- Page 1 EMM Tiny Module Operation manual Version 06.10.15 © TS-Market...
-
Page 2: Table Of Contents
Contents ..............3 EMM Tiny Module ..........5 Main Technical Characteristic ............. 7 Working with the Module ..............7 Preparing for Work ........8 Choosing the Recording Parameters ..............8 Default Settings ..............9 Voice Recording ............10 Playing the Recordings ............ -
Page 3: Emm Tiny Module
EMM Tiny Module The EMM Tiny Module is designed for professional voice record- ing on Flash media that can be downloaded into a PC. This mod- ule is the development of the Tesystems Company’s miniature digital voice recorders of the EM Tiny model. The module has... - Page 4 tervals stay the same. When recordings are uploaded onto a computer, pauses can be restored as silence or skipped depending on previous settings. • The LEDs that provide indications depending on modes of operation. • The switch that provides control of module’s work. In flash-disk mode, the module can be used for storing and trans- ferring any type of data.
-
Page 5: Main Technical Characteristic
Main Technical Characteristic Characteristic Meaning Signal-to-noise ratio -64 dB Recording format Mono Compression algorithm Without compression, u-Law, ADPCM 2 and 4-bits Sampling rate 5.5, 8, 11, 16 or 22 kHz Frequency band Up to 100… 10k Hz (depend- ing on settings) Input signal 2.9 Vpp with constant 1.5 V Consumption current... -
Page 6: Without Compression (Linear), Sampling Rate 5.5 Khz, 55 Kbits/Sec, K=3.4
Recording time depending on the modification (sampling rate 8 kHz, 2 bits ADPCM) Index Recording time Flash memory capacity 1120 1120 min (18.6 h) 128 Mbytes 2240 2240 min (37.3 h) 256 Mbytes 4480 4480 min (74.6 h) 512 Mbytes 8960 8960 min (149.3 h) 1 Gbytes... -
Page 7: Working With The Module
Modified 4-bit ADPCM, sampling rate 5.5 K Hz, 22 kbits/sec, k=1.4 Modified 2-bit ADPCM, sampling rate 22 kHz, 44 kbits/sec, k=2.8 Modified 2-bit ADPCM, sampling rate 16 kHz, 32 kbits/sec, k=2 Modified 2-bit ADPCM, sampling rate 11 kHz, 22 kbits/sec, k=1.4 Modified 2-bit ADPCM, sampling rate 8 kHz, 16 kbits/sec, k=1 Modified 2-bit ADPCM, sampling rate 5.5 kHz, 11 kbits/sec, k=0.7 k is a coefficient that shows how many times the maximum re-... -
Page 8: Choosing The Recording Parameters
There are labels on the module contacts in the description of module’s appearance in the manual’s appendix. The user can connect an external indicator (LED) and an exter- nal control, for instance, a switch. If the external control is con- nected to the module, the module built-in switch has to be in the STOP position. -
Page 9: Voice Recording
Voice Recording To turn on the recording, set the switch in the RECORD position (or connect the K and GND contacts). The module will flash five times and then blinks in several sequences while recording. To turn off the recording, set the switch into the STOP position (or disconnect the K and GND contacts). -
Page 10: Playing The Recordings
Playing the Recordings Download the recordings onto a PC using the RecManager pro- gram. Then play them using any audio program, for instance, Windows Media Player. Connecting to a PC The module has to be connected to a PC to play/save record- ings, set the module’s parameters, and make other operations. -
Page 11: To Renew Firmware
Our company’s support engineers constantly at work to improve our software and the documentation. You can always download a new version of our software and documentation for free from our website: http://ts-market.com . To Renew Firmware To renew the firmware of your module, go to the website http://ts- market.com . -
Page 12: Multilingual Support
After running the RecManager program, the new language will appear in the Language menu. If you like, you can send the cor- rected file to support@ts-market.com . The installation program that supports this new language will appear at http://ts-market. com. -
Page 13: Troubleshooting
Troubleshooting If you have some problems, there are some troubleshooting tips in the table below. Problem Cause Solution The indicator did not Power sup- Check the flash three times after ply is not connected connection to power power supply was The mod- source turned on and the... - Page 14 Problem Cause Solution Power voltage is off Check the connection module indicator to the power source does not does not record turn on Power voltage is low Check the power indicator source flashes 5 times in sequenc- There is not enough Free memory space indicator memory space for...
-
Page 15: Support
Support If you find any errors in our software or documentation, download the new one from http://ts-market.com. If the errors are not elimi- nated, connect to our technical support service: support@ts-mar- ket.com . We will eliminate the errors as soon as possible. Also...
