- Page 1 RCY21208 Manual Crimp Hand Tool For Mini-PV Contacts AWG 22-26 User’s Manual Revision : 03 Date : November 4, 2007 www.foehrenbach.be...
- Page 2 1. Purpose Crimping of Mini-PV AWG 22-26 loose piece contacts onto dedicated stranded wire. 2. Tool description Cat. No.: RCY21208 Single head crimp tool. The tool crimps one contact per cycle. Short set-up times. Releasable ratchet ensures the complete crimping process.
- Page 3 Introduce the contact. Push the contact till it reaches the hard stop. Push the locator towards the crimping die. A magnet will keep the locator in position. Attention! This is only possible when the crimping die is open. RCY21208 User’s Manual Rev.: 03 Date: November 4, 2007 Page 3/8...
- Page 4 For any support, please contact Föhrenbach Application Tooling: Föhrenbach Application Tooling Krijgsbaan 128 B – 2640 Mortsel Belgium RCY21208 User’s Manual Rev.: 03 Date: November 4, 2007 Page 4/8 www.foehrenbach.be...
- Page 5 For operator safety, it’s necessary to apply eye protection. Apply the tool only in a dry and clean environment. Apply the tool only in a well lighted environment (1000 Lux). RCY21208 User’s Manual Rev.: 03 Date: November 4, 2007 Page 5/8...
- Page 6 : 10 to 90% R.H. reduced operation 9.3. Atmospheric pressure Normal range: 533 - 1060 m bar. 10. Power connections 10.1. Electrical No electrical supply required. 10.2. Pneumatic No air supply required. RCY21208 User’s Manual Rev.: 03 Date: November 4, 2007 Page 6/8 www.foehrenbach.be...
- Page 7 The technical data in this publication has been carefully checked and assembled. No liability from inaccuracies or errors is assumed. The right to change or improve this document without notice is reserved. RCY21208 User’s Manual Rev.: 03 Date: November 4, 2007 Page 7/8 www.foehrenbach.be...
- Page 8 CERTIFICATE OF CONFORMITY We hereby certify that the hand tool RCY21208 described below has been manufactured and inspected, and is conform to applicable drawings, requirements and specifications, according to FCI spec TA-75. Serial number of hand tool: ……………………….. Specification: • Wire range AWG 22-26: 0.14 - 0.33 mm²...
