Summary of Contents for Philips DVP522
- Page 1 DVD VIDEO PLAYER 8239 300 32141 01-30 DVP522_69 24/02/2004, 2:10 PM...
-
Page 2: General Information
Due to the numerous versions of new CD-Audio copy protection or enhanced CD-Audio protection recently available on certain discs, Philips is unable to guarantee that this DVD Player is fully compatible with such new discs. Should you have difficulty playing any such CD-Audio discs, kindly refer them to your CD- Audio disc retailer. - Page 3 This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.
-
Page 4: Table Of Contents
Contents Introduction Supplied accessories ... 5 Care and safety information ... 5 Connections Connecting TV ... 6-7 Using Component Video jacks (Y Pb Pr) .. Using Composite Video jack (CVBS) ... Using S-Video jack ... Using an accessory RF modulator ... Connecting the power cord ... -
Page 5: Introduction
Leave the player in the warm environment until the moisture evaporates. Do not block the vents – Do not operate the DVD Player in an enclosed cabinet, allow about 10 cm (4 inches) of free space all around the player for adequate ventilation. -
Page 6: Connections
Component video input jacks (or labeled as Y Pb Pr or YUV) on the TV (cable not supplied). To hear the sound of this DVD Player through your TV, use the audio cables (white/red) to connect AUDIO OUT (L/ R) jacks of the DVD Player to the corresponding AUDIO IN jacks on the TV (cable supplied). -
Page 7: Using S-Video Jack
RF In,) you will need an RF modulator in order to view the DVD playback on the TV. See your electronics retailer or contact Philips for details on RF modulator availability and operations. Using an accessory RF modulator Use the composite video cable (yellow) to connect the DVD Player’s CVBS (VIDEO... -
Page 8: Connecting The Power Cord
AC power cord to the power outlet. Never make or change any connections with the power switched on. When no disc is loaded, press STANDBY ON on the DVD Player front panel, “NO DISC” may appear on the display panel. NO DISC... -
Page 9: Optional: Connecting Digital Av Receiver
Connect the COAXIAL jack of the DVD Player to the corresponding Digital Audio In jack on your Receiver (cable not supplied). Set the DVD Player’s Digital Output to PCM-ONLY or ALL depending on the capabilities of your Receiver (see page 21 “Digital Output”). -
Page 10: Functional Overview
Functional Overview Front and Rear Panels STANDBY-ON B – To switch the DVD Player to Standby mode or ON Disc tray OPEN/CLOSE / – Open/Close the disc tray STANDBY-ON Mains (AC Power Cord) – Connect to a standard AC outlet S-Video Out –... -
Page 11: Remote Control
MUTE – Disables or enables sound output 01-30 DVP522_69 Functional Overview POWER B – To switch the DVD player to standby mode or ON 0-9 numerical key pad – Selects numbered items in a menu DISPLAY – Displays information on TV... -
Page 12: Getting Started
6-7 “Connecting TV”). Turn on the TV and set to the correct video-in channel. You should see the blue Philips DVD background screen on the Usually these channels are between the lowest and highest channels and may be called FRONT, A/V IN, or VIDEO. See your TV manual for more details. -
Page 13: Selecting The Colour System That Corresponds To Your Tv
This DVD Player is compatible with both NTSC and PAL. In order for a DVD disc to play on this Player, the colour system of the Disc, the TV and the DVD Player should match. - - Video Setup Page - -... -
Page 14: Step 3: Setting Language Preference
Getting Started Step 3: Setting language preference You can select your own preferred language settings.This DVD system will automatically switch to the selected language whenever you load a disc. If the language selected is not available on the disc, the disc’s default language will be used instead. -
Page 15: Disc Operations
“Setting up the TV”). Press STANDBY-ON on the DVD Player front panel. You should see the blue Philips DVD background screen on the TV. Press OPEN•CLOSE 0 button to open the disc tray and load in a disc, then press the same button again to close the disc tray. -
Page 16: Using The Disc Menu
Disc Operations Using the Disc Menu Depending on the disc, a menu may appear on the TV screen once you load the disc. To select a playback feature or item Use the 1 2 3 4 or numeric keypad (0-9) on the Remote Control, then press PLAY B to start playback. -
Page 17: Repeat
Repeat (DVD/SVCD/VCD/CD) Press REPEAT continuously to choose a Repeat mode during playback. REPEAT CHAPTER (DVD) – to repeat playback of the current chapter. REPEAT TRACK/TITLE (CD/SVCD/VCD/ DVD) – to repeat playback of the current track (CD/SVCD/VCD)/title (DVD). REPEAT ALL – to repeat playback of all the disc and all the programmed tracks. -
