VIDEO WEB SERVER
PATENT
User's Manual
Please read instructions thoroughly before operation and retain it
for future reference.
732 V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVC732 and is the answer not in the manual?

Questions and answers

Related Manuals for Avtech AVC732

Summary of Contents for Avtech AVC732

  • Page 1 VIDEO WEB SERVER PATENT User’s Manual Please read instructions thoroughly before operation and retain it for future reference. 732 V1.0...

  • Page 2: Table Of Contents

    WARNING The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

  • Page 3: What Do You Get

    What do you get ? FEATURES Video Web Server Features • Compatible with most of CCTV Products; empower any video output device watching and controlling on the Internet or LAN • Auto Network Reconnection (ANR) • Upgrade firmware & AP from FTP site via Video Web Server •...

  • Page 4: Rear Panel

    REAR PANEL Reset ALARM I/O DC 12V Video 1. VIDEO INPUT (2 channels) Connect to video source, such as camera or DVR video output. 2. ALARM I/O (optional for advanced applications) Connect control devices, such as PTZ, DVR and external alarm signal input. 3.

  • Page 5: Software Installation At Client Site

    1. Connect video output of camera or DVR with the video input of Video Web Server. 2. Connect PC with Video Web Server for IP setting. (Please refer to page 4) 3. Connect Video Server with ADSL or CABLE MODEM with Static IP address. 4.
  • Page 6 Step 2: Please enter the default IP address (192.168.1.1) in the browser. Then press ENTER. Click “ Download Windows AP” to download the application program and save “ Video web server.exe” in the HDD. Step 3 ： Click twice on the Video web server.exe and it will install the program into the PC. After the installation, there are 5 files in your assigned path (file folder) as below.

  • Page 7: Operation Guide

    Operation Guide STATIC IP SETTING Please set up the server IP before first execution of the program. Follow every step as instructed. If you have finished the setup, please jump to next section— software operation-- to operate the program (User need to apply one static IP address first).
  • Page 8 3.Click “Properties”for TCP/IP setup 4.Click “INTERNET PROTOCAL (TCP/IP)”and then select “Properties”to setup Before changing the PC network setting, please write down the original network setting in order to recover the original setting after the setup. Leave blank NOTE： The above steps are to connect PC and Video Server in one Domain (e.g.:192.168.1.XXX). The setting of “...
  • Page 9 Step 3： To configure the Server IP, please click twice to enter the setup. Step 4： Key in User Name, Password, and IP address (User Name and Password are both default at “ admin” ; IP address is 192.168.1.1, Port:80). Then click OK to connect. Step 5：...

  • Page 10: Software Operation

    Step 6： Connect the Video Web Server with ADSL or Cable modem through RJ-45 then you can operate it from the internet. INTERNET ADSL/CABLE MODEM RJ-45 NOTE： The attached LAN cable is standard CAT5 cable. In some operation environment, the user might need the crossover cable.
  • Page 11 [Introduction of Basic Operation] 1.Using device 2.Exit, Menu, Lock, Enter, Record 3.Left, Right, Up, Down, Stop 4.Rewind, Fast Forward, Pause, Slow, Play 5.PIP, Search, Zoom, quad screen, 7-9-10- 13-16 screen 6.Camera video input 1.IP address, assume the setting is 61.222.50. (last part) 2.Connection/Disconnection 3.Conceal/Resume video screen...

  • Page 12: Playback Operation

    PLAYBACK OPERATION Please find a “record” folder on the desktop and click twice on the recording file to playback. 1.ON SCREEN DISPLAY 2.Snapshot 3.Slow playback(1/2, 1/4, 1/8) 4.PLAY 5.Recording duration time 6.Fast Forward 7.Pause 8.Stop 9.Status 10.Playback controlling bar ADVANCED SETTING Click “System Config”for advanced setting.

  • Page 13: Dynamic Ip Setting

    1.Network Setting To set up the network setting of the Video Web Server. Check with your network administrator or Internet Service Provider. 2.IP Get Method The default setting is Static IP. 3.I/O Port Setting— refer to APPENDIX#1 Set up video input device. It supports our brand 1CH DVR, 4CH DQR, 4CH, 9CH, 16CH DMR, Multiplexer, and camera. 4.Device ID—...
  • Page 14 Step 3: Enter the default IP address ( IP： 192.168.123.254/ Default router gateway) to log in the router from the browser. And then enter the login web page and key in the default password “ admin” . Step 4： Click [Basic Setting] -> [Primary Setup] -> [Change] and change the Router internet setting.
  • Page 15 Step 5： Select [Basic Setting] -> [DHCP Server] and activate DHCP SERVER. Set up “ STARTING” and “ ENDING ADDRESS” and click “ Save” à” Reboot” Step 6： Select [Forwarding Rules] -> [Virtual Server] and set up “ 80” and “ 8888” port for Video Web Server.

  • Page 16: Ddns Apply

    DDNS APPLY Step 1： Connect to “ http://www.dyndns.org” Web page ( the below is only for example) and click “ ACCOUNT” à” CREATE ACCOUNT” Step 2： Register the information and click “ Dynamic DNS” (add host) Step 3： User can set up their own DDNS HOST. For example, the user’s applied Host name is “...

  • Page 17: Rs-485 Pin Define

    RS-485 PIN DEFINE PIN 1, 6. RS485-A, RS485-B Using RS485-A & RS485-B serial communications signals to control digital units just like DVR. PIN 4, 7, 8, 9. ALARM INPUT Using PIN 4,7,8,9 to receive the alarm input then trigger Video Server to send mail to users for auto e-mail warning system.

  • Page 18: Specifications

    SPECIFICATIONS Video Input 2 Channels for analog & digital products, 1.0 Vp-p, 75, Composite, BNC Alarm Input 4 Inputs Watch dog Yes* RS-485 Port Network Interface Ethernet (10/100 Base-T) Image Compression JPEG Video Adjustment Brightness, Contrast, Saturation, Quality Level adjust Protocols TCP/IP, ICMP, SMTP Hardware...
  • Page 19 2) Set the “ Remote” function in the DVR products. NOTE : Remote mode : RS-485, Baud rate : 2400, ID : same as “ I/O port setting” in the Video Web Server. A. 1/4 CH DVR B. 4/9/16 CH DMR 3) Set the “...

  • Page 20: Appendix#2 Email Sending

    APPENDIX#2 EMAIL SENDING 1) Connect the Sub-D plug of Video Web Server with the COM/NO ports of Sensor. 2) Set the “ mail setting” & “ Mail to : ” item in the system configure. NOTE1 : You can get all the data from the ISP company or mail server supplier (POP3/SMTP server). NOTE2 : You should set the mail list which you want to send to when the alarm is triggered.
