Slee Cryostat MEV Operating Instructions Manual page 21

For adjusting the cutting angle of
the blade, loosen the blade holder
fixation by turning the right lever on
the blade holder base counter
clockwise.
Set new angle for cutting by turning
the knob in the front of the blade
holder or by manual tilting the
blade holder. A tilt towards the
object holder increases the cutting
angle (clockwise turn of the knob),
a tilt away from the object holder
decreases the cutting angle (counter
clockwise turn of the knob).
Tighten the blade holder fixation by
turning the right lever on the blade
holder base clockwise.
Release hand wheel lock for cutting.
Instructions – MEV
Loosening of blade holder fixation and adjusting new
cutting angle (increased cutting angle).
Fixation of blade holder with increased cutting angle.
