Axis AX1408NAV Installation Manual

2-DIN 6.8" TOUCHSCREEN DVD/MULTIMEDIA
PLAYER with BLUETOOTH & NAVIGATION
GPS NAVIGATION SIRI CONTROL
GENERAL
- 6.8" WVGA Digital TFT LCD (800 X 480 Pixels)
- Cortex A9 Processor
- WinCE 6.0 Operating System
- Touchscreen Control
- Dynamic Graphic User Interface
- ISO 2-DIN Mounting
- ISO Wiring Harness
- Line Out - Front/Rear/Sub
- 4 Ch Line Out
- Video Line Out
- Stereo AV Line In (Rear)
- Reverse Camera Input (Rear)
- Steering Wheel Control Ready
- 10.5 - V DC Voltage
- Dimensions: 178W x 101.5H x 177.3D mm
- Speaker Impedance 4-8 Ohm
- Max Power 4 Ch x 45 Watts
AX1408NAV
DVD/CD/MP3 BLUETOOTH
TUNER
- PLL Synthesized AM/FM Stereo
- Xtreme Long Range Tuner
- Interference Absorption Circuit
- FM 87.5-108 MHz; AM 522-1
- 30 Station Presets
- 18FM/12AM Memory
- Station Seek / Scan / Auto Store
- Local / Distant Control
- Digital Clock - 12/24 Hour Mode
MULTIMEDIA
- i-mode: Siri Control
- USB Input - Front Panel for: XVID/
MP4/AVI/FLV/ASF/OGM/
MPEG-1/MPEG-2/MP3/JPEG Playback
- SD / MMC Card Port
- AUX-IN Socket - Front Panel
- Stereo AV Line In (Rear)
Supports DIVX
- AUDIO CONTROL
- Rotary Volume Encoder
- Band EQ
- Loud / Mute
The AX1408NAV is designed as a
complete
system,
technologies & media sources. The
massive 2-DIN 6.8" LCD touchscreen
user
exciting
Navigation, Bluetooth & Siri i-mode.
• 6.8 Inch LCD Touchscreen Display
+
• Reversing Camera Input
SD
• 2-DIN Chassis
INPUT
0 KHz
vehicle
integrating an
interface is combined
functions including
DVD/CD PLAYER
- Supports DVD/VCD/CD/MP3/DIVX/JPEG
- Supports DVD±R/DVD±RW/CD-R/RW
- Auto Loading
- Electronic Shock Protection
- Zoom/Slow/Multi-Angle/
Last Position Memory
- Into/Repeat/Random Play/Track Up-Down
- Select Folder/Track/File Search
BLUETOOTH
- Bluetooth in Phone Mode
- External Microphone
- Phone Contacts / History
- Dial Pick-Up/Call Transfer
- A2DP Audio Streaming
- AVRCP App Control
INCLUDED
- External Microphone
- External GPS Antenna
- Remote Control
- Mini USB to USB Adaptor
- Touchscreen Stylus
- Installation Hardware
- ISO Wiring Harness
infotainment
array of
with
GPS
2
YEAR
WARRANTY
