- Page 1 IR Intelligent Speed Dome Installation Manual Version 1.1.1...
-
Page 2: Table Of Contents
Table of Contents INTELLIGENT SPEED DOME INSTALLATION ..........1 Installation Environments ........................1 Check installation space and installation location intension ............1 About cable ............................. 1 Please keep all package material well for future use ............... 2 SETUP BEFORE INSTALLATION ..............3 Check Accessories .......................... - Page 3 INSTALLATION....................14 Component Installation ........................14 Wall Mount Installation Steps ......................14 3.2.1 Installation Environments ....................... 14 3.2.2 Installation Steps ..........................14 APPENDIX Ⅰ LIGHTENING PROTECTION AND SURGE PROTECTION ..17 APPENDIX Ⅱ ABOUT RS485 BUS ..............18 RS485 Bus Main Feature ........................18 RS485 Bus Transmission Distance ....................
- Page 4 Welcome Thank you for purchasing our speed dome! Please read the following safeguards and warnings carefully before you install or use the product!
-
Page 5: Important Safeguards And Warnings
Important Safeguards and Warnings Safety Measures 1. Qualified Engineer Needed The installation engineer or maintenance engineer shall have corresponding CCTV system installation certificate or maintenance qualification certificate. The installation engineer or maintenance engineer shall have qualification certificate for work at height. - Page 6 Please turn off the power and unplug the power cable, If there is any smoke, disgusting smell, or noise. Please contact your local retailer or customer service centre for help. All the examination and repair work should be done by the qualified service engineers. We are not liable for any problems caused by unauthorized modifications or attempted repair.
- Page 7 Please use the soft cloth to clean dust on the shell, or you can use soft cloth with cleaning liquid to clean the shell and then use soft cloth to make it dry. Do not use gasoline, dope thinner or other chemical material to clean the shell. It may result in shell transfiguration or paint flake.
-
Page 8: Intelligent Speed Dome Installation
95% knitted copper shield RS485 communication cable, refer to appendix 2 International Model Max Transmission Distance (Ft\M) RG59/U 750Ft (229M) RG6/U 1,000Ft (305M) RG11/U 1,500Ft (457M) Note: The above can be applied to analog speed dome and network speed dome... -
Page 9: Please Keep All Package Material Well For Future Use
1.4 Please keep all package material well for future use Please keep speed dome package material well in case you need to send it back to your local retailer or manufacturer for maintenance work. Non-original package material may result in device damage during the transportation. -
Page 10: Setup Before Installation
2 SETUP BEFORE INSTALLATION 2.1 Check Accessories Before the installation, please check the accessories one by one according to the packing list. Please make sure all the components listed are included. 2.2 Open Device Remove the package and then take out the device. Please remove the protection paste from the speed dome. -
Page 11: Initial Setup
Figure 2-2 2.3.1 Initial Setup Address: 1 Parity: None Baud rate: 9600 120Ω resistance: OFF 2.3.2 Dial Switch Setup for Intelligent Speed Dome Before you control speed dome, please set the speed dome address, baud rate, parity. Otherwise, you cannot control the device! See Figure 2-3. -
Page 12: Baud Rate And Parity Setup
Figure 2-3 2.3.3 Baud Rate and Parity Setup For the dial switch button 1-4. 1 and 2 is to set baud rate. 3 and 4 is to set parity. Please refer to the following figure for detailed information. See Figure 2-4. Figure 2-4 Please refer to the baud rate sheet for detailed information. -
Page 13: Terminal Matching Resistance Setup
Figure 2-5 The encode mode adopts binary system. 1 to 8 is valid bit. The highest address bit is 255. You can refer to the following sheet for more information. Address …… ………………………………………………………………… 2.3.5 Terminal Matching Resistance Setup There is terminal resistance 120Ω on the main board. There are two modes: See Figure 2-6. 120Ω... -
Page 14: Dial Switch Setup (Hdcvi Intelligent Speed Dome)
Figure 2-8 2.4 Dial Switch Setup (HDCVI Intelligent Speed Dome) Open the rear cover you can see there are two dial switches on the PTZ for you to set address, baud rate and etc. See Figure 2-9. Figure 2-9 Note: HDCVI speed dome can’t implement dial and other relevant RS485 settings if it only uses coaxial control. -
Page 15: Baud Rate And Hd/Sd Video Format Setup
Open speed dome rear cover, you can see the dial switch buttons on the PTZ main board. You can follow the steps listed below to set the speed dome address, baud rate, and HD/SD video format. Please note you need to restart the device to activate the new setup! There are two dial switch buttons on the PTZ of intelligent speed dome. -
Page 16: Speed Dome Address Setup
1200bps Please refer to the HD/SD video format setup sheet for detailed information. HD/SD video format Self-adapt 2.4.4 Speed Dome Address Setup The address interface is shown as in Figure 2-12. Figure 2-12 The encode mode adopts binary system. 1 to 8 is valid bit. The highest address bit is 255. You can refer to the following sheet for more information. - Page 17 Figure 2-14 If you want to connect the 120Ω resistance, please remove the jumper from the pin 2 and pin 3 and connect to pin 1 and pin 2. Now the 120Ω is connected to the circuit. See Figure 2-15. Figure 2-15...
