Summary of Contents for Boston Whaler 285 Conquest

  • Page 14 MODIFICATIONS & SEVERABILITY e terms and conditions contained herein, as well as those of any documents prepared in conjunction with the sale of this vessel may not be modi ed, altered or waived by any action, inaction, or representations, whether oral or in...
  • Page 15 Boston Whaler. invalidity or unenforceability of any one or more of the provisions herein shall not a ect the validity and enforceability of the other provisions. WARRANTIES UNDER AUSTRALIAN CONSUMER LAW Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
  • Page 28 1-10...
  • Page 29 1-11...
  • Page 30 1-12...
  • Page 31 1-13...
  • Page 32 STOP TURN TURN RIGHT TURN LEFT GO FASTER GO SLOWER SPEED OK OK AFTER FALL SKIER IN WATER CUT MOTOR BACK TO DOCK 1-14...
  • Page 33 1-15...
  • Page 34 1-16...
  • Page 35 1-17...
  • Page 36 1-18...
  • Page 37 WARNING Avoid serious injury or death from fire or explosion resulting from leaking fuel. DANGER Inspect system for leaks at least once a year. Contents can be under pressure. Open slowly in well ventilated area. No smoking or open flames. STAY CLEAR OF MOVING PARTS.
  • Page 38 The joystick is for boat docking and low speed maneuvers. Use the joystick only when the ERC controls are in neutral. When the ERC controls are shifted into gear, the joystick disengages. To limit engine power during docking and maneuvering, engage the dock feature by pressing the DOCK button.
  • Page 39 THIS BOAT HAS BEEN DESIGNED FOR A MAXIMUM MRP# 1743548 CERTIFIED COMPONENTS OUTBOARD ENGINE WEIGHT OF BOSTON WHALER, EDGEWATER, FL 1400 Lb / 635 kg WARNING Carbon monoxide (CO) can cause brain damage or death. Carbon monoxide can be present in the cabin Signs of carbon monoxide poisoning include nausea, headache, dizziness, drowsiness, and lack of conciousness.
  • Page 40 NOTICE THIS BOAT IS EQUIPPED WITH AN OPTIONAL DIRECT OVERBOARD DISCHARGE VALVE. DISCHARGING OF SEWAGE DIRECTLY OVERBOARD IS FOR USE WHERE APPROVED ONLY MRP# 1745156 NOTICE Fixed fire extinguisher system must be suitable for gross compartment volume of 75 cu ft. MRP# 2029137 WARNING NO VENTILATION IS PROVIDED.
  • Page 41 STOP 1-23...
  • Page 42 1-24...
  • Page 44 LES PETITS BÂTIMENTS, EN VIGUEUR À LA DATE DU DÉBUT DE SA CONSTRUCTION OU À LA DATE DE SON IMPORTATION. BOSTON WHALER, INC. 285 Conquest 1800 AUSTRALIAN BUILDERS PLATE MANUFACTURER: BOSTON WHALER, INC. - USA MODEL: 285 CONQUEST INFORMATION DETERMINED: ISO STANDARDS MAX OUTBOARD: 372 kw; 635 kg...
  • Page 46 Speci cations & Dimensions...
  • Page 51 AUTO COOL HEAT AUTO DEHUMIDIFY MODE...
  • Page 52 2-10...
  • Page 53 2-11...
  • Page 54 2-12...
  • Page 55 2-13...
  • Page 56 2-14...
  • Page 57 2-15...
  • Page 58 2-16...
  • Page 59 STBD NAV/ANC SPREADER WINDSHIELD PORT HORN CTSY WIPER LIGHTS LIGHTS VENT WIPER LIGHTS WINDLASS WINDLASS FWD BILGE AFT BILGE ACC 3 ACC 1 ACC 2 ON/OFF UP/DOWN PUMP PUMP 2-17...
  • Page 60 STBY AUTO MENU PAGES Vessel View7 2-18...
  • Page 61 2-19...
  • Page 62 NAV/ANC SPREADER WINDSHIELD PORT STBD HORN CTSY WIPER WIPER LIGHTS LIGHTS LIGHTS VENT WINDLASS WINDLASS FWD BILGE AFT BILGE ACC 1 ACC 2 ACC 3 ON/OFF UP/DOWN PUMP PUMP 2-20...
