CHS12LB50
Battery Charging Station
For use with Lectrosonics LB-50 battery only
FCC NOTICE:
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a
residential installation. The equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equip-
ment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
•
•
•
•
Changes or modifications to this equipment not expressly approved by Lectro-
sonics, Inc. could void the user's authority to operate it.
Fill in for your records:
Serial Number:
Purchase Date:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and receiver
Connect the equipment into an outlet on a circuit different from that which
the receiver is connected
Consult the dealer or an experienced radio/TV technician for help
Charge ONLY
Lectrosonics
LB50 batteries
INSTRUCTION MANUAL
LB50 Charging Station
Rio Rancho, NM, USA
www.lectrosonics.com
