- Page 1 DS-7300HI/7300HFI/8100HDI-ST Series DVR Quick Operation Guide Version 2.0.1...
-
Page 2: Verify Contents
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. This manual is applicable to DS-7304HI-ST, DS-7308HI-ST, DS-7316HI-ST; DS-7304HFI-ST, DS-7308HFI-ST, DS-7316HFI-ST; DS-8104HDI-ST, DS-8108HDI-ST, DS-8116HDI-ST series DVR. Verify Contents Verify that the package contents are correct by checking the items against the packing list. - Page 3 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Connect one end of the data cable to the motherboard of DVR and the other end to the HDD. 4. Connect the power cable to the HDD. 5. Re-install the cover of the DVR and fasten screws.
- Page 4 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Steps (for DS-8100HDI-ST): 1. Remove the cover from the DVR by unfastening the screws on the back and side. 2. Install the HDD to the HDD rack using the provided screws, and then fasten the screws to fix the HDD. 3.
-
Page 5: Front Panel
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Front Panel DS-7300HI-ST& DS-7300HFI-ST: Name Function Description POWER ON/OFF Power on/off switch. IR Receiver Receiver for IR remote control. Connect to USB mouse or USB flash memory devices. DVD-ROM Slot for DVD-ROM. POWER Power indicator lights in green when DVR is powered up. - Page 6 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Enter letters “MNO”; In Playback mode, it is used for direct access to playback interface. Enter numeral “7”; Enter letters “PQRS”; 7PQRS/REC Manual record, for direct access to manual record interface; manually enable/disable record. Enter numeral “8”;...
- Page 7 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR DS-8100HDI-ST: Name Function Description POWER ON/OFF Power on/off switch. IR Receiver Receiver for IR remote control. Connect to USB mouse or USB flash memory devices. DVD-ROM Slot for DVD-ROM. ALARM Alarm indicator turns red when a sensor alarm is detected. READY Ready indicator is normally blue, indicating that the DVR is functioning properly.
- Page 8 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Return to the Main menu (after successful login); MENU/WIPER Turn off audible key beeper by pressing and holding the button for 5 seconds; Start wiper (if applicable) in PTZ Control mode. The F1/LIGHT button when used in a list field will select all items on the list. F1/LIGHT In PTZ Control mode, it will turn on/off PTZ light.
-
Page 9: Rear Panel
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Rear Panel DS-7304HI-ST & DS-7304HFI-ST: Note: The DS-7308HI-ST & DS-7308HFI-ST provide 8 BNC video input connectors on the rear panel. Item Description MAIN VIDEO OUT BNC connector for video output. 1. When both HDMI and VGA are connected, or either one is connected, it is used as the auxiliary video output for live view, playback, recording and PTZ controls;... - Page 10 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR DS-7316HI-ST & DS-7316HFI-ST: Item Description MAIN VIDEO OUT BNC connector for video output. 1. When both HDMI and VGA are connected, or either one is connected, it is used as the auxiliary video output for live view, playback, recording and PTZ controls;...
- Page 11 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR DS-8100HDI-ST: Note: The DS-8104HDI-ST provides 4 BNC video input connectors and 4 BNC audio input connectors. Item Description VIDEO IN BNC connector for analog video input. AUDIO IN BNC connector for audio input. VIDEO SPOT OUT BNC connector for spot video output.
-
Page 12: Connecting To Alarm Input / Output Device
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Connections Connecting to Alarm Input / Output Device The alarm input/output interface of the DVR is shown as below: The alarm input is an open/closed relay. If the input is not an open/closed relay, follow the connection diagram below: To connect to an AC/DC load, use the following diagram: For DC load, JP4 can be used within the limit of 12V/1A safely. -
Page 13: Alarm Connection
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Alarm Connection To connect alarm devices to the DVR: 1. Disconnect pluggable block from the ALARM IN /ALARM OUT terminal block. 2. Insert the signal cables into the screwless terminal block. 3. Connect pluggable block back into terminal block. RS-485 Connection To connect RS-485 devices to the DVR: Disconnect pluggable block from the RS-485 terminal block. -
Page 14: Specifications
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Specifications Table 1 Specifications of DS-7300HI-ST Model DS-7304HI-ST DS-7308HI-ST DS-7316HI-ST Video H.264 compression 4-ch, BNC (1.0 Vp-p, 8-ch, BNC (1.0 Vp-p, 16-ch, BNC (1.0 Vp-p, Analog video 75Ω), PAL/NTSC 75Ω), PAL/NTSC 75Ω), PAL/NTSC input adaptive adaptive... - Page 15 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR @ 25 fps (P) / 30 fps Channel 1-4: Channel 1-4: Stream type Video / Video & Audio Video/Video & Audio; Video/Video & Audio; Channel 5-8: Video Channel 5-16: Video Playback 4CIF /2CIF /CIF /QCIF resolution Synchronous 4-ch...
