“ RUN or ON “ and the “ START or CRANK “ positions, and 0 Volts when the key is turned to the “ OFF “ and “ ACCESSORY “ positions. RED w/WHITE TRACE WIRE FROM PRO 9171FT IGNITION SWITCH KEY POSITION SPLICE(TYP.)
Page 3
Grey w/ Black wire; see Brown w/ Black tracer wire. BROWN Wire: Positive Inhibit Input 1 Any time + 12 Volts is applied to the Brown wire, the Remote Starter will stop operating, even if the signal is received from the transmitter.
Page 4
Orange sleeve, and are either both Black, both Yellow, or both White wires. Consult the factory service manual for additional information. 3. Connect the Light Blue wire from the Remote Starter to terminal 86 of an external relay. Connect terminal 85 of the relay to a fused + 12 Volt battery source.
Page 5
DARK GREEN Wire: Tach Sensor Input This wire will continually monitor the tach rate while the engine is running under power supplied by the Remote Starter. This wire will be routed through the fire wall into the engine compartment. It is necessary to use an existing grommet when passing wires through the fire wall to prevent short circuiting.
Page 6
1. RF Programmable Features: Feature Selection 1 Flash First 1 Second Door Locks Second 10 Minute Run Time Third Park Lights Steady On Fourth (No Function) Fifth (No Function) Sixth Ignition 2 Off During Crank Diagnostics Off Seventh Eighth (No Function) To program these selectable features: 1.
1. Locate the Orange / Black reference wire in the" C2" connector found at the ECM in GM B Body vehicles or, locate the equivalent reference wire in the vehicle you are installing the Audiovox Remote Start Unit in. 2. Connect the Cathode, (Striped) end, of a 4000 series diode to this reference wire.
Mechanical Neutral Start Switch from starting in gear. AUDIOVOX ADVISES THAT YOU MAINTAIN THE FACTORY CIRCUIT WHENEVER POSSIBLE. The following two circuits may be used only if the above circuit is not available.
Page 9
E. Connect the cathode (striped) side of a 4002 series diode to this same wire, and connect the (non striped) side to the negative shut down safety wire (Gray / Black) of the Audiovox Remote Start Unit. F. Connect terminal 86 of the relay to a fused +12 volt constant battery source.
Make sure the surface is clean before applying the label. 5. Replace all panels that were removed during installation, and re-test the system. 6. Explain all activated features of the remote starter to the customer. above.
Page 11
BRAKE SWITCH BROWN POSITIVE INHIBIT 1 CONTROL SWITCH BLACK w/WHITE CHASSIS GROUND HOOD PINSWITCH GREY IGNITION3 LIGHT BLUE SHOCKBY-PASS GREY w/BLACK NEGATIVE INHIBIT 2 BLACK TO CHASSIS GROUND DARKGREEN TACH YELLOW w/BLACK TO ALARM'S IGNITION INPUT- (YELLOW WIRE OF AUDIOVOX ALARMS)
