Swivl Robot User Manual page 6

Step 3: Connect your device.
Open the Bluetooth menu on your device. Press and hold sync button on the Swivl base until Bluetooth status light flashes. Pair
with Swivl. Green status light means connected. You will be prompted to open the Swivl Capture App. Then, insert your device,
screen forward into the base.
Step 4: Connect audio cable.
The marker contains a microphone, so plug the audio cable into micro-
phone port on the base and into your mobile device to receive wireless
microphone feed.
Step 5: Select room placement.
Place Swivl approximately 6-15 feet from the presenter in the front or
middle of the room. Use the Swivl floor or table stand for the best results.
The heads-up display allows the teacher to view the live recording and
uploaded presentations.
Swivl User Guide
whiteboard or projection screen
capture of whiteboards
Desk Desk
Desk Desk
Best for capturing
class interactions
Best for content
Desk
and of the instructor
Desk
Desk
Desk
6
