− Only use the enclosed drill bit for metal, wood and plastic.

Inserting tools

1. To clamp in one of the drill bits
turn it counterclockwise (see fig. D). This will open the quick-action drill chuck.
2. Select
• the suitable drill bit and insert it in the quick-action drill chuck.
• the suitable bit and insert it with the hexagonal side in the quick-action drill
chuck.
3. Turn the quick-action drill chuck clockwise until tight (see fig. D).

Removing tools

1. Turn the quick-action drill chuck
2. Take the tool out of the quick-action drill chuck and store it properly in the
storage case

Screwing and drilling

1. If you would like to drill or screw into soft wood, mark the applicable area.
2. Push the rechargeable battery
until the rechargeable battery locks into place.
3. Insert a drill bit
4. Turn the torque adjustment ring
• to the symbol (drilling) if you would like to drill into wood, plastic or metal.
Do not use this setting when screwing.
• to the desired torque if you would like to screw:
Low torque: small screws and sensitive materials.
High torque: large screws and robust materials.
The torque adjustment ring will then audibly lock into place.
5. Use the gear switch
and the gear switch simultaneously to avoid damaging the cordless drill.
Speed 1: 0 to 400 rpm
Speed 2: 0 to 1600 rpm
Speed 1 is suitable for screwing and drilling a large bore diameter.
Speed 2 is suitable for drilling a small bore diameter.
6. Set the rotation direction of the quick-action drill chuck using the right-handed/
left-handed rotation selector
towards the quick-action drill chuck) so that the quick-action drill chuck turns
clockwise. Select left-handed rotation (arrow pointing away from the quick-action
drill chuck) so that the quick-action drill chuck turns counterclockwise.
13 .
11 or a bit 12 (see chapter "Inserting tools").
3 to select 1st or 2nd gear. Do not push the On/Off switch
5
11 or a bit 12 in the quick-action drill chuck
counterclockwise (see fig. D).
1
6 all the way into the rechargeable battery holder
2
: Select right-handed rotation (arrow pointing
Operation
1 ,
9
21
