Summary of Contents for E-Wheels EW-29
- Page 1 EW-29 Owner’s Manual www.ewheelsdealers.com (888) 305-0881 Sales (888) 571-2845 Service...
- Page 2 Table of Contents Page 2 - Feature Guide Page 3 - Product Specifications Page 4 - Operation of Scooter Page 6 - Charging and Battery Maintenance Page 7 - Ramps and Curbs Page 7 - General Page 8 - Use While Under Influence Page 8 - Safety Requirements Page 10 - Warranty...
- Page 3 Folding Seat Lock Headlight Rear Basket Throttle Front Basket Chain Tensioner Chain Guard Front Wheel Motor...
-
Page 4: Technical Specifications
Technical Specifications Model EW-29 Weight Capacity 400Lbs Speed: Up to 15mph Distance: 20 miles per charge (distance varies on terrain, riders weight, road surface, etc.) Front Seat: Type Oversized with back rest Front seat: Size 10“ x 12“ x 9” (LxWxH) Front Seat: 32”... - Page 5 Operation of Scooter: 1. Turning on the power Insert key into ignition underneath the seat and turn clockwise to turn the scooter on. The battery indicator will display the current charge level when on. Turn the key counter- clockwise to power off when stopped. 2.
- Page 6 5. Headlight Switch The headlight is controlled with switch on the headset. -The “I” Symbol is on -The “O” Symbol is off 6. Seat Folding and Stabilizing Bolt The seat is locked in place to avoid removal of the battery without keys. The stabilizing bolt keeps the seat stable.
- Page 7 Charging Instructions: The smart charger included with your scooter will shut off when the scooter is fully charged. When the light on the charger is red, the scooter is still charging. When the light turns green, this means the scooter is fully charged.
- Page 8 Ramps and Curbs: 1. Check that the ramp surface is roughened to prevent slipping. Never drive across a slope or turn sharply on a slope. 2. When driving up curbs, always check the height of the curb to ensure that it does not exceed 4” height.
- Page 9 Safety Requirements: Driving Surface The EW-29 has the best stability and performs the best under the normal driving conditions (dry, level ground with concrete or asphalt). Extra care must be taken when riding on other surfaces (grass, gravel, etc.).
- Page 10 Changing the initial setting of refitting your scooter is forbidden. Use caution when operating near busy streets, markets, or shopping centers. Do not operate in unsafe areas. Consult local authorities about the traffic rules for scooters in your city. ...
- Page 11 Warranty: For valid warranty claims E-Wheels will, at their discretion, replace/repair/refund items mutually agreed to be defective. E-Wheels warranty as following: 1. Electronic components: (1) year limited warranty. 2. Controllers: (1) year limited warranty. 3. Batteries: Not warranted 4. Consumables: Not warranted (Tires, tubes, seat cushions, etc) 5.
Need help?
Do you have a question about the EW-29 and is the answer not in the manual?
Questions and answers
Battery pack is under rear basket, how do I remove plastic cover?
To access the battery pack under the rear basket of the E-Wheels EW-29, follow these steps:
1. Remove the stabilizing bolt to release the seat.
2. Turn the key to the left to unlock and lift the seat.
3. Insert the secondary key into the left-hand trunk latch release lock cylinder.
4. This unlocks access to the battery pack under the plastic cover.
These steps must be completed before the battery can be removed.
