1.
Packing List
1. Prestigio MultiPad
2. Quick Start Guide
3. AC Adapter
2.

Device Overview

7
Earphone Jack
1
DC Port
2
Micro USB Port
3
Power\Lock
4
Switch
PMP5070
USER MANUAL
Prestigio MultiPad
PMP5070
Earphones connection
AC adapter connection for charging.
USB connection
Press the switch left to turn on the device.
Press the switch right to turn off the screen.
When the device is on, but the screen is off,
press the switch left to turn on the screen.
4. USB Cable
5. Warranty Card
6. Legal and Safety notice
1
2
3
8
4
5
6
EN - 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MultiPad PMP5070 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Prestigio MultiPad PMP5070

Summary of Contents for Prestigio MultiPad PMP5070

  • Page 1: Device Overview

    USER MANUAL Prestigio MultiPad PMP5070 Packing List 1. Prestigio MultiPad 4. USB Cable 2. Quick Start Guide 5. Warranty Card 3. AC Adapter 6. Legal and Safety notice Device Overview Earphone Jack Earphones connection DC Port AC adapter connection for charging.

  • Page 2: Getting Started

    USER MANUAL Prestigio MultiPad PMP5070 Press and hold to select one of the following options: Power off: Turn off the device. Suspend: Activate sleep mode. Cancel: Return to the home screen. Micro SD Card Insert the SD card Slot Charge Indicator...
  • Page 3 USER MANUAL Prestigio MultiPad PMP5070 turning off option. Power off: Turn off the device. Suspend: Activate sleep mode. Cancel: Return to the home screen  Press the switch left to turn on the device. Press the switch right to turn off the screen. When the device is on, but the screen is off, press the switch left to turn on the screen.

  • Page 4: Home Screen

    USER MANUAL Prestigio MultiPad PMP5070 Home screen Home screen  Your device has a resistive sensitive screen. It is operated by touching the screen surface with your finger. Status bar The status bar displays the home button, time, battery status, alarm, WiFi and controls area.
  • Page 5  To modify the default behavior, open the orientation settings by touching → Settings → Sound & display→Orientation.  Prestigio home screen allows to adjust it according to the user’s preferences. PMP5070 EN - 5...
  • Page 6 Prestigio MultiPad PMP5070  Prestigio home screen is made up of four individual rooms. Each room fits the physical display border and can be set to have its own shortcuts and widgets. You can move around the home screen in two...
  • Page 7 USER MANUAL Prestigio MultiPad PMP5070 To remove a Home screen item:  Touch and hold an item such as a widget, shortcut, or folder that you want to remove, until it magnifies and becomes movable.  Drag the item onto the top of the delete icon , and when the item becomes red release it.
  • Page 8 USER MANUAL Prestigio MultiPad PMP5070  You can access the Google Search tool directly from home screen by tapping anywhere on the Google search bar. Note: Please, make sure your device is connected to the Internet. Keyboard controls for inserting text: ...
  • Page 9 USER MANUAL Prestigio MultiPad PMP5070  Touch the Menu button →Settings →Language & keyboard→ Android keyboard.  To enable a setting, touch the setting option to select the check box ; to disable a setting, touch the setting option to clear the check Available keyboard settings: The device beeps when you touch a key.
  • Page 10 USER MANUAL Prestigio MultiPad PMP5070  Touch OK. To edit a word in the dictionary: →Settings →Language & keyboard→  Touch the Menu button User dictionary.  Touch a desired word.  Touch Edit.  Edit the spelling of the word in the Edit word text field.

  • Page 11: Connecting To Internet

    USER MANUAL Prestigio MultiPad PMP5070  Touch Menu button →Settings →SD card & phone storage.  Touch Unmount SD card to enable the Format SD card option. CAUTION: Formatting a microSD card erases all data and downloaded applications, stored on it. Ensure that you back up the data that you need before formatting your microSD card.
  • Page 12 USER MANUAL Prestigio MultiPad PMP5070 Browsing the Web  Choose Browser. To use the browser controls bar: Touch the web page address field and type the address of the web page. Touch to view bookmarks, most visited web pages, and browsing history.

