Maevex 5150 decoder (Back)
Description of supported connections
Connector
5V DC power
HDMI
5V DC
power
Description
Connect the 5V DC power supply included with
your product to this connector. While the 5V DC
power supply is connected to the device and
electrical socket, the power LED (
(not black).
For more information on LEDs,
5150 encoder and 5150 decoder", page
Connect a digital monitor to this connector. If
your digital monitor has a DVI connector, you
need an HDMI to DVI-D adapter to connect
your monitor to this connector.
Note:
To connect to this connector, you need a
shielded HDMI cable.
LAN1/LAN2
(network or
decoder)
see "Maevex
Matrox Maevex Series – User Guide 19
Line Out
HDMI
(monitor)
Required
encoder
connection
) is active
24.
