Lemon RX Stabilizer PLUS Receiver - Essential Instructions
Contents
Introduction ........................................................................................................................................................ 2
What does the Stabilizer PLUS do? ..................................................................................................................... 2
Requirements of the Stabilizer PLUS .................................................................................................................. 2
Transmitter ..................................................................................................................................................... 2
Servos and Power Sources .............................................................................................................................. 3
Installation and Setup ......................................................................................................................................... 4
Binding (Bind Plug in channel 7) ..................................................................................................................... 4
Setting Failsafe (Bind Plug in channel 7) ......................................................................................................... 5
Preparing to Fly ................................................................................................................................................... 6
Your First Flight ................................................................................................................................................... 7
Resetting the Stabilizer ....................................................................................................................................... 7
Resetting Level and Alignment (Toggle).......................................................................................................... 7
Resetting Stick Neutrals (Toggle) .................................................................................................................... 8
Special Options ................................................................................................................................................... 9
Stabilizer Always-ON (Rebind) ........................................................................................................................ 9
Changing Mode Order and Autolevel Setting (Bind Plug in channels 4, 5, 6)................................................. 9
Hardware Reset (Bind Plug in channels 2, 3, 4) ............................................................................................ 10
Other Issues ...................................................................................................................................................... 10
Using a Two-Position Switch to Control Stabilization ................................................................................... 10
Using the Stabilizer PLUS with a DX6i ........................................................................................................... 10
Mixing ........................................................................................................................................................... 11
Stabilizer Mode Settings ............................................................................................................................... 11
Alignment and Location ................................................................................................................................ 11
Mounting ...................................................................................................................................................... 11
Vibration ....................................................................................................................................................... 12
Further Information
For more detailed information see the Complete Guide to the Lemon RX Stabilizer PLUS, available at:
https://www.rcgroups.com/forums/showpost.php?p=29478801&postcount=4
A number of short instructional videos for the Stabilizer PLUS are available on the same RCGroups post.
To offer comments or raise questions about the Stabilizer PLUS or the instructions, please go to The Official
Lemon STABILIZER PLUS thread on RC Groups:
https://www.rcgroups.com/forums/showthread.php?2800238-The-official-Lemon-STABILIZER-PLUS-thread-
New-Users-read-first-6-posts-%29
Lemon Stab Plus Essential Instructions 2017 v.1a.doc
Lemon RX
Stabilizer PLUS 7-Channel Receiver
Essential Instructions
2017-01-07
Page 1
