Summary of Contents for RF Power HVLA1K3 PLUS
- Page 1 MANUALE INGLESE AMPLIFICATORE HVLA700AI REV.4 PLUS HVLA1K3 USERS MANUAL 1300 WATTS 1.8 - 54 MHz AUTOMATIC SOLID STATE LINEAR AMPLIFIER...
- Page 2 This compact and lightweight amplifier employ the new generation of NXP™ extremely rugged 50V RF power LDMOS MOSFETs. The built-in decoder, which allow you to forget about the band setting, and the electronic solutions adopted, give this amplifier the most complete and very easy to operate in the market.
- Page 3 PLUS HVLA1K3 USERS MANUAL Don’t turn ON the amplifier before connected the ANTENNA; a hazardous RF voltage may be present on the antenna connector with no antenna connected. Don’t disconnect an antenna during transmission; fire or electric shock may be possible. Don’t expose the amplifier to rain, snow or any other liquids;...
- Page 4 PLUS HVLA1K3 USERS MANUAL Don’t obstruct the entries for cooling present in the cover of the amplifier; the poor heat dissipation generated, in this situation, may damage the amplifier. Don’t place the amplifier near walls or other obstacles; the poor heat dissipation generated, in this situation, may damage the amplifier.
-
Page 5: Front Panel Description
PLUS HVLA1K3 USERS MANUAL FRONT PANEL DESCRIPTION BAND This 9 position rotary switch select the manual (green LEDs “AUTO A” and “AUTO B” unlit) or auto desired operating frequency band. AUTO A Green LED lights when operating frequency band is automatically controlled by KENWOOD™ transceiver;... - Page 6 PLUS HVLA1K3 USERS MANUAL HIGH Green LED lights when high RF output power level has been chosen; if not, the amplifier is in standby mode. ANTENNA This 2 position rotary switch select a primary antenna (ANT A) or a second antenna /dummy load (ANT B).
-
Page 7: Rear Panel Description
PLUS HVLA1K3 USERS MANUAL REAR PANEL DESCRIPTION AUTO B D-SUB (9 pin) male connector for control cable from ICOM™ - YAESU™- ELECRAFT™ transceiver. RELAY (Opto-Isolated input) RCA female connector for control cable from KENWOOD™ transceiver (or other brand). The center pin is to be shorted to ground through the relay circuit of the transceiver;... -
Page 8: Preliminary Precautions
PLUS HVLA1K3 USERS MANUAL PRELIMINARY PRECAUTIONS Before you start to install the amplifier, fully read this manual. Carefully remove the amplifier from its boxes and packaging materials and inspect for physical damage incurred during shipping. If any damage is found contact immediately your supplier. Keep the original boxes and packaging materials;... - Page 9 PLUS HVLA1K3 USERS MANUAL CONNECTION AND OPERATION with KENWOOD™ transceiver 6.1 Connect AC power cord and coax cables as mentioned on page 9. Run a shielded cable from the transceiver “REMOTE” connector to the amplifier rear panel “RELAY” phono (RCA) female connector.
- Page 10 PLUS HVLA1K3 USERS MANUAL 6.10 IMPORTANT NOTES: For high duty cycle transmissions like RTTY, it is advised that you use the intermediate output power position (green LED “LOW” lit up). Due to the relatively low switching time of the TX-RX relays, we don’t guarantee the use of the transmission high-speed CW Full Break-in mode for speed more than 25-30 wpm.
- Page 11 PLUS HVLA1K3 USERS MANUAL CONNECTION AND OPERATION with ICOM™ transceiver This section explains a one-antenna connected to an ICOM™ transceiver provided of “Band Voltage Output” pin. 7.1 Connect AC power cord and coax cables as mentioned on page 9. Run a shielded control cable (see page nr.13) from the remote terminals (transceiver producers give different names to this output;...
- Page 12 PLUS HVLA1K3 USERS MANUAL Use of the amplifier with an incorrect band filter selected, or without a well- adjusted antenna, may damage the amplifier. ICOM™ TRANSCEIVER CONTROL CABLE SCHEMATIC DIAGRAM This section explains the electrical connections to control the amplifier with an ICOM™ transceiver provided of “Band Voltage Output”...
- Page 13 PLUS HVLA1K3 USERS MANUAL CONNECTION AND OPERATION with YAESU™ transceiver This section explains a one-antenna connected to a YAESU™ transceiver provided of “Band Data” output pins. 9.1 Connect AC power cord and coax cables as mentioned on page 9. Run a shielded control cable (see page nr.15) from the remote terminals (transceiver producers give different names to this output;...
- Page 14 PLUS HVLA1K3 USERS MANUAL Use of the amplifier with an incorrect band filter selected, or without a well- adjusted antenna, may damage the amplifier. 10 YAESU™ TRANSCEIVER CONTROL CABLE SCHEMATIC DIAGRAM This section explains the electrical connections to control the amplifier with a YAESU™ transceiver provided of “Band Data”...
- Page 15 PLUS HVLA1K3 USERS MANUAL 11 CONNECTION AND OPERATION with K3 ELECRAFT™ transceiver This section explains a one-antenna connected to a K3 ELECRAFT™ transceiver provided of D-SUBHD (15 pin) “ACC” connector. 11.1 Connect AC power cord and coax cables as mentioned on page 9. Run a shielded control cable (see page nr.17) from K3 “ACC”...
- Page 16 PLUS HVLA1K3 USERS MANUAL Use of the amplifier with an incorrect band filter selected, or without a well- adjusted antenna, may damage the amplifier. 12 K3 ELECRAFT™ TRANSCEIVER CONTROL CABLE SCHEMATIC DIAGRAM This section explains the electrical connections to control the amplifier with a K3 ELECRAFT™ transceiver provided of D-SUBHD (15 pin) “ACC”...
-
Page 17: Protection Circuits
PLUS HVLA1K3 USERS MANUAL 13 PROTECTION CIRCUITS There are many protection functions in this amplifier. If the amplifier has shut-down for some reasons, before re-setting, correct the possible cause of the shut-down. Turn OFF the main AC power switch once and back ON to reset. If the amplifier is operated in such a manner that multiple protections work repeatedly over a long period of time, the amplifier can be seriously damaged. - Page 18 PLUS HVLA1K3 USERS MANUAL 13.5 Power Supply Unit (PSU) protections The internal switching power supply unit features the following automatic protections: - Soft start - Short circuit - Over current - Over voltage - Over temperature A built-in green LED check its normal activity. If the green LED is OFF means that the PSU is in an auto-protect condition, or AC mains power supply fuses are blown.
-
Page 19: Troubleshooting
PLUS HVLA1K3 USERS MANUAL 14 TROUBLE SHOOTING The following table analyzes some common faults and their correction: Fault Possible Cause Solution AC mains not a)AC fuses blown a)Replace with new ones. operating b)AC cord not plugged b)Plug in securely. Can’t enter a)Control cable not a)Check the control cable and connect properly.
