Terminate the receiver as shown in the diagrams on pages 6-9 of this booklet. Step 3 Screw the receiver back plate securely into the back box. Step 4 Clip the front of the receiver back onto the receiver back plate. Wireless Receivers Model: RC1-WTS...
Page 4
Wiring Diagram - RC1-WTS LED Status Two Zone Heating System There are 4 LED lights on the receiver. Each LED is labeled and will light up or flash during setup and operation. To Boiler Please refer to your thermostats instructions for LED status information.
Page 5
Wiring Diagram - RC1-WTS Wiring Diagram - RC1-WTS 1 Heating Zone & 1 Hot Water Zone System Combination Boiler System To Boiler To Boiler Neutral Mains Supply In P/L = Permanent Live P/L and S/L connections Hot Water Valve S/L = Switched Live...
Page 6
Wiring Diagram - RC1-WTS Notes With Mid Position Valve ..................................Cylinder Mid Position Stat Valve ..................................Grey Hot Water OFF ..................................Hot Water ON Orange ..................................Heating ON White ....................................................................Mains Supply In ....................................................................NO1 NC1 ....................................................................
Page 7
Heating Professionals: Request a copy of our product installation guide containing detailed technical specifications for our complete product range: www.heatmiser.com/guide Want More Information? Call our support team on: +44 (0)1254 669090 Or view technical specifications directly on our website: www.heatmiser.com...
