- Page 1 FUSG50100 Secvest Wireless Outdoor Sounder Installation instructions and user manual Version 1.08 BOM 12686955...
-
Page 2: Table Of Contents
Contents Contents Introduction ..................................3 Safety information ................................5 Scope of delivery ................................7 Technical data ..................................7 Functional principle and features ............................ 9 Installation ..................................12 Functions, jumpers and displays ........................... 16 Maintenance ..................................21 Warranty .................................... 23 Disposal .................................... 24 Declaration of conformity ............................... -
Page 3: Introduction
If you have any questions, please contact your specialist dealer. Further general information and information on product support can be found at www.abus.com on the general page or for dealers and installers, in the Partner portal. - Page 4 Everything possible has been done to ensure that the content of these instructions is correct. However, neither the author nor ABUS Security-Center GmbH & Co. KG can be held liable for loss or damage caused by incorrect or improper installation and operation or failure to observe the safety instructions and warnings.
-
Page 5: Safety Information
Safety information Explanation of symbols The following symbols are used in this manual and on the device: Symbol Signal word Meaning Caution Indicates a risk of injury or health hazards. Indicates a risk of injury or health hazards caused by electrical Caution voltage. - Page 6 Battery warning information The device is supplied with direct current from a battery pack. To guarantee a long lifespan and avoid fire and injury, please note the following: Caution Do not dispose of the battery with household waste. The battery must not be directly exposed to heat or sunlight, and must not be Caution stored in hot places.
-
Page 7: Scope Of Delivery
Product description Sounder Item number FUSG50100 Manufacturer ABUS Security-Center GmbH & Co. KG Environmental class IV (EN 50131-1 + A1:2009 Section 7) Protection class, IP IP65 (in installed state) IP = international protection or ingress protection... - Page 8 Battery type 2 x 3 V alkaline manganese batteries, 18 Ah Item number of the replacement batteries: FU2986 (comprises 2 battery packs) Battery life 2 years nominal With one activation per month for 3 minutes. Flashing and audio alarm With one arming acknowledgement per day.
-
Page 9: Functional Principle And Features
Functional principle and features General The Wireless Outdoor Sounder is an outdoor combination alarm device with siren and flashing light for use with Secvest alarm panels. It serves as an optical and acoustic alarm. The sounder and alarm panel communicate with each other wirelessly, so no fixed wiring is required between the two units. - Page 10 Before starting installation, identify a suitable installation location for the Wireless Outdoor Sounder using the wireless test box. Ensure that the sounder is installed out Note of hand’s reach (minimum 3 m installation height). In addition, the sounder should be visible and audible from afar.
- Page 11 Device description Lid fixing screw with cover Mounting hole for wall installation Mounting holes for tamper mechanism Spirit level Jumper/connector cover Fixing tab for the jumper/connector cover To unlock: Push the tabs on both sides outwards Jumpers and battery connectors Battery Tamper switch 10 Anti-removal wall contact;...
-
Page 12: Installation
Installation Installing the sounder Step 1: Select installation location for the sounder Select an installation location which: is inaccessible to intruders and vandals is located well out of reach (>3 m) is clearly visible, so that it acts as a strong deterrent ... - Page 13 Step 4: Teach in sounder in the alarm panel If this has not been done already, switch the alarm panel on. Place the sounder next to the alarm panel or within range of the alarm panel with which it communicates.
- Page 14 Step 5: Mount the sounder on the wall Note A pin serves as an anti-removal wall contact to activate the tamper switch on the inside of the sounder. To fit uneven walls, the length of this pin can be adjusted. To do this, turn the screw, which is in the pin, either in or out.
- Page 15 Step 6: Switch on sounder Caution The sounder should not be activated in the following steps. You should, however, be prepared for the fact that the sounder might nevertheless be activated. Make sure that any loud sounds emitted do not startle you, causing you to fall off the ladder. ...
-
Page 16: Functions, Jumpers And Displays
Functions, jumpers and displays Installer mode The sounder’s installer mode prevents the sounder and the flashing light from being activated when the cover is opened. Installer mode is activated when installer mode is called up on the alarm panel and is deactivated when installer mode is exited. - Page 17 Set Conf Activates or deactivates the flashing light/beep acknowledgement. If the flashing light is to flash briefly when the system is armed or disarmed, use the alarm panel to enable the “Strobe on Set” or “Strobe on Unset” option in the relevant partition. If the sounder is to beep briefly when the system is armed or disarmed, use the alarm panel to enable the “Beep on Set”...
- Page 18 Time The Tune jumper (off-switch timer) is used to configure the maximum length of time that the acoustic sounder (sounder tone) is active following an alarm. You can choose between five seconds and three minutes. If you do not connect a jumper, a switch-off time of 15 minutes is set. Jumper open = 15 minutes Jumper “3 m...
- Page 19 Operation of the comfort LEDs In normal operation, the comfort LEDs flash alternately if the sounder is connected to the power supply to visually display that the system is operational. When installer mode is activated on the alarm panel, the two comfort LEDs are continuously on for several minutes.
- Page 20 Error and tamper monitoring The sounder continually monitors error and tamper states and reports all events to the alarm panel. The following is monitored: Tamper contact: The sounder’s tamper contact is continually monitored. The sounder activates itself in the event of tampering.
-
Page 21: Maintenance
Maintenance Caution Before opening the sounder’s cover, make sure that the alarm panel is in installer mode. This should prevent the sounder being activated. You should, however, be prepared for the fact that the sounder might nevertheless be activated. Make sure that any loud sounds emitted do not startle you, causing you to fall off the ladder. - Page 22 How to replace the batteries: Put the alarm panel in installer mode. Open the covers for the lid-fixing screws (see Fig. 1), loosen the screws and open the lid. Remove the jumper/connector cover (see Fig. 1) by pushing the two fixing tabs outwards and lifting up the cover at the same time.
-
Page 23: Warranty
In such cases, the warranty ends when the original warranty period of two years expires. All further claims are expressly rejected. ABUS will not be held liable for defects and damage caused by external influences (e.g. transport, use of force, operating errors), inappropriate use, normal wear and tear or failure to observe the instructions in this manual. -
Page 24: Disposal
Declaration of conformity ABUS Security-Center GmbH & Co. KG hereby declares that the device with item number FUSG50100 complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. The declaration of conformity can be obtained from the following address: ABUS Security-Center GmbH &...
