Features; Operations; Shift; Sub-Functions Under Edit Mode - midiplus X mini User Manual

4. Features

1. X mini MIDI keyboards include X2 mini, X3 mini, X4 mini and X6 mini which have 25, 37, 49
and 61 weighted keys respectively.
2. X mini MIDI keyboard is hot plug supported. No driver is needed. It is powered by USB
and no external power supply is needed.
3. Capactive touch sensors to control PITCH and MODULATION.
4. Featured with SHIFT for customised functions and OCTAVE/TRANSPOSE.
5. 4 customisable knobs; Default setting: T1 (Volume), T2 (Pan), T3 (Expression Controller), T4
(Reverb).
6. 6 customisable buttons; Default set up for playback.
7. 1 MIDI out, 1 SUSTAIN pedal, 1 USB

5. Operations

5.1 SHIFT

When switched on, the keyboard is in performing mode and each key functions as labelled
above itself. Pressing and holding the SHIFT button, the keyboard will shift to edit mode (LCD
display shows "
keyboard will be back in performing mode.

5.2 Sub-functions under edit mode

5.2.1 Other key sub-functions (Setting will be memorised after setup)
(1) VEL: Key force sensitivity curve (1 - 3)
(2) CTRL CC: Controller CC setting (0 - 127)
(3) CTRL CHL: Controller channel setting (0 - 16)
(4) BANK MSB: Sound library tens adjustment (0 - 127)
(5) BANK MSB: Sound library digits adjustment (0 - 127)
"). Then select your function and press ENTER. Release SHIFT and the
3
