;  Right arm Extension;  Left arm extension;  Additional right arm extension;  Moulding Stop (Flip-Flop). INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 13: Get To Know Your Double Miter Saw

    10 – Window; 11 – Hand Protection; 12 – Hand Button Starter; 13 – Maintenance hood; 14 – Clamping System Regulator; 15 – Scrap Output; 16 – Front Door; 17 – Lower Hood. INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 14: Technical Specifications

    4 – TECHNICAL SPECIFICATIONS: INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 15: Installation

    To invert the direction rotation in single phase machines it’s necessary to change the wires position T5 and  T8 (change one for another) inside the connection box. This procedure has to be done by a qualified service technician. (Fig. 12). INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 16: Lubricant Oil Level

    Fig. 12 5. 3 – Lubricant oil level The products developed by Inmes offer long durability and high performance, in order to guarantee total satisfaction of our customers. Our quality control department test every machine before it be packaged. However, they are delivered without pneumatic oil which it is recommended to be refuel.

  • Page 17: Air Supply

    The 5mm Allen wrench it is not supplied with the equipment. Now, sliding the part 01 to the right to remove it. Now slide the moulding stop next to the part 03 (fig. 15). This way the measure “B” will be 94mm. Fig. 14 Fig. 15 INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 18: Safety Shields Adjustment

     Position the clamping system over the frame, leaving a 10 mm gap (Fig. 18 e 19).  Tighten the handle 01; Make sure the workpiece be pressed against the fence as shown in fig Fig. 20.  Fig. 17 Fig. 18 Fig. 19 INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 19: Blades Descent Speed Adjustments

    02 the left sawblade descend. Turning the valve counter clockwise direction will increase descend of the sawblade. 2. Turning the valve 01 clockwise direction will decrease descend of the sawblade. Fig. 24 INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 20: Lubricant Spray (Only For Im-300Pl Al)

    For a high quality cut and long durability of the sawblades while cutting aluminum, the Double Miter Saw IM-300PL AL is equipped with a lubricant spray system. Before starting the operation, please, fill the recipient 01 (fig. 25) with the oil lubricator. Proceed as follow: 1) Unpplug the hoses 02 (Fig.

  • Page 21: Cutting The Profile

    (130mm) or the external line of the profile must match with the external measure of the frame (255mm). Move the moulding stop 02 fig. 30 in the profile, without moving the profile; Then tighten the moulding stop. INMES Industrial Ltda – Double Miter Saw IM-300PL...
  • Page 22 (Fig. 28 and 29). By doing it, the both sawblades will descend at the same time, increasing your productivity. . Remember: Operating on that way, your waste will be bigger. Fig. 32 INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 23: Recommendations

     Before starting any kind of maintenance and cleaning  In order to avoid damage in your equipment, of the machine, disconnect the power source and read we do recommend using original parts from the instructions manual Inmes . INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 24: Changing The Saw Blade

    Fig. 36 Fig. 37 W A R N IN G In order to guarantee a long durability of you sawblade, better quality cuts and more safety; sharpen the sawblade regularly. INMES Industrial Ltda – Double Miter Saw IM-300PL...
  • Page 25 1) With your right hand push up the item 01 (Fig 40). 2) And with your left hand turn down the hood 02 (Fig. 40). Fig. 40 INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 26: Adjustment Of The Saw Belts

    7) Take out the cover 01 (Fig. 45); Fig. 43 Fig. 44 Fig. 45 8) Unplug the cable as shown in Fig. 46; 9) Take out the upper hood as shown in fig. Fig. 46 Fig. 47 INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 27: Lubrification

    (01 fig. 53). You should lubri- cate the bearings in the blade arms with a grease gun as shown on item 01 fig. 53 Fig. 52 Fig. 53 INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 28: Troubleshooting

    Debris between the profile and moulding fence Clean it up the machine * Before turning ON the circuit breake, make sure there is no problem on the eletric system of the motor. INMES Industrial Ltda – Double Miter Saw IM-300PL...

  • Page 29: 9- Spare Parts Of Im-300Pl/ Im-300Pl Al

    P03020785 Hex Nut MA M16mm Zinc 04080149 Central Scrap Output Protection IM-300P/PL (Z) P03020788 External hex head screw M8x35mm 04080154 Scrap Output Protection IM-300P/PL (Z) P03020790 Hex Nut MA M4mm Zinc 04080160 INMES Industrial Ltda – Double Miter Saw IM-300PL...
  • Page 30 Left Aluminum Calibrated Scale MM IM-300PL 04190142 Neutral Label 04050018 Right Aluminum Calibrated Scale POL IM-300PL 04190166 Attention Label 40x100mm Port/Esp/Ing 04050020 Left Aluminum Calibrated Scale POL IM-300PL 04190167 Window Label 04050034 Label 05040015 INMES Industrial Ltda – Double Miter Saw IM-300PL...
  • Page 43 IM-300P/PL OPTIONAL ACCESSORIES ARM EXTENSION ROLLING ARM EXTENSION FLIP-FLOP MOLDING STOP DUST COLLECTOR...

