5.5 Capacitive Touch Sensors
5.5.1 PITCH Bend Wheel
Use the PITCH bend wheel to get the bend. Slide up or down to adjust the pitch.
return to neutral.
5.5.2 MODULATION Wheel
Use the MODULATION wheel to get the result of vibrato : Slide up or down to adjust the level of
vibrato.
5.5.3 OCTAVE/TRANSPOSE
Use OCTAVE / TRANSPOSE buttons to adjust the piano octave. Press the two buttons
simultaneously to reset.
With holding SHIFT, use OCTAVE/TRANSPOSE buttons to adjust the piano transpose. With holding
SHIFT, press the two buttons simultaneously to reset.
5.6 Reset to factory settings
1.
Power off and unplug the keyboard.
2.
Press and hold button 1 and 2 at the same time.
3.
Connect a USB cable to the keyboard and the display shows "
after 3 second sand the keyboard is now Factory
settings.
6
Release and
". Release the buttons