  • Page 63 2-21...
  • Page 64 2-22...
  • Page 65 LENCO 2-23...
  • Page 66 NAV/ANC SPREADER WINDSHIELD PORT STBD HORN CTSY LIGHTS LIGHTS VENT WIPER WIPER LIGHTS WINDLASS WINDLASS FWD BILGE AFT BILGE ACC 1 ACC 2 ACC 3 ON/OFF UP/DOWN PUMP PUMP 2-24...
  • Page 67 2-25...
  • Page 68 2-26...
  • Page 69 2-27...
  • Page 70 2-28...
  • Page 71 2-29...
  • Page 72 2-30...
  • Page 73 2-31...
  • Page 74 2-32...
  • Page 75 2-33...
  • Page 76 2-34...
  • Page 81 REFER TO THE ENGINE MANUFAC TURER’S MANUAL IN YOUR OWNER’S MANUAL PACKET FOR COMPLETE INSTRUCTIONS AND WARRANTY.
  • Page 86 3-10...
  • Page 87 3-11...
  • Page 88 3-12...
  • Page 89 3-13...
  • Page 90 PORT STBD LIVEWELL LIVEWELL WATER FISHBOX FISHBOX PUMP LIGHT PORT STBD LIVEWELL LIVEWELL WATER FISHBOX FISHBOX PUMP LIGHT STBD PORT HORN NAV/ANC CTSY SPRDR H-TOP LIGHTS LIGHTS LIGHTS LIGHT UNSW MAIN HELM CABIN WINDLS TRIM WINDLSS WINDSHIELD PORT STBD SHOWER BILGE SUMP TABS...
  • Page 91 e AC/DC refrigerator is located on the front of the prep station. If equipped the refrigerator is powered by shore power, if connected or generator (option). The “ ” breaker on the 120V AC breaker panel on the MDP panel located in the port cabin (See g.
  • Page 92 3-16...
  • Page 93 3-17...
  • Page 94 AUTO COOL HEAT AUTO DEHUMIDIFY MODE 3-18...
  • Page 95 120V / 60HZ 12VDC REVERSED POLARITY POWER VOLTMETER VOLTMETER HIGH WATER WARNING GASOLINE VAPORS CAN EXPLODE KOHLER BEFORE STARTING START GENERATOR -CHECK BILGE FOR MODE GASOLINE VAPORS -RUN BLOWER STOP FOR 4 MINUTES SHORE GENERATOR MONITOR -NOTE: RUN BLOWER BELOW CRUISE SPEED STEREO BATTERY...
  • Page 96 REVERSED POLARITY POWER SHORE GENERATOR KOHLER START MODE STOP WARNING GASOLINE VAPORS CAN EXPLODE BEFORE STARTING KOHLER GENERATOR -CHECK BILGE FOR START GASOLINE VAPORS -RUN BLOWER MODE FOR 4 MINUTES -NOTE: RUN BLOWER BELOW CRUISE STOP SPEED STEREO TV/DVD STEREO BLOWER ACC.
  • Page 97 3-21...
  • Page 98 3-22...
  • Page 99 e AC/DC refrigerator/freezer is located on the front of the galley. e refrigerator/freezer is powered by shore power, if connected or generator (option). e “ ” breaker on the 120V AC breaker panel on the MDP panel located in the cabin (See g. 4.9.1) must be ON for the refrigerator/freezer to function.
  • Page 100 3-24...
  • Page 101 3-25...
  • Page 102 DISP MENU ZOOM SUB-T SETUP 3-26...
  • Page 103 3-27...
  • Page 104 CAUTION AVOID PROPERTY DAMAGE ENGAGE GYPSY LOCK AND ENSURE ANCHOR IS SECURED WITH LANYARD BEFORE GETTING UNDERWAY. MRP# 3-28...
  • Page 105 NAV/ANC SPREADER WINDSHIELD PORT STBD HORN CTSY WIPER WIPER LIGHTS LIGHTS LIGHTS VENT WINDLASS WINDLASS FWD BILGE AFT BILGE ACC 3 ACC 1 ACC 2 ON/OFF UP/DOWN PUMP PUMP 3-29...
