HIKVISION DS-7300HI Series Quick Operation Manual page 15

Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR
Stream type
Playback
resolution
Synchronous
playback
SATA
eSATA
Hard disk
Capacity
Network
interface
Serial interface
External
interface
USB interface
Alarm in
Alarm out
Power supply
Consumption
Working
temperature
Others
Working
humidity
Chassis
Dimensions
(W × D × H)
Weight
Video / Video & Audio
4CIF /2CIF /CIF /QCIF
4-ch
4 SATA interfaces
1 eSATA interface
Up to 4TB capacity for each disk
1 RJ45 10M / 100M adaptive Ethernet
1 RS-232 interface (for parameters configuration, maintenance, transparent
channel);
1 RS-485 interface (for PTZ control);
1 RS-485 keyboard interface (for special keyboard control)
3, USB 2.0
8
4
100 ~ 240 VAC, 5 A, 50~60 Hz
≤ 25 W (without hard
disk or DVD-R/W)
-10 ºC ~ + 55 ºC
10% ~ 90%
19-ich rack-mounted 1.5 U chassis
440 × 390 × 70 mm
≤ 8 Kg (without hard disk or DVD-R/W)
14
Channel 1-4:
Video/Video & Audio;
Channel 5-8: Video
8-ch
8
≤ 30 W (without hard
disk or DVD-R/W)
@ 25 fps (P) / 30 fps
(N)
Channel 1-4:
Video/Video & Audio;
Channel 5-16: Video
16-ch
16
≤ 35 W (without hard
disk or DVD-R/W)
