- Page 1 Easy Educator EZ-902 Quick Start Guide E-Collar Technologies, Inc.
- Page 2 Welcome Thank you for trusting us with your purchase of the 902 Easy Educator Remote Education Collar. We have made every attempt to provide you with the most technologically advanced product using the most stringent quality and manufacturing standards. We are confident you will be pleased with the results you will attain with the 902 Easy Educator.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Characteristics Package Contents Turning ON/OFF the EZ-902 System / Charging Instructions EZ-902 Functions LCD Display 2 Dog Mode Buttons Descriptions and Stimulation Button Assignments I Mode Lock and Unlock Stimulation Level Booster Level Setup Lost Transmitter Activation Pairing EZ-902 Two Dog Default Settings Warranty and Registration... -
Page 4: Characteristics
CHARACTERISTICS 1/2 mile Range Employs Quick Charge Li-Polymer Batteries Convenient Intensity Dial for Quick Adjustment Stimulation Levels Adjustable from 0 to 100 Collar Receiver Light for Night Tracking “Lock and Set” Stimulation Safety Feature User Adjustable Boosting Levels Provides 2 Control Buttons for Each Dog Patented “I”... -
Page 5: Package Contents
PACKAGE CONTENTS Ergonomic Transmitter Waterproof Collar Quick Start Owner’s Receiver High Quality - Remote-Sender Guide Biothane Strap Easy Educator EZ-902 Quick Start Guide E-Collar Technologies, Inc. Test Light Contact Point Tool 5/8” and ¾” Contact Points Lanyard Battery Charger Splitter Cable... -
Page 6: Turning On/Off The Ez-902 System / Charging Instructions
T urning ON/OFF the EZ-902 System Turn ON/OFF the transmitter by pressing the lower right button for 1 second. To turn ON/OFF the collar receiver simply position the red dot on the backside of the transmitter against the red dot on the collar receiver for 1 second. Charging Instructions Please charge the units on or before the low battery indication. -
Page 7: Ez-902 Functions
EZ-902 Functions Easy Educator 902 provides 5 types of stimulation sensations, tone, and vibration. Stimulation Icon Function Description Momentary Stimulation Send Momentary Stimulation (Volume Level) Send Momentary Boosted Stimulation Momentary Boost Stimulation (Volume + Boost Level) Sends Continuous Stimulation Continuous Stimulation (max 10 sec, volume level) Sends Continuous Bboosted Stimulation Continuous Boost Stimulation... -
Page 8: Lcd Display 2 Dog Mode
LCD DISPLAY 2 DOG Mode Icon Description Remarks Momentary Stimulation Short Pulse of Stimulation Momentary Boost Stimulation Short Pulse of Boosted Stimulation Continuous Stimulation Up to 10 Seconds of Stimulation Continuous Boost Stimulation Up to 10 Seconds of Boosted Stimulation Stimulation Level Displayed on the LCD, Instant Stimulation Mode Must Start From “0”... -
Page 9: Buttons Descriptions And Stimulation Button Assignments
Buttons Descriptions and Stimulation Button Assignments The 902 Easy Educator has 4 control buttons which are assigned to stimulation, vibration and tone. S1 / S3 buttons are programmed for Dog 1 and S2 / S4 buttons are programmed for Dog 2. It also has 2 program buttons for changing modes (P) and turning the unit ON and OFF. - Page 10 Program Function Description Buttons Press more than 1 sec to turn ON Power ON/OFF Press more than 2 sec to turn OFF 1D light : ON/OFF + S1 ON/OFF (toggling : blink solid off) Night Lights 2D light : ON/OFF + S2 (toggling : blink solid off) 1D Volume lock : P+S3 (more than 1 sec) Volume Lock...
-
Page 11: I Mode 1
I Mode “I” Instant Stimulation Mode “I” Instant Stim ulation Mode The "I" mode is a patented feature which allows the stimulation to increase gradually as determined by the user. The gradual introduction of stimulation provides a more gentle sensation and removes the startling effect sometimes associated with applying a constant level of stimulation. -
Page 12: Lock And Unlock Stimulation Level
Lock and Unlock Stimulation Level Lock and Unlock Stimulation Level for Dog 1 Lock and Unlock Stimulation Level for Dog 1 1. Check LCD display to confirm 1D icon is blinking. 2. Set the desired stimulation to lock by rotating the volume dial. 3. -
Page 13: Booster Level Setup
Booster Level Setup Boost Level Setup for Dog 1 Boost Level Setup for Dog 1 1. Change the mode of S1 or S3 button to Momentary if not already programmed to “M” mode. 2. Change the Stimulation level to “0” (Stimulation level should be unlocked) 3. -
Page 14: Lost Transmitter Activation
Lost Transmitter Activation Lost Transmitter Activation (6 Hour Timer) 1. Change the Stimulation level to “0” 2. Press ON/OFF button and then press P button simultaneously. 3. One short beep will sound confirming the activation of the locator timer. 4. To deactivate, press ON/OFF button and P button one more time. 5. -
Page 15: Pairing 1
Pairing/Syncing When you change transmitters or collar receivers they will need to be paired/ synced to each other for them to communicate with each other. Pairing for Dog 1 (ON/OFF + S3) Pairing for Dog 1 (ON/OFF + S3) 1. Turn on the Transmitter. 2. -
Page 16: Ez-902 Two Dog Default Settings
EZ-902 Two Dog Default Settings Factory default setting of EZ-902 is as below. You can change Tone Mode, Vibration Mode, and Instant Mode by using computer interface tool which can be downloaded on our website www.ecollar.com. Factory Default Setting S1-Button 1D Momentary S2-Button 2D Momentary... -
Page 17: Warranty And Registration
(1) Go to the “Products” section on www.ecollar.com www.ecollar.com and click the “Register Your e-Collar Products” tab and complete the form (2) Fill out the provided warranty registration card and mail it or fax it to us at 1-855-226-5527. -
Page 18: Contact Information
International : 001-260-357-0051 www.ecollar.com sales@ecollar.com customerservice@ecollar.com This product is covered by various patents including but not limited to patents 8757098 and 8833309. Patent is pending on the Instant Stimulation Feature on this device. Copyright 2014 E-Collar Technologies, Inc. All Rights Reserved. - Page 19 IMPORTANT INFORMATION About Contact Points: Many dogs in our modern society have developed sensitivity to nickel which is a metal in all stainless steel products. Keep a watchful eye on your dogs skin where the contact points are touching his/her skin for redness or any signs of irritation. This should be done hourly at first and slowly transition to once every four hours after a month of daily wearing of the e- collar.
- Page 20 E-Collar Technologies, Inc. 2120 Forrest Park Drive Garrett, IN 46738-1887 1-260-357-0051 (US & International) 1-855-326-5527 (US Toll Free) 1-855-226-5527 (US Toll Free Fax) sales@ecollar.com www.ecollar.com...
