Page 2: Table Of Contents
TABLE OF CONTENTS PROTECTION AGREEMENTS ....... 3 REFRIGERATOR FEATURES ........19 WARRANTY ............4 Refrigerator Shelves ...........19 REFRIGERATOR SAFETY ........5-6 Deli Drawer ............19 Proper Disposal of Your Old Refrigerator ..6 Crisper ..............20 INSTALLATION INSTRUCTIONS ..... 7 FREEZER FEATURES ..........21 DOOR FEATURES ..........22 Unpack the Refrigerator ........7 Location Requirements ......... -
Page 3: Protection Agreements
• Power surge protection against electrical damage due to power fluctuations. Congratulations on making a smart purchase. Your new Kenmore® product is designed and manufactured for • $300 Food Loss Protection for any food spoilage years of dependable operation. But like all products,... -
Page 4: Warranty
WITH PROOF OF SALE, a defective appliance will receive free repair or replacement at option of seller. For warranty coverage details to obtain free repair or replacement, visit the web page: www.kenmore.com/warranty This warranty applies for only 90 DAYS if this appliance is ever used for other than private household purposes. -
Page 5: Refrigerator Safety
REFRIGERATOR SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and others. All safety messages will follow the safety alert symbol and either the word “DANGER”... -
Page 6: Proper Disposal Of Your Old Refrigerator
SPECIFICATIONS MODELS 7121*, 6121 * WIDTH 32.9 in EXTERNAL DIMENSIONS BACKGROUND 32.0 in HIGH 66.7 in NET WEIGHT 220.5 Lbs FREEZER CAPACITY 5.8 cu ft FRESH FOOD CAPACITY 15.0 cu ft TOTAL CAPACITY 20.8 cu ft COOLING SYSTEM FORCED CONVECTION SYSTEM CARACTERISTICS BY RESISTENCE, TYPE SHEATH... -
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS Unpack the Refrigerator WARNING Excessive Weight Hazard Use two or more people to move and install refrigerator. Failure to do so can result in back or other injury. Clean Before Using Remove the Packaging • Remove tape and glue residue from surfaces before •... -
Page 8: Location Requirements
INSTALLATION INSTRUCTIONS Location Requirements Electrical Requirements WARNING WARNING Explosion Hazard Electrical Shock Hazard Keep flammable materials and vapors, such as gasoline, Plug into a grounded 3 prong outlet. away from refrigerator. Do not remove ground prong. Do not use an adapter. Failure to do so can result in death, explosion, or fire. -
Page 9: Parts And Features
PARTS AND FEATURES *This instruction manual refers to several models. Features may vary according to model. 1. Freezer door bin 7. Adjustable half width shelf with deli drawer 2. Dairy compartment for spreadable food items such as butter or margarine. 8. -
Page 10: Water Supply Requirements
INSTALLATION INSTRUCTIONS Water Supply Requirements(optional) Water Pressure iMPorTANT: A cold water supply with water pressure This water line installation is not warranted by the between 30 and 120 psi (207 and 827 kPa) is required to refrigerator or icemaker manufacturer. Follow these operate the icemaker. -
Page 11: Connect To Refrigerator
INSTALLATION INSTRUCTIONS Connect the Water Supply (continued) Connect to Refrigerator 5. Drill a ¼” hole in the cold water pipe (even if using a 1. Unplug refrigerator or disconnect power. self-piercing valve), using a sharp bit. Remove any burrs 2. Remove the screws holding the compressor compartment resulting from drilling the hole in the pipe. -
Page 12: Complete The Installation
INSTALLATION INSTRUCTIONS Complete the Installation Front Base Grille WARNING The front base grille which was packaged inside the refrigerator for shipment and should be installed after the refrigerator has been leveled. 1. Align the base grille to the screw holes. (The cut out side on the base grille installs around the lower hinge of the door.) Electrical Shock Hazard... -
Page 13: Front Base Grille Installation
