Appendix C – Mounting your Maevex
5100 Series device
Maevex 5150 Encoder and 5150 Decoder – This section provides guidelines for mounting your
Maevex devices in rack mounts or on VESA mounts using one or multiple mounting kits available
from Matrox: the rack mounting kit and the angled bracket kit.

Mounting guidelines

To prevent damage to your Matrox hardware, read the following guidelines before mounting your
Matrox hardware:
Mounting shelf only – To install your mounting shelf, fasten it to the rack as per your
rack's instructions. Head screws compatible with most rack mounts are provided.
Mounting shelf only – The mounting shelf has existing holes for your Maevex device that
allow the shelf to be mouzwnted facing forward or backward.
Use a hand screwdriver to carefully tighten each screw. Make sure not to overtighten the
screws.
Don't stack anything directly over the device.
Make sure the cables connected to your device are properly secured and that no tension
is applied to them.
Make sure the ambient temperature doesn't exceed the maximum recommended
temperatures. For more information,
Once your Maevex device is mounted, you can connect your system, monitors, and devices to your
device.

Mounting your Maevex 5150 encoder or 5150 decoder

Using the mounting shelf kit in a rack mount, you can mount two (2) Maevex encoders or three (3)
decoders horizontally on a single shelf.
see "Product information", page
Matrox Maevex Series – User Guide 41
31.
