6.3 Auto-Mode

In the Auto-Mode, you can call up the auto program as an endless loop.
Press the AUTO-button.
Select the desired speed via the SP and +/- buttons.
Select the desired Flash-Frequency via the F and +/- buttons.

6.4 Sound Control-Mode

The sound-control works via the built-in microphone.
Press the SOUND ACTIVE-button.

6.5 Blackout-Mode

Press the BLACKOUT-button and all devices will be set to Blackout-mode.
Please note: The Sound button does not work with devices without sound-control. The buttons DMX Mode,
Slave and Set Addr are not available for controllers.

8. CLEANING AND MAINTENANCE

We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.

9. TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
DMX-control-channels:
DMX-512-connection:
Sound-control:
Dimensions (WxDxH):
Weight:
Accessory:
EUROLITE IR remote for LED effects
Please note: Every information is subject to change without prior notice. 09.09.2014 ©
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
100-260 V AC, 50/60 Hz ~
via 9-12 V, 500 mA power supply unit
6 W
47
3-pin XLR
via built-in microphone
110 x 35 x 100 mm
0.3 kg
No.
51914130
15/15 00058530, Version 1.4
