Part Name & Functions
1
Dome Cover
1
Dome Cover
Covers the inner cover, lens, and main body to protect them.
2
SD Card Slot
3
Reset Button
All the settings will be restored to the factory default. Power
On the unit and push the button for 5 seconds.
WARNING
YOU WILL LOSE ALL DATA THAT HAD BEEN ENTERED PREVIOUSLY AND
THE IP DOME CAMERA WILL BE SET TO ITS FACTORY RESETS.
4
Main Body
Includes a lens, a connecting slot, a PCB board, screws and
such.
4
Main Body
5
Tilt Stopper Screw
Using this screw, the slope of the lens can be adjusted and
fixed.
6
Test Video Slot
Use it to connect the test video calbe.
7
Audio In/Out Port
8
Terminal Block
Connect the power, alarm I/O device.
9
RJ-45 Connector
Connect the crossover cable.
6
2
SD Card Slot
3
Reset Button
5
Tilt Stopper Screw
6
Test Video Slot
7
Audio In/Out Port
8
Terminal Block
9
RJ-45 Connector
