Avadesign DP-104 Manual

Ip video door phone and app
Hide thumbs Also See for DP-104:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installer and User Manual
Avadesign Technology
DP-104
IP Video Door Phone
APP
and
-
1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP-104 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avadesign DP-104

Summary of Contents for Avadesign DP-104

  • Page 1 Avadesign Technology DP-104 IP Video Door Phone...
  • Page 2 The DP-104 SIP IP Video Door Phone is easily to setup and configuration via a web browser. Just using your smartphone or tablet, you can see, answer and talk to visitors who at your door and open door for them.

  • Page 3: Table Of Contents

    2.2.5 How to share the DP-104 door phone with your family .......

  • Page 4: Chapter 1 Introduction

    If you want to identify who is at your door before you answer the phone or before letting them in, then the DP-104 IP video door phone is available with a built-in IP camera supporting up to 1280 x 720 HD video. This video can be viewed in a web browser and shows real-time video on a PC or on a mobile phone/tablet that supports iOS and Android.

  • Page 5: Vbell App Features

    Avadesign Technology home. With the VBell DP-104 SIP IP video door phone you can respond to visitors at anytime and anywhere.  Can be combined with the IP Phone as a tool of open door When the IP video door phone is dialed into the IP-PBX, it rings to the specified IP phone extension, and the caller opens the door by pressing the key.
  • Page 6  Can be shared and used with family members You can share your DP-104 SIP IP video door phone with your family via the VBell Smartphone / Tablet VBell APP function. You can also cancel the sharing function at any...

  • Page 7: How It Works

    Connect power adapter to the DP-104 SIP IP Video Door Phone that not build-in PoE to power it and mount it near to your door. Connect the DP-104 to your Internet router using Ethernet cable. Done! You will now receive instant alerts with sound on your smartphone or tablet if someone pushes the call button of DP-104 Door Phone, you can see and talk with your visitor in real-time.

  • Page 8: Chapter 2 How To Install

    The V-Bell DP-104 SIP IP Video Door Phone requires minimal configuration for a typical installation. 2.1 DP-104 Door Phone Installation 2.1.1 Open carton Open the carton and take out the DP-104 SIP IP Video Door Phone. Your package should include:  One DP-104 SIP IP Video Door Phone ...

  • Page 9: Wiring And Mounting On The Wall

    Power supply RJ-45 Cable, connect to the DP-104  Fix the DP-104 IP video door phone on the wall using a roof or a panel and two screws as shown the diagrams below: Fig. 1 Mounting on the wall with Roof...

  • Page 10: Plug In

    The VBell Service is the cloud service and free charge that provided by Avadesign Technology for the DP-104 SIP IP Video Door Phone application. 2.1.6 Access VBell service The DP-104 SIP IP Video Door Phone will access the VBell service directly and start to work automatically. Now, you can test the DP-104.

  • Page 11: Vbell App Installation And Instructions For Use

    Avadesign Technology 2.2 VBell APP Installation and Instructions for use Next, learn how to install VBell APP on your smartphone / tablet to provide you the intercom cloud service. 2.2.1 How to Download You can find Apple Store or Google Play Store...
  • Page 12 Avadesign Technology Then you can install “VBell” on your smartphone. Step 1: Please click “INSTALL” button on the screen of your smartphone. The screen will show as below: Step 2: Please click “ACCEPT” button on the screen of your smartphone.

  • Page 13: Ios Smartphone/ Tablet Download Method

    Avadesign Technology Step 3: Please click “OPEN” button on the screen of your smartphone to create VBell application. 2.2.1.2 iOS Smartphone/ Tablet Download Method You can find Apple Store on the screen of your smartphone tablet. Apple Store At first, click “Apple Store” icon then please search for “vbell”. Found VBell now! Then please click “INSTALL”...

