- Page 1 Technical Manual DS-9000HFI-RH Embedded Hybrid DVR Technical Manual ©2006 – 2011 by HIKVISION. All rights reserved.
- Page 2 HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or subject...
- Page 3 Technical Manual Overview The Hikvision DS-9000HFI-RH series Hybrid DVR is a new generation of video surveillance product with powerful functionalities in video encoding and decoding, video data storage, intelligent video analytics and network management. The product supports RAID disk array and virtual disk configuration to enhance data reliability and storage capability, as video data can be divided and replicated among 8 hard disk drives.
-
Page 4: Order Models
Technical Manual Order Models DS-9004HFI-RH, DS-9008HFI-RH, DS-9016HFI-RH Note: 1. The default DVRs are without HDD or CD-R/W. 2. A factory recommended HDD should be used for this device. ©2006 – 2011 by HIKVISION. All rights reserved. -
Page 5: Main Features
Smart searching for the motion event when playing back; Disk array and virtual disk configurable; Manual disk array rebuilding; Hot swap/spare rebuilding; RAID level migration; Online storage capacity expansion. Network detection. ©2006 – 2011 by HIKVISION. All rights reserved. - Page 6 Support redundant recording; Available with 8 SATA interfaces; Support eSATA disk (optional); Network monitoring for traffic, packet capturing and connection; NTP, SADP, SMTP, NFS and iSCSI protocols support. ©2006 – 2011 by HIKVISION. All rights reserved.
-
Page 7: Front Panel
② Power Button ③ IR receiver ④ DVD-ROM ⑤ DIRECTION/ENTER Buttons ⑥ Front Panel Lock ⑦ USB Ports ⑧ Control Buttons ⑨ Alphanumeric Buttons ⑩ JOG SHUTTLE Control ⑪ Left and Right Button ©2006 – 2011 by HIKVISION. All rights reserved. -
Page 8: Rear Panel
⑬ GND, when cascading multiple devices, it is required that grounding through GND first, and then connecting to the protection ground of control keyboard and power input. ⑭ 100~240VAC Power Input ⑮ HDMI interface ©2006 – 2011 by HIKVISION. All rights reserved. -
Page 9: Specifications
Interface 8 SATA interfaces Hard disk type Capacity Up to 2 TB capacity for each disk Array type RAID 0, RAID 1, RAID 5, RAID 10 Disk array Number of array ©2006 – 2011 by HIKVISION. All rights reserved. - Page 10 Others Working 10% ~ 90% humidity Chassis 19-inch rack-mounted 2U chassis Dimensions 445 × 470 ×90 mm (W × D × H) Weight ≤ 8 Kg (without hard disk or DVD-R/W) ©2006 – 2011 by HIKVISION. All rights reserved.
