- Page 1 Manual No: 577014-031 ● Revision: C TLS Magnetostrictive Probes International Installation Instructions...
- Page 2 Notice Veeder-Root makes no warranty of any kind with regard to this publication, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Veeder-Root shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this publication.
-
Page 3: Table Of Contents
Determining the Correct Probe Length..............15 Determining the Minimum Access Chamber Depth..........16 Probe Riser Pipe Installation ..................17 Probe Spacer Assembly ..................18 Field Wiring ........................20 Probe to TLS console .....................20 Maximum Cable Lengths..................20 Splicing Probe Field Wiring ..................20 Surge Protector .......................23 Installation (If Required) ..................23... - Page 4 Installation Of A Mag Probe With A Process Connection (Gland)....14 Figure 15. Dimensions Needed To Calculate Custom Probes And Risers ....15 Figure 16. Veeder-Root Riser Cap Assemblies............17 Figure 17. Example Probe Canister Sleeve/Adapter Assembly ........18 Figure 18. Connection Diagram For A Mag Probe In A Riser Pipe With And Without Optional Surge Protection ...........19...
-
Page 5: General
Veeder–Root maintains a continuous process of product development and therefore product specifications may not be as described in this manual. Please contact the Veeder-Root office nearest you, or visit our website at www.veeder.com for information on new or updated products. Changes affecting products or procedures described in this manual will be reported in subsequent revisions. -
Page 6: Health And Safety
RESULTING IN SERIOUS INJURY OR DEATH. EQUIPMENT PROTECTION TLS monitoring equipment, including the Magnetostrictive Probe, is designed and certified to comply with the Directive 94/9/EC (ATEX) and the IECEx scheme. The installer must consider any local regulations, which may differ or be more stringent, prior to installing any equipment. The suitability/safety of any installation is ultimately... -
Page 7: Equipotential Grounding
If the site has a submersible pump (DIN/EN 15268) connected to the same mains safety ground as the TLS Monitoring System Console and it is installed in a metallic riser of a metallic storage tank, the zener diode barrier must be referenced to the same earth (safety) ground. -
Page 8: These Are The Conditions For Safe Use When Installing A Mag Probe
Except for the cables used to connect intrinsically safe apparatus, information contained on the system certificate and each of the device certificates, provide the safety related information (Ex ia) required to install a TLS Monitoring System. Cables used to connect intrinsically safe apparatus must be considered in determining compliance and are limited to the maximum allowable cable parameters listed in this manual. -
Page 9: Procedures For Installing Mag Probes
TLS Magnetostrictive Probes International Installation Guide Procedures for Installing Mag Probes Procedures for Installing Mag Probes Process Connection Riser Pipe Procedure for installing Mag Procedure for installing Mag Probes into storage tanks Probes into storage tanks using a tube gland. -
Page 10: Figure 2. Procedures For Installing Mag Probes Using Wireless Connections
TLS Magnetostrictive Probes International Installation Guide Procedures for Installing Mag Probes Process Connection Riser Pipe Procedure for installing Mag Procedure for installing Mag Probes into storage tanks Probes into storage tanks using a tube gland. using a riser pipe. NOTE: Use a tube gland in... -
Page 11: Mag Plus Probe Installation Kits
Mag Plus Probe Installation Kits The Mag Plus Probe Installation kit. These two wires connect in the J-box or splice kit to the two field wires from the console. Product float Product float Probe cable connector (attaches to threaded connector on the top of probe canister) Adapters Cable... -
Page 12: Surge Protector Kits
10 uA. For example, the two surge arrestors below, supplied by Gilbarco/Veeder-Root, are examples that comply with the above requirements per the manufacturers declaration of conformity. -
Page 13: Process Connections
The two riser caps/glands and process connection gland detailed below can be supplied by Gilbarco Veeder-Root and are included on the manufactures type approval certificates DEMKO 06 ATEX 0508841X and IECEx UL 06.0001X and provide IP67 zone isolation and have been additionally subjected to a 10 bar pressure test. -
Page 14: 76Mm Cap And Gland
TLS Magnetostrictive Probes International Installation Guide Process Connections 76MM CAP AND GLAND Shield (if required) Probe leader cable gland* *Hummel probe leader cable gland P/N: HSK-M-Ex, Size: M16X1,5 (IP68) Ratings: II 2 G Ex e II Label II 1 D Ex tD A20 IP6X Cert No. -
Page 15: Probe Installation
The installation of the tank access chamber is the responsibility of the customer or their local site contractor and not that of Gilbarco S.r.l. / Gilbarco UK. However, there are certain requirements which need to be met to allow the correct installation of Veeder-Root in–tank monitoring probes. Typical installations are shown in Figure 10 and Figure 11. -
Page 16: Provision For Probe Risers