-
Page 18: Reset And Sd Card Installation (Network Speed Dome)
2.5 RESET and SD Card Installation (Network Speed Dome) Open the rear cover, there is a RESER button shown as in Figure 2-16. The RESET button is to restore system settings. The Micro-SD card installed on the driver is to storage data. Figure 2-16 Micro-SD card should be installed on the module (see Figure 2-17), which is used for data storage. -
Page 19: Cable Connection
Figure 2-17 Note: Please contact the technical support of our company if you have any questions. 2.6 Cable Connection Please connect the power cable, video output cable, audio cable, RS485 control cable, alarm input/output pin, network cable, high-frequency cable, fiber cable according to your actual requirements. - Page 20 The video port is covered the heat shrink tube of high shrinking ratio. After the video connection, please heat the tube to make sure the video port is damp proof and water proof.
-
Page 21: Installation
3 INSTALLATION The intelligent speed dome adopts wall mount mode. 3.1 Component Installation The wall mount bracket and IR speed dome is shown as in Figure 3-1. Figure 3-1 3.2 Wall Mount Installation Steps 3.2.1 Installation Environments The wall mount speed dome can be installed in the hard construction wall in the indoor or outdoor environments. - Page 22 Figure 3-2 Dig holes in the wall according to the installation holes at the bottom of the wall mount bracket. Please make sure the cable exit of the bracket is facing the round hole of the wall. Insert expansion bolts (not provided) to the holes you just dug. Connect the composition cable and then pull it through the hole in the wall.
- Page 23 Figure 3-4...
-
Page 24: Appendix Ⅰ Lightening Protection And Surge Protection
4 APPENDIX Ⅰ LIGHTENING PROTECTION AND SURGE PROTECTION This series speed dome adopts TVS lighting protection technology. It can effectively prevent damages from various pulse signals below 6000V, such as sudden lighting and surge. While maintaining your local electrical safety code, you still need to take necessary precaution measures when installing the speed dome in the outdoor environment. -
Page 25: Appendix Ⅱ About Rs485 Bus
5 APPENDIX Ⅱ ABOUT RS485 BUS 5.1 RS485 Bus Main Feature RS485 is semi duplex communication cable of impedance 120Ω. Its max load amount is 32 effective loads (including main control device and devices to be charged). 5.2 RS485 Bus Transmission Distance When we take 0.56mm (24AWG) twisted-pair as communication cable, the max transmission distance (theoretically) are listed below (according to different baud rates). -
Page 26: Rs485 Bus Faq
Figure 5-2 5.4 RS485 Bus FAQ Phenomenon Possible Reasons Solution Modify host or speed dome setup ； Speed dome Host address(baud rate) and can run self- speed dome address(baud rate) Switch RS485 positive end and diagnosis but I are not match;... -
Page 27: Relationship Sheet
6 APPENDIX Ⅲ THE 24V AC WIRE GAUGE AND TRANSMISSION DISTANCE RELATIONSHIP SHEET It is the recommended transmission distance when the cable diameter is fixed and the 24V AC power consumption is below 10%. For the AC device, the max permission voltage power consumption is 10%. -
Page 28: Appendix Ⅳ12V Dc Wire Gauge And Transmission Distance
APPENDIX Ⅳ12V DC WIRE GAUGE AND TRANSMISSION DISTANCE RELATIONSHIP SHEET The recommended max transmission distance is under the following environments: The wire diameter is fixed and the DC 12V power voltage loss rate is below 10%. For the device of DC power supplying, the max allowed voltage loss rate is 10%. -
Page 29: Appendix V Wire Gauge Reference Sheet
