Fault Finding 3110 - Stephill SE6000D4 Handbook

INTERNAL MEMORY
ERROR

7.10 Fault finding 3110

Unit is inoperative
Read/Write
configuration does not
operate
Unit shuts down
Unit locks out on
Emergency Stop
Low oil Pressure fault
operates
after engine has fired
High engine
temperature fault
operates after engine
has fired.
Shutdown fault
operates
HZ / Frequency
shutdown &
Voltage
shutdown
Warning fault
operates
Fail to Start is
activated after pre-set
number of attempts to
start
Starter Motor not
operating
Issue 6
from the Fuel and Start outputs of the controller.
The configuration file is corrupted. Contact your supplier for
assistance.
Check the DC supply.
Check reset button not tripped and reset if required.
Check 12V DC supply to module. If supply present but not operational try new
unit.
Check for loose wires on the DC connector plug and socket.
Check continuity on +VE and -VE wires to battery.
Check DC supply voltage is not above 16 Volts or below 9 Volts
Check the operating temperature is not above 70°C.
Check the DC fuse.
Check emergency stop switch is functioning correctly.
Check wiring is not open circuit.
Check engine oil pressure.
Check oil pressure switch and wiring, switch is normally closed and opens
with pressure.
Check Oil level and fill to correct level if necessary
Check for loose wires on the Oil switch & DC loom connector block.
Check the continuity of the earth wire. (Refer to wiring diagram)
Check operation of Oil switch.
Check engine temperature.
Check switch/sensor and wiring.
Check switch polarity is correct Normally closed.
Check for loose wires on the temperature switch & DC loom connector block.
Check the continuity of the earth wire. (Refer to wiring diagram)
Check operation of the temperature switch.
Check that the generator air inlets and outlets are not obstructed.
Check relevant switch and wiring of fault indicated on LCD display.
Check configuration of input.
Check reset button not tripped and reset if required.
Check AC Input at module. 115V or 230V (Dependant on type of generator)
Check engine speed is set to 52.5Hz at no load. Adjust if required (Speed
should be set when engine is cold)
Check AC supply from alternator. (If no output refer to alternator handbook)
Check fuse on AVR. (If fitted)
Check engine has been regularly serviced.
Check relevant switch and wiring of fault indicated on LCD display.
Check configuration of input.
Check wiring of fuel solenoid.
Check fuel lift pump operational & fuel supply to engine.
Check battery supply.
Check battery supply is present on the Fuel output of the module.
Check battery voltage is above 12.5V.
Check Oil level and fill to correct level if necessary.
Check fuel level.
Check operation of fuel lift pump.
Check fuel is reaching the injectors. When running correctly fuel should be
running freely from the injector return pipe. If no fuel running from return
check the fuel filters & check condition of fuel.
Check no air in system. Keep fuel pump running using prime button for 20-
30 seconds.
Check Emergency stop.
Check the fuses.
Check battery voltage is above 12.5V.
Check for loose wires on the solenoid, relays, fuses, module terminals, plug
8 15/06/2015