  • Page 45: Assembling The Extension Tables (Optional)

    INMES Industrial Ltda developed extensions tables in order to guarantee the cutting quality for the Double Miter Saw models IM-300P and IM-300PL. The extensions tables provide necessary support when cutting long profiles avoiding that they move; giving precision, finishing and high productivity.
  • Page 46 After that, tighten all screws making sure that the alignment on the horizontal position it is right as well (fig. 12). Also, make sure the calibrate scale of the fence mach with the calibrate scale of extension table as shown in fig. 13. INMES Industrial Ltda – Double Miter Saw IM-300P/ PL...
  • Page 47 5) By using the bolts 01 (fig. 18), leveling the additional extension table. 6) Then, with a wrench of 13,00mm (it is not supplied with the machine) tighten the nut as shown in Fig. 19. Fig. 17 Fig. 18 Fig. 19 INMES Industrial Ltda – Double Miter Saw IM-300P/ PL...
  • Page 48 Scale MM IM-300PL Socket Head Hex Screw M6x16mm 0408016 Right Extension Table Calibrated Scale POL IM- 0419173 300PL Socket Head Hex Screw M6x20mm 0408018 Right Additional Extension Table Calibrated 0419174 Scale POL IM-300PL INMES Industrial Ltda – Double Miter Saw IM-300P/ PL...

  • Page 50: Aligning The Extension Table

    10 (fig. 02) fixing the extension table support 08 on the table 09 (Fig. 02). Make sure to align the rolls 04 (fig. 03) with the surface of the fence (item 05 on fig. 02). Fig. 03 INMES Industrial ltda – Double Miter Saw IM-300P/ PL...

  • Page 51: Assembling The Additional Right Extension Table

    05 (fig. 05). Use the leveling 06 (fig 05) to align the additional extension table. Finally, make sure the fences of the both exten- sion tables are parallel as well as the rolls. Fig. 05 INMES Industrial ltda – Double Miter Saw IM-300P/ PL...

  • Page 52: Spare Parts List

    Left Roller 0302742 Hex Nut MA 8mm Zinc 0408179 Rolling Arm Extension Adapter IM-300P/ 0302869 Washer 1/4POL 0408200 Leveling M8 47,00x65,00mm (B) 0305140 Washer 5/16POL 0408201 Socket Head Hex Screw M6x20mm 0408018 INMES Industrial ltda – Double Miter Saw IM-300P/ PL...

  • Page 53: Part Drawing

    0302578 Hex Nut MA 6mm Zinc 0408177 Left Roller 0302742 Hex Nut MA 8mm Zinc 0408179 Leveling M8 47,00x65,00mm (B) 0305140 Washer 1/4POL 0408200 Socket Head Hex Screw M8x20 0408026 Washer 5/16POL 0408201 INMES Industrial ltda – Double Miter Saw IM-300P/ PL...

  • Page 56: Right Rolling Arm Extension Sapre Parts List

    As a solution for cutting different sizes of profiles on the same operation, INMES developed the new Flip- Flop molding stop. 20 – GET KNOWING THE FLIP-FLOP MOLDING STOP Before installing the flip-flop molding stop, make sure to identify the components: 01 –...

  • Page 57: Left Addictional Rolling Arm Extension Sapre Parts List

    21.2 – INSTALLING THE FLIP-FLOP SWITCH 1) First of all, placed the switch 01 as show in fig. 08. 2) Then tighten the key with the part 01 (Fig. 09). Fig. 08 Fig. 09 INMES Industrial ltda – Double Miter Saw IM-300P/ PL...

  • Page 58: Work Wiht The Molding Stop Flip-Flop

    ! Make a miter cut with the left blade saw. Then, after cutting the profile, the Flip-Flop Molding Stop will assume its position as shown in Fig. 15. Fig. 13 Fig. 14 Fig. 15 INMES Industrial ltda – Double Miter Saw IM-300P/ PL...
  • Page 59 ! Tighten the handle 05 (Fig. 16); ! Make the cut with the right saw blade. ! Take out the other part of the frame; ! Repeat the same process as many times as necessary. Fig. 18 INMES Industrial ltda – Double Miter Saw IM-300P/ PL...

  • Page 60: Flip-Flop Molding Stop Switch

    0407366 Washer 6,30x15,00x2,00mm (Z) 0305163 Electric-Pneumatic Valve 5/2 Ret Spring 0407372 1/8POL 220V Molding Stop Locker IM-30 (Z) 0306095 Hose 6,00x3,5m 0407454 Cylinder INMES D24 x C10mm 0306460 Buffer G1/8POL 0407464 INMES Industrial ltda – Double Miter Saw IM-300P/ PL...

  • Page 62: Assembling The Dust Collector

    1) Take the hose 01, the clamp 02 and with a screwdriver (not supplied with the machine) fix the hose on the dust collector 03 (fig. 04); 2) Proceed on the same way to fix the other side of the hose on the machine (fig. 05). Fig. 04 Fig. 05 INMES Industrial ltda – Double Miter Saw IM-300P/ PL...

  • Page 63: Spare Parts List

    Dust Collector Label 0405057 Wire PP 3x1,5 0412041 Ground Cable Label 0405066 Wire Holder 1/2POL 0412047 Static Electricity Label 0405074 Motor 0,75CV 220/380V 60Hz 0413008 PVC Hose 3POL 0407020 Motor 3/4 115/208-230V 0413020 INMES Industrial ltda – Double Miter Saw IM-300P/ PL...
  • Page 66 Caixa Postal 65 - CEP 88750-000 Braço do Norte - SC - Brasil h t t p : / / w w w . i n m e s . c o m . b r e-mail: vendas@inmes.com.br S A C 0 3 0 0...
