Optional Hardware:
(Allows 2.5 Exdrive to plug-in to a Desktop computer internally)
40 Pin IDE
Power Socket
Connector
Model: AAMD25BY
NOTE:
You may use an available 3.5 Floppy bay like the image shown above
to install the exdrive cradle. If none is available you can mount one to
a 5.25 bay with mounting brackets to fit the bay.
Serial ATA converter board can be attached to the IDE port of the
Exdrive cradle. Once the SATA board is connected, make sure that
both power to the board and the cradle are connected.
Addonics Technologies – Pocket Exdrive Kit Users Guide v6.0
MC-36 Pin
Connector
Exdrive Cradle with Serial ATA
Converter board Attached.