Page 18: Special Disc Features
Disc Operations Special disc features Playing a Title (DVD) Press DISC MENU. The disc title menu appears on the TV screen. Use 341 2 keys or numeric keypad (0-9) to select a play option. Press OK key to confirm. Camera Angle (DVD) Press ANGLE repeatedly to select different desired angle. -
Page 19: Playback Selection
Playback selection During playback, you can; S / T Press to select another file in the current folder. on the remote to rotate/flip 1 2 3 4 the picture files. Press repeatedly to pause/resume playback. Repeat (MP3/JPEG) Press REPEAT continuously to access different ‘Play Mode’. -
Page 20: System Menu Options
Press OK to start playback. Helpful Hint: – Program can be activated only when a disc is in the DVD player. Screen Saver This function is used to turn the screen saver on or off. - - General Setup Page - -... -
Page 21: Audio Setup Page
If DIGITAL OUTPUT is set to ‘All’, all audio settings except MUTE are invalid. LPCM Output If you connect the DVD Player to a PCM compatible receiver via the digital terminals, such as coaxial or optical etc, you may need to adjust ‘LPCM Output’. -
Page 22: Dolby Digital Setup
The levels for dynamic selection: Full, 3/4, 1/2, 1/4 and Off. Helpful Hint: – DTS surround audio output are not available in this DVD player. 01-30 DVP522_69 Equalizer The option included in Equalizer is: ‘Sound Mode’. Press 34 to highlight ‘Sound Mode’. -
Page 23: 3D Processing
Go To Video Setup Page 01-30 DVP522_69 System Menu Options TV Display Set the aspect ratio of the DVD Player according to the TV you have connected. Press 34 to highlight ‘TV Display’. Enter its submenu by pressing 2. Move the cursor by pressing 34 to highlight the selected item. -
Page 24: Closed Captions
System menu Options Closed Captions Closed captions are data that are hidden in the video signal of some discs. Captions are different from subtitles because captions hearing are impaired by showing the sound effects (e.g., “phone ringing” and “footsteps”), while subtitles do not. Before you select this function, please ensure that the disc contains closed captions information and your TV set also... -
Page 25: Picture Setting
Picture Setting The options included in Picture Setting Setup page are: ‘Sharpness’, ‘Brightness’ and ‘Contrast’. Press the 34 keys to highlight an option. Enter its submenu by pressing 2. Move the cursor by pressing the 34 keys to highlight the selected item. - - Picture Setting Setup - - Sharpness High... -
Page 26: Password
System Menu Options Parental - cont’d Helpful Hint: – Some DVDs are not encoded with a rating though the movie rating may be printed on the Disc cover. The rating level feature does not work for such Discs. Rating explanations 1 KID SAFE –... -
Page 27: Specifications
TV STANDARD (PAL/50Hz) (NTSC/60Hz) Number of lines Playback Multistandard (PAL/NTSC) VIDEO PERFORMANCE DA Converter 12 bit, 54mHz Component video Y: 1 Vpp into 75 ohm output (480i/p) PbPr: 0.7 Vpp into 75 ohm Video Output 1Vpp — 75 ohm S-Video Output Y: 1Vpp —... -
Page 28: Troubleshooting
– Connect DVD Player directly to the TV. – Make sure the disc is compatible with the DVD Player. – Ensure that the DVD Player’s TV Type is set to match that of the Disc and your TV. – Adjust the volume. - Page 29 – Operations may not be permitted by the disc. Refer to the instructions of the disc jacket. – Use a commonly available cleaning CD/DVD to clean the lens before sending the DVD Player for repair. – Press STOP twice before selecting System Menu.
-
Page 30: Glossary
Glossary Analog: Sound that has not been turned into numbers. Analog sound varies, while digital sound has specific numerical values. These jacks send audio through two channels, the left and right. Aspect ratio: The ratio of vertical and horizontal sizes of a displayed image. The horizontal vs. -
Page 31: Language Code
Language Code Abkhazian 6566 Afar 6565 Afrikaans 6570 Amharic 6577 Arabic 6582 Armenian 7289 Assamese 6583 Avestan 6569 Aymara 6589 Azerhaijani 6590 Bahasa Melayu 7783 Bashkir 6665 Belarusian 6669 Bengali 6678 Bihari 6672 Bislama 6673 Bokmål, Norwegian 7866 Bosanski 6683 Brezhoneg 6682 Bulgarian... -
Page 32: Class 1 Laser Product
Phone: (033)-747333 PO Box 12163 50768 Kuala Lumpur, MALAYSIA Customer Relation Centre Phone: (03)-7562144 3, Haddows Road Madras 600 006 Philips Elect. Ind. of Pakistan INDIA F-54, S.I.T.E. PO Box 7101 Phone: (044)-8292221 75730 Karachi PAKISTAN Customer Relation Centre Phone: (021)-2560071-82...
