Section 6: Quick Reference Guide - Generac Power Systems 5.6 kVA PowerPact Owner's Manual

Section 6: Quick Reference Guide

System Diagnosis
To clear an active alarm, press the ENTER button twice and then press AUTO. If the alarm reoccurs, contact an inde-
pendent authorized service dealer.
Active Alarm LED
NONE GREEN
HIGH RED
TEMPERATURE
RPM SENSE RED
LOSS
NOT ACTIVATED NONE
LOW OIL RED
PRESSURE
RPM SENSE RED
LOSS
OVERCRANK RED
NO LEDs LIT NONE
OVERSPEED RED
UNDERSPEED
Owner's Manual for 5.6 kVA PowerPact™
Table 6-1. System Diagnosis
Problem
Unit running in AUTO
but no power in house.
Unit shuts down during
operation.
Unit was running and
shuts down. Attempts
to restart.
Unit will not start in
AUTO with utility loss.
Unit will not start in
AUTO with utility loss.
Unit will not start in
AUTO with utility loss.
Unit will not start in
AUTO with utility loss.
Unit will not start in
AUTO with utility loss.
Unit will not start in
AUTO with utility loss.
Things to Check Solution
Check MLCB. Check MLCB. If it is in the ON position,
contact an Independent Authorized
Service Dealer.
Check the LED's / Check ventilation around the
Screen for alarms. generator, intake, exhaust and rear of
generator. If no obstruction, contact an
Independent Authorized Service
Dealer.
Check the LED's / Clear alarm and remove household
Screen for alarms. loads from the generator. Put back in
AUTO and restart. If generator does
not start, contact an Independent
Authorized Service Dealer.
See if screen says Refer to activation section in
unit not activated. Installation Manual.
Check the LED's / Check oil level. Add oil per
Screen for alarms. Requirements. If oil level is correct,
contact an Independent Authorized
Service Dealer.
Check the LED's / Clear alarm. Using the control panel,
Screen for alarms. check the battery by navigating to the
BATTERY MENU option from the
MAIN MENU. If battery is GOOD,
contact an Independent Authorized
Service Dealer. If display reads
CHECK BATTERY, replace the
battery.
Check the LED's / Verify fuel line shutoff valve is in the
Screen for alarms. ON position. Clear alarm. Attempt to
start the unit in MANUAL. If it does not
start or starts and runs rough, contact
Independent Authorized Service
Dealer.
Check the LED's / Check ATO 7.5 Amp ATO® fuse.
Screen for alarms. Replace with same type fuse if bad.
Contact Independent Authorized
Service Dealer if fuse is good.
Check the LED's / Contact Independent Authorized
Screen for alarms. Service Dealer.