  • Page 14: How To Apply For A New Account

    Avadesign Technology Please wait a minute for the VBell app file download. The size of VBell app file is 19.7MB. The screen of your smartphone will show the percentage of downloading. When the download has completed, please click “OPEN” button on the screen of your smartphone to create VBell application.
  • Page 15 Avadesign Technology Step 7: Then you will see the success message of a new account registration on the screen. And click “Ok” button here. Step 8: Then you will return to “VBell” page again and click “Login” button on the screen.
  • Page 16 Avadesign Technology After sign in, you will see this tuition page. Step 9: Please click “I know” button to skip this page. Then you will see the screen was shown at right side: No any door phone shows on the screen now.

  • Page 17: How To Add Your New Door Phone

    Avadesign Technology The account application of the IOS smart phone / tablet is the same as above steps 2 ~ 10. The color of screen and the type of button are different from Android smart phone. Please reference to the following screen.
  • Page 18 Avadesign Technology iOS smartphone/ tablet screen 【Remark】 If you lost the Quick Installation Guide, please feel free to contact your Avadesign representative. Tell him/her the MAC number on the bottom of your new door phone that shown as below. Avadesign representative will provide the Activation Code for you.
  • Page 19 Avadesign Technology Then you will see the successful information after scanning. Please press “ok” button. At the same time, you will see the activation code of your new IP door phone display on the screen. Step 12: Click on “OK” button...
  • Page 20 Avadesign Technology Then the image of the DP-104 SIP IP video door phone will be displayed on your smartphone. As shown below. Congratulation! Your installation is successful. Now you can click and view the video of DP-104 IP door phone. And you also can make real time two way communication.

  • Page 21: Setting

    Avadesign Technology Now you can see the video of DP-104 IP door phone display on the screen of your smartphone. Step 15: You can see and speak with visitor who at your door. Then open the door for visitor. 2.2.3.1 Setting 「Setting」provides do not disturb function for you.

  • Page 22: History

    Avadesign Technology 2.2.3.2 History Click the “History” button on the screen of your smartphone/ tablet, the incoming call recent records of door phone (up to 30 records) will be shown as below. Click on this picture to see the visitor...

  • Page 23: Update And Modify Your Door Phone Information

    Avadesign Technology 2.2.4 Update and modify your door phone information You can edit and modified the data of door phone such as change door phone’s name or delete the door phone or share your door phone with others or find the door phone IP information.

  • Page 24: Chang Your Door Phone's Name

    Avadesign Technology 2.2.4.1 Change your door phone’s name You can change the name of your door phone by input a new name using keyboard on the screen. .Please refers to following screenshot: iOS smartphone / tablet screen Android smartphone / tablet screen...

  • Page 25: Find The Ip Address Of Your Door Phone

    Avadesign Technology 2.2.4.2 Find the IP address of your door phone You can find the detail IP information of your door phone by selecting this function. Detail IP information of door phone. iOS smartphone / tablet screen Android smartphone / tablet screen...

  • Page 26: How To Share The Dp-104 Door Phone With Your Family

    Avadesign Technology 2.2.5 How to share the DP-104 door phone with your family You can share your DP-104 SIP IP video door phone with your family member or others by selecting 「Share Setting」 function. Step 1： Select and click 「Share Setting」...
  • Page 27 / tablet screen Android smartphone / tablet screen In addition, other users can also share his or her DP-104 door phone with you. If other user shares door phone with you, the door phone picture will appear in the area of “Share DoorPhone”.

  • Page 28: Cancel The Sharing

    Avadesign Technology 2.2.6 Cancel the Sharing Click the "Delete" button behind the sharer who you want to cancel, you may cancel this member to share your door phone. Click the “Delete” button, you may cancel this member to share your door phone.

  • Page 29: Chapter 3 How To Operate And Application

    When the visitor comes to ring the bell Open Door Hang up DP-104 IP video door phone and VBell intercom APP build your intelligent access control management system. It brings more convenient communication and more secure access management for your family.
  • Page 30 【Remark】 DP-104 IP video door phone also provides full Web configuration for setting door phone functions and services depending on what your need. Please refer to DP-104 SIP IP video door phone user manual. 30 -...
