Page 1 PROFESSIONAL QUALITY COOKING EQUIPMENT INSTALLATION MANUAL FOR MEDALLION DUAL FUEL RANGES MODEL NUMBERS: ARR-304DF, ARR-366DF, ARR-364GDDF, ARR-364GRDF, ARR-486GDDF, ARR-486GRDF, ARR-4822GDDF, ARR-484X2GRDF, ARR-60622GDDF, ARR-606X2GRDF, ARR-606GDGRDF DESIGN CLASS FUNCTION RETAIN THIS MANUAL FOR FUTURE REFERENCE © 2015 American Range All Rights Reserved...
Page 2: Table Of Contents
Installation Manual Residential Dual Fuel Ranges Table of Contents Warnings & Important Safety Instructions ..................1-4 Product Dimensions ............................5 Specifications & Electrical Requirements ..................6-7 General Instructions ............................8-9 Clearance Dimensions ..........................10-11 Installation Steps ............................12-20 Performance Checklist ............................21 Final Preparation ..............................21 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
Page 3: Warnings & Important Safety Instructions
Residential Installation, Operation and Dual Fuel Ranges Maintenance Instructions Installation Manual FOR YOUR SAFETY! Do not store or use gasoline or other flammable vapors or liquids YOUR YOUR in the vicinity of this or any other appliance. SAFETY SAFETY WARNING! Improper installation, adjustment, alteration, service WARNING WARNING...
Page 4 Installation Manual Residential Dual Fuel Ranges IMPORTANT - PLEASE READ AND FOLLOW! • Before beginning, please read all the instructions carefully. • DO NOT remove permanently affixed labels, warnings, or plates from product. This may void the warranty. • All local and national codes and ordinances must be observed, installation must conform with local codes. •...
Page 5 • The required use of a GFI is normally related to the location of a receptacle to any significant sources of water or moisture. • American Range will not warranty any problems resulting from GFI outlets which are not installed properly or do not meet the requirements below.
Page 6 Installation Manual Residential Dual Fuel Ranges IMPORTANT - PLEASE READ AND FOLLOW! Do not use the handle or oven door to lift the oven, remove pull down door WARNING before installation to ensure that it is not used to lift the unit. Make sure pins are inserted into hinges before removing door to prevent injury to hands and / or fingers.
Page 7: Product Dimensions
Installation Manual Residential Dual Fuel Ranges DIMENSIONS - DUAL FUEL RANGES 2 " 3 5 - - 1 / 7 / 8 2 " " - 1 / 2 " 2 9 - - 1 / 7 / 8 " 37"...
Page 8: Specifications & Electrical Requirements
Installation Manual Residential Dual Fuel Ranges SPECIFICATIONS & ELECTRICAL REQUIREMENTS DUAL FUEL RANGES - 30” & 36” Ranges Description 30” wide models 36” wide models Overall Width 30” 36” Overall Height To top of side trim 36-1/4”. Legs adjust 1”. Overall Depth 30”...
Page 9: Specifications & Electrical Requirements
Installation Manual Residential Dual Fuel Ranges SPECIFICATIONS & ELECTRICAL REQUIREMENTS DUAL FUEL RANGES - 48” & 60” Ranges Description 48” Wide Models 60” Wide Models Overall Width 48” 60” Overall Height To top of side trim 36-1/4”. Legs adjust 1”. Overall Depth 30”...
Page 10: General Instructions
Installation Manual Residential Dual Fuel Ranges GENERAL INSTRUCTIONS RANGE LOCATION: The location for the range must meet the following criteria. If any of these criteria are not met, select another location. CABINET PREPARATION: The range is a free standing appliance. If the range is to be adjacent to cabinets, the clearances shown below are required. This range may not be recessed into the cabinets.
Page 11 Installation Manual Residential Dual Fuel Ranges GENERAL INSTRUCTIONS • Do not remove protective packaging until you are ready to perform the installation. • Do not remove the protective wrapping from the product control panel until the product is installed. • Use proper equipment to move products. •...
Page 12: Clearance Dimensions
Installation Manual Residential Dual Fuel Ranges CLEARANCE DIMENSIONS N - C 2 4 " M I N 1 3 " 3 0 " I B L B I N M I N T I B I A L R I A 1 8 "...
Page 13 Installation Manual Residential Dual Fuel Ranges CLEARANCE DIMENSIONS 6 6 " m i n 7 2 " 3 0 " 3 0 " m i n 6 " 3 6 " 6 6 " m i n 7 2 " 2 4 "...
Page 14: Installation Steps
Installation Manual Residential Dual Fuel Ranges INSTALLATION STEPS STEP 1 Open door completely. Place pins, supplied with unit in pin hole. For personal safety, only use the pins supplied with the unit. STEP 2 Remove hinge trim screws, take off hinge trim, identify right and left hinge for future re-installation.
Page 15 Installation Manual Residential Dual Fuel Ranges INSTALLATION STEPS STEP 3 Close until pins stop door. STEP 4 Hold the door with both hands just below the handle and pull it away form the oven while continuing to lift. 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
Page 16 Installation Manual Residential Dual Fuel Ranges INSTALLATION STEPS STEP 5 Remove racks. STEP 6 Measure the four corners in cutout area to verify that flooring is level. 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
Page 17 Installation Manual Residential Dual Fuel Ranges INSTALLATION STEPS STEP 7 For uneven or sloped floors, level unit with metal shims only, as the adjustment required may exceed the thread available in the leg. STEP 8 Move unit into opening. 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
Page 18 Installation Manual Residential Dual Fuel Ranges INSTALLATION STEPS STEP 9 Check that unit is level side to side and front to back. Side trim of the high corner must be 3/8” above the countertop. 3/8" (1cm) STEP 10 Pull oven straight out. Install Anti-Tip Device according to installation instructions found inside the Anti-Tip Device kit.
Page 19 Installation Manual Residential Dual Fuel Ranges INSTALLATION STEPS STEP 11 Connect gas and electrical supplies before placing appliance in operation, always check for gas leaks. This must be performed by your dealer, a qualified licensed plumber or gas service company. A.
Page 20 Installation Manual Residential Dual Fuel Ranges INSTALLATION STEPS STEP 12 Replace door. STEP 13 Open door completely. Put hinge trim plates back on. Secure the screw. 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
Page 21 Installation Manual Residential Dual Fuel Ranges INSTALLATION STEPS STEP 14 Remove pins and close door. STEP 15 Insert racks back into oven. 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
Page 22 Installation Manual Residential Dual Fuel Ranges INSTALLATION STEPS STEP 16 Burner caps are packed in a separate box with the grates. Place burner and caps on top of range. Place burner grate on top of burner cap and grate support. BURNER BASE 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com...
Page 23: Performance Checklist
Installation Manual Residential Dual Fuel Ranges PERFORMANCE CHECKLIST A qualified installer should carry out the following checks: Refer to User Manual to perform the following check points. 0 Check operation of Bake at 350º. 0 Check operation of Convection Bake. 0 Check operation of Broil function.
Page 24 Failure to comply will void any written or implied warranty. Should the equipment require service during the standard warranty period, the receipt proving certified installation must be made available to American Range for verification. If installation was not performed by a certified/licensed contractor be prepared to submit a major credit card for payment for proper installation prior to service.
