Menu Option: Subwoofer; An Overview Of The Menu Structure - Paradigm SOUNDPLAY Owner's Manual

MENU OPTION: SUBWOOFER

Subwoofer: Enter the submenu by pressing the
enter button. Here you may configure external
subwoofer integration. It is possible to connect
multiple wired subwoofers if you utilize a 'Y'
splitter attached to the subwoofer cable, or if
your subwoofer offers an output designed to
daisy chain multiple subs.
Subwoofer > No Sub (Default): This option
configures the soundbar to handle all bass infor-
mation and will not output information via the subs
wired connection. Activate by pressing the enter
button and the soundbar will respond with 'Saved'.

AN OVERVIEW OF THE MENU STRUCTURE

Installation [select installation location]
|
–› * Shelf Mount [select when set on a flat surface]
|
†
– › Wall Mount [select when mounted to a wall]
|
–› Above TV [select when soundbar is mounted above TV]
|
– › Below TV [select when soundbar is mounted below the TV]
Subwoofer [select subwoofer configuration]
|
–› * No Sub [select when not using a subwoofer]
|
†
– › Wired Sub [select when attaching a sub via a cable]
Bass Level [adjust bass level in 2dB increments]
|
–› +10dB through –10dB [*
Surrounds [configure surround options for 5.1-channel sources]
|
–› Off [turns off simulated surrounds]
|
– › *On [use simulated surrounds at normal level]
|
– › +6dB [increases level of simulated surrounds +6dB]
†
Stereo Mode [configure options for 2-channel stereo sources]
|
–› Wide [creates a wider stereo image]
|
– › Voice+ [simulates a center channel for stereo sources]
|
†
– Normal [use original stereo signal]
*
Bass Mode [select EQ listening mode for bass]
|
–› Bass+ [sets bass EQ mode for enhanced bass]
|
†
– › *Normal [returns bass EQ to normal levels]
|
– › Night [sets bass EQ mode for reduced bass]
Display [select display mode]
|
–› Bright [use display at full brightness at all times]
|
†
– › Dim [use dimmed display at all times]
† default = 0dB]
Subwoofer > Wired Sub: This option configures
the soundbar to use an external subwoofer
connected via a cable to the soundbar's Sub
Out RCA connection. Activate by pressing the
enter button and the soundbar will respond
with 'Saved'.
**
|
–› *Auto Bright [full brightness, display turns off automatically]
|
– › Auto Dim [dimmed display, display turns off automatically]
Touch Display [select touch display mode]
|
–› Off [turns off LED]
|
– › Bright [use dimmed display at all times]
|
– › Dim [use dimmed display at all times]
|
– › *Auto Bright [full brightness, display turns off automatically]
|
– › Auto Dim [dimmed display, display turns off automatically]
ARC [configure Anthem Room Correction]
|
–› * On [turns Anthem Room Correction on, if loaded]
|
†
– › Off [turns Anthem Room Correction off]
Power Settings [configure power settings]
|
–› Power Standby [configure standby behavior]
|
|
–› * Auto Standby [soundbar turns itself on and off as needed]
| |
†
– › Always On [the soundbar is always powered on]
|
– › Power-On Volume [set default volume for power on]
|
|
–› Set
| |
|
–› Max through –90dB [*
| |
– › Last Used [volume at power on is equal to previous level]
|
– › IP Control [configure IP control]
|
|
–› Off [turns IP Control off]
| |
†
– › *On [turns IP Control on]
|
– › Standby IP [configure Standby IP Control]
|
–› * Off [turns Standby IP Control off]
|
†
– › On [turns Standby IP Control on, disabled if IP Control is off]
default = –35dB]
†
18