  • Page 13: Select Text

    USER MANUAL Prestigio MultiPad PMP5070  Touch the web address of a desired web page. The window opens displaying the page in full screen. To find text within a web page: →Find on page.  When viewing a web page, touch ...

  • Page 14: Managing Bookmarks

    USER MANUAL Prestigio MultiPad PMP5070 To check your most visited web pages, touch the Most visited tab. Allow downloading web applications: Applications downloaded from the web can be harmful. To protect your device and personal data, download applications only from trusted sources such as AppsLib.
  • Page 15 USER MANUAL Prestigio MultiPad PMP5070 open, edit the bookmark, add it as shortcut and share. Settings Browser settings On the browser screen, touch →Settings to adjust the browser settings. Sound and display settings →Settings→Sound & display.  Touch  To enable a setting, touch the setting option to select the check box ;...

  • Page 16: Notification Ringtone

    USER MANUAL Prestigio MultiPad PMP5070 preferred timeout period; to disable this feature select Never timeout. The screen automatically turns off and locks itself after an inactivity timeout selected here has passed. To turn on and unlock the screen, press the Power switch.
  • Page 17 USER MANUAL Prestigio MultiPad PMP5070  The device will be automatically recognized by the PC. Please, transfer the necessary content using Windows Explorer. Downloading applications  The device offers 2 ways of downloading applications – from a web-site or from a PC.
  • Page 18 USER MANUAL Prestigio MultiPad PMP5070 Downloading content from AppsLib  You can download free or paid applications directly from your device using the AppsLib application marketplace.  Before entering the AppsLib make sure the WiFi connection is established.  With Internet connection established, press the icon on the Home screen.
  • Page 19 USER MANUAL Prestigio MultiPad PMP5070 Applications Audio Player  Press to open the Audio Player.  The list of audio files will be displayed. Touch any audio file to play it. All music Touch to display the list of all available music files.
  • Page 20 USER MANUAL Prestigio MultiPad PMP5070 playlist.  The play interface displays the song name, author, location folder and other available information. Touch and hold anywhere on the song information to search for the song author using Music player or Browser.
  • Page 21 USER MANUAL Prestigio MultiPad PMP5070  To exit Audio Player pause the current track and touch twice Video Player  Press to open the Video Player.  The list of video files will be displayed. Touch any video file to play it.
  • Page 22 USER MANUAL Prestigio MultiPad PMP5070 Photo Viewer  Press to open the Photo Viewer.  Image folders and images will be displayed. Touch any item to display  During image playback touch the screen to display menu bars.  The following menu items are available: Zoom in Touch to zoom in the current image.
  • Page 23 USER MANUAL Prestigio MultiPad PMP5070 Photo Frame  You can set the device to work as a photo frame.  Touch to open the Photo Frame.  The following interface is displayed: Touch to start/pause the slide show. Touch to enter the list of images and select the image folder for displaying.
  • Page 24 USER MANUAL Prestigio MultiPad PMP5070 Email You can create POP3, IMAP, and exchange e-mail accounts from web-based e-mail services on your device.  Touch to open the Email. Setting up an email account:  Type the e-mail address and password of the e-mail account you want to add and then touch Next.
  • Page 25 USER MANUAL Prestigio MultiPad PMP5070 Files  You can access all files and folders on the device by touching  The following interface will be displayed: Note: In order to operate with SD Card and USB these devices must be connected.

  • Page 26: Technical Specifications

    USER MANUAL Prestigio MultiPad PMP5070 Technical Specifications Processor RockChip 2818 ANDROID™ 2.1 “Eclair” Display 7” TFT LCD, High resolution Touch screen with virtual keyboard, 16 million colours Resolution High resolution, 800 x 480 pixels, 16 million colors H.264 up to 720p resolution – 30 fps / 2.5 Mbps.
  • Page 27 No liability can and will be accepted for any errors or omissions. Prestigio reserves the right to make any changes without further notice to any products herein.
