8.5 SPECIMEN ORIENTATION ADJUSTMENT
Turn hand wheel to its highest position
and activate the hand wheel stop.
For orientation of the specimen, open the
fixing lever.
For upward and downward orientation
use the upper orientation wheel.
For orientation to the left and right use
the left orientation wheel.
Close the orientation fixing lever.
Release hand wheel lock for cutting.
Instructions – MEV
Opening of orientation fixation lever and
orientation of object holder upwards and
downwards.
Orientation of object holder to the left and right.
Fastening of orientation fixation.