- Page 16 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Table 2 Specifications of DS-7300HFI-ST Model DS-7304HFI-ST DS-7308HFI-ST DS-7316HFI-ST Video compression H.264 4-ch, BNC (1.0 Vp-p, 8-ch, BNC (1.0 Vp-p, 16-ch, BNC (1.0 Vp-p, 75Ω), PAL/NTSC 75Ω), PAL/NTSC 75Ω), PAL/NTSC Analog video input Video/ adaptive adaptive...
- Page 17 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR USB interface 3, USB2.0 Alarm in Alarm out Power supply 100 ~ 240 VAC, 5 A, 50~60 Hz ≤ 30 W (without hard ≤ 35 W (without hard ≤ 40 W (without hard Consumption disk or DVD-R/W) disk or DVD-R/W)
- Page 18 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Table 3 Specifications of DS-8100HDI-ST Model DS-8104HDI-ST DS-8108HDI-ST DS-8116HDI-ST Video compression H.264 4-ch, BNC (1.0 Vp-p, 8-ch, BNC (1.0 Vp-p, 16-ch, BNC (1.0 Vp-p, 75Ω), PAL/NTSC 75Ω), PAL/NTSC 75Ω), PAL/NTSC Analog video input adaptive adaptive adaptive...
- Page 19 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR 12-ch: QCIF @ 25 fps (P) /30 fps (N) Stream type Video / Video & Audio Playback 4CIF / 2CIF / CIF / QCIF resolution Synchronous 4-ch 8-ch 16-ch playback SATA 4 SATA interfaces 8 SATA interfaces 8 SATA interfaces eSATA...
-
Page 20: Hdd Storage Calculation Chart
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K 160K 192K 224K... -
Page 21: Menu Operation
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Menu Operation Menu Structure The menu structure of the DS-7300HI/7300HFI/8100HDI-ST Series DVR is shown as below: Startup and Shutdown Proper startup and shutdown procedures are crucial to expanding the life of the DVR. To start your DVR: 1. -
Page 22: Using The Setup Wizard
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Using the Setup Wizard By default, the Setup Wizard will start once the DVR has loaded. Operating the Setup Wizard: 1. The Setup Wizard will walk you through some important settings of your DVR. If you don’t want to use the Setup Wizard at this time, click the Cancel button. - Page 23 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR 7. Click Next button after you configure the network parameters to enter the HDD Management window. 8. To initialize the HDD, click the Init button. Initialization will remove all the data saved in the HDD. 9.
-
Page 24: Live View
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Live View Some icons are provided on screen in Live View mode to indicate different camera status. These icons include: Live View Icons In the live view mode, there are icons at the right top of the screen for each channel, showing the status of the record and alarm in the channel, so that you can find problems as soon as possible. -
Page 25: Instant Playback By Channel
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR PTZ Control In the Live View mode, you can press the PTZ Control button on the front panel or on the remote, or choose the PTZ Control icon to enter the PTZ toolbar. Description of the PTZ toolbar icons Icon Description... -
Page 26: All-Day Playback By Channel
Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR All-day Playback by channel 1. Enter the All-day Playback menu. Mouse: right click a channel on the screen and select the All-day Playback option from the right-click menu. Front Panel: Press PLAY button to play back record files of the current channel in single-screen view mode. Under multi-screen live view, record files of the top left channel (not masked) will be played back. - Page 27 Quick Operation Guide of DS-7300HI/7300HFI/8100HDI-ST Series DVR Backup Recorded files can be backed up to various devices, such as USB flash drives, USB HDDs or a DVD writer. To export recorded files: 1. Enter Video Export interface. Choose the channel(s) you want to back up and press Quick Export button. 2.