TLS Magnetostrictive Probes International Installation Guide Access Chamber Installation PROVISION FOR PROBE RISERS A dedicated probe tapping of either 2-inch BSP (preferred), 3-inch BSP, or 4-inch BSP must be provided. For maximum height–to–volume accuracy, the probe socket must be as close as possible to the longitudinal axis of the tank. -
Page 17: Probe And Riser Installation Criteria
TLS Magnetostrictive Probes International Installation Guide Probe and Riser Installation Criteria Probe and Riser Installation Criteria Mag probe installations require a 2-inch or 3-inch (51 or 76mm) riser, regardless of tank entry size. Entry sizes of 1 inch, or entries larger than 3 inches must be with the suitable fittings. -
Page 18: Probe Installation Using Process Connection
G2 inch 11 tpi to DIN 2999 (BS2779) must be provided. 1. Prior to installing or servicing the Magnetostrictive Probe, remove the AC input power going to the TLS Console and verify that the console power is off. During servicing, disconnect the probe cable and remove the probe from the tank. -
Page 19: Determining The Correct Probe Length
TLS Magnetostrictive Probes International Installation Guide Probe and Riser Installation Criteria DETERMINING THE CORRECT PROBE LENGTH Refer to Figure 15 and carry out the following procedure. 1. Enter dimensions A, B, C, and E in Table 1. 2. Add dimensions B + C and enter this in column “F”. -
Page 20: Determining The Minimum Access Chamber Depth
Column “K” must be zero or a positive number. If the result is a negative number there is insufficient clearance for the probe and riser assembly. In this case please contact Veeder-Root Technical Support or your local Representative for details on custom length Mag Probes and special skirted risers, having available the dimensions A - E shown in Figure 15. -
Page 21: Probe Riser Pipe Installation
Veeder-Root magnetostrictive probes, should be used for Mag Probe installation (see Figure 16). Riser caps are normally fitted at the time of probe installation by Veeder-Root authorised engineers. An optional cable shield is available for 3-inch (76mm) riser caps, if required. -
Page 22: Probe Spacer Assembly
TLS Magnetostrictive Probes International Installation Guide Probe Riser Pipe Installation PROBE SPACER ASSEMBLY See Figure 17 for example probe sleeve/adapter assembly instructions. Sleeve Assembly - 2” Riser Adapter Assembly - 3” & 4” Risers Fit adapters at each end of the canister. -
Page 23: Figure 18. Connection Diagram For A Mag Probe In A Riser Pipe With And Without Optional Surge Protection
TLS Magnetostrictive Probes International Installation Guide Probe Riser Pipe Installation ZONE 1 HAZARDOUS LOCATION SURGE PROTECTION NOT REQUIRED SURGE PROTECTION REQUIRED Dual Channel Surge Protector Encapsulation Enclosure or Weatherproof Box From From WHITE WHITE Cable Probe Probe BLACK BLACK Bushing... -
Page 24: Field Wiring
Conduits and wiring troughs from probes and sensors to the console must not contain any other wires. At least 2 metres of free cable must be left for connection at both the TLS console and the probe locations. Ensure that cables are correctly identified. -
Page 25: Figure 20. Splice Connections
TLS Magnetostrictive Probes International Installation Guide Field Wiring 3. Make the connections using wire nuts [Figure 3]. Cut off the bare shield wire at the cable jacket. Cable from TLS Cable from probe Bare drain wire (cut back to cable jacket) -
Page 26: Figure 21. Removing Sealing Compound Clip
TLS Magnetostrictive Probes International Installation Guide Field Wiring Figure 21. Removing Sealing Compound Clip Thoroughly mix compound together. Invert bag several times while squeezing compound from one end to the other for a minimum of one minute. 8. Once the mixture feels warm, immediately cut one corner and slowly fill the plastic sleeve. Stop just short of filling the entire sleeve. -
Page 27: Surge Protector
TLS Magnetostrictive Probes International Installation Guide Surge Protector 031-18 Figure 23. Securing Splice Enclosure With Cable Tie Surge Protector INSTALLATION (IF REQUIRED) When surge protection is required, mount the surge protector as close as possible to the entry point for the probe leader cable. -
Page 28: Figure 24. Example Wireless Installation With Process Connection And Single Channel Surge Protector
TLS Magnetostrictive Probes International Installation Guide Surge Protector Battery pack (this side of Probe cable battery support Transmitter bracket) (far side of Pre-installed piping, bracket) e.g., Dip Tube Cable from surge protector Bond 4 mm 2 wire Tie wrap cables... -
Page 29: Appendix A - Surge Protection Risk Assessment
Appendix A - Surge Protection Risk Assessment Where a tank gauge probe is installed in a ‘riser’ and the entire probe is within the vapour space of the tank, a risk assessment is required to assess whether additional surge protection is required in close proximity to the probe. First, complete the Lightning Risk Assessment by identifying whether the site is suitably described by one of the 6 categories listed. - Page 30 Example Isokeraunic Map from IEC Lightning Risk Assessment Tool: Germany...
- Page 31 For technical support, sales or other assistance, please visit: www.veeder.com...