  • Page 106 3-30...
  • Page 107 3-31...
  • Page 108 THRUSTER THRUSTER 3-32...
  • Page 109 THRUSTER THRUSTER REFER TO THE BOW THRUSTER MANUFAC TURER’S MANUAL IN YOUR OWNER’S PACKET FOR COMPLETE INSTRUCTIONS AND WARRANTY. 3-33...
  • Page 110 3-34...
  • Page 113 PORT STBD LIVEWELL LIVEWELL WATER FISHBOX FISHBOX PUMP LIGHT PORT STBD LIVEWELL LIVEWELL WATER FISHBOX FISHBOX PUMP LIGHT STBD PORT HORN NAV/ANC CTSY SPRDR H-TOP LIGHTS LIGHTS LIGHTS LIGHT UNSW MAIN HELM CABIN WINDLS TRIM WINDLSS WINDSHIELD PORT STBD SHOWER TABS CONTROL VENT...
  • Page 118 R E F E R TO T H E D O W N R I G G E R M A N U FAC T U R E R ’S M A N U A L F O R C O M P L E T E I N S T R U C T I O N S A N D WARRANTY.
  • Page 119 12VDC 120V / 60HZ REVERSED POLARITY POWER VOLTMETER VOLTMETER HIGH WATER WARNING GASOLINE VAPORS CAN EXPLODE KOHLER BEFORE STARTING START GENERATOR -CHECK BILGE FOR MODE GASOLINE VAPORS -RUN BLOWER STOP FOR 4 MINUTES SHORE GENERATOR MONITOR -NOTE: RUN BLOWER BELOW CRUISE SPEED STEREO BATTERY...
  • Page 120 12VDC 220V / 60HZ REVERSED POLARITY POWER VOLTMETER VOLTMETER HIGH WATER WARNING GASOLINE VAPORS CAN EXPLODE KOHLER BEFORE STARTING START GENERATOR -CHECK BILGE FOR MODE GASOLINE VAPORS -RUN BLOWER STOP FOR 4 MINUTES SHORE GENERATOR MONITOR -NOTE: RUN BLOWER BELOW CRUISE SPEED STEREO BATTERY...
  • Page 121 TRANSDUCER LOCATION 4-11...
  • Page 122 4-12...
  • Page 123 4-13...
  • Page 124 HELM SWITCH PANEL HORN 211-14 RD 212-14 OR/BU NAV/ANC LIGHTS 207-16 GY/WH 203-16 GY 207A-16 GY/WH 209-16 BU 202-14 RD CTSY LTS 627-16 BU/RD 601-16 BU/RD 600-14 RD SPREADER LTS 630-14 RD 631-14 BU/RD W/S VENT 212-14 OR/BU 575-16 BK 207-16 GY/WH 576-16 RD PLUG...
  • Page 125 4-15...
  • Page 126 4-16...
  • Page 127 4-17...
  • Page 128 4-18...
  • Page 129 4-19...
  • Page 130 4-20...
  • Page 131 4-21...
  • Page 132 4-22...
  • Page 133 4-23...
  • Page 134 Connect to source unit's rear RCA outputs Connect to source unit's rear RCA outputs Connect to source unit's front RCA outputs Connect to source unit's front RCA outputs Connect to source unit's remote turn-on lead (Blue/White) Connect to source unit's remote turn-on lead (Blue/White) Connect to negative terminal of 12VDC battery or distribution block Connect to negative terminal of 12VDC battery or distribution block Connect to positive terminal of 12VDC battery or distribution block...
  • Page 135 4-25...
  • Page 136 4-26...
  • Page 137 4-27...
  • Page 138 4-28...
  • Page 148 5-10...
  • Page 149 5-11...
  • Page 150 PLY 2x4 P&S PLY 2x4 P&S PLY 2x4 P&S PHEN 4x18 PLY 2 PHEN 2 PHEN 2 PHEN 2 PLY 2 PHEN 7x7 PLY 2 PLY 9x10 PHEN 2 PHEN 2 PLY 2 PLY 3 PHEN 2 PHEN 2x10 PLY 7x12 P&S PLY 11x12 P&S...
  • Page 151 5-13...
  • Page 152 5-14...