INSTALLATION INSTRUCTIONS Reverse Doors (optional) iMPorTANT: If you want to reverse your doors so that they 7. Tape the refrigerator door shut with masking tape.With open in the opposite direction, follow these steps. a 5/16 “ socket and ratchet, remove the middle hinge screws and middle hinge from the top of refrigerator Tools required: 5/16 “... -
Page 14: Reverse Doors
INSTALLATION INSTRUCTIONS Reverse Doors (optional) (continued) 12. Remove the refrigerator door stop from the underside 15. Carefully place refrigerator door onto the hinge plate of refrigerator door and secure it on the opposite side in lower corner. Ensure that the washer is in place on with a Phillips screwdriver. -
Page 16: Adjust The Doors
INSTALLATION INSTRUCTIONS Adjusting the Doors Door Aligning Leveling If the space between your doors looks uneven, you can adjust it using the following instructions: Your refrigerator has two front adjustable legs - near each front corner of ther refrigerator, next to the rollers. If your NoTe: Use foam door spacer to set the correct gap between refrigerator seems unsteady or you want the doors to the freezer and refrigerator door. -
Page 17: Refrigerator Use
REFRIGERATOR USE Using the Controls Freezer Temperature Control Your refrigerator has two controls that affect the The temperature control dial is calibrated in a range from temperature. “Coldest” to “Cold”. The Temperature control is located at the top front of the refrigerator compartment and the Airflow control is For your convenience, the Temperature control is preset at located on the back wall of the freezer compartment. -
Page 18: Icemaker
REFRIGERATOR USE Frost Free Your refrigerator is designed to defrost automatically ice Production rate • The icemaker should produce approximately 8 to 12 Warm Cabinet Surfaces batches of ice in a 24 hour period. If ice is not being made fast enough, turn the Freezer control toward a At times, the front of the refrigerator cabinet may be warm higher (colder) number in half steps. -
Page 19: Refrigerator Features
REFRIGERATOR FEATURES Half-Width Shelf Your model may have some or all of these features. To know about glass shelves and covers: One side of the shelf rests on a molded side-wall support; a bracket on the other side hooks into a track on the rear Refrigerator Shelves cabinet wall. -
Page 20: Crisper
REFRIGERATOR FEATURES Crisper Crisper Humidity Control Crisper Drawers You can control the amount of humidity in the moisture- sealed crisper. For most fruits, slide the control (select The Crispers provide a storage area for fruit and models) to “lo” to provide and vegetables with skins lower vegetables. -
Page 21: Freezer Features
FREEZER FEATURES CAUTION : To avoid personal injury or property damage. • Never attempt to adjust a shelf when it is loaded with food. • Confirm that shelf is secure prior to loading items onto To remove and replace a wire shelf: 1. -
Page 22: Door Features
DOOR FEATURES Door Bins To remove and replace the bins: 1. Remove the bin by lifting it and pulling it straight out. 2. Replace the bin by sliding it in above the desired support and pushing it down until it stops. Dairy Compartment The covered dairy compartment is designed to store spreadable food items such as butter or margarine. -
Page 23: Food Storage Guide
FOOD STORAGE GUIDE Fresh Food Storage Freezer Storage • The fresh food compartment of a refrigerator should • The freezer compartment of a refrigerator should be kept between 34°F (1°C) and 40°F (4°C) with an be kept at approximately 0°F (-18°C). To check the optimum temperature of 37°F (3°C). -
Page 24: Refrigerator Care
NoTe: When cleaning stainless steel, always wipe in the direction of the grain to avoid cross-grain scratching. Stainless Steel Cleaner For best cleaning results, use Kenmore Stainless Steel Cleaner item #02240083 or equivalent. Available on sears.com or by calling 1-844-553-6667. - Page 25 REFRIGERATOR CARE Vacation and Moving Care Moving 1. If your refrigerator has an automatic icemaker: Vacations • Turn off the water supply to the icemaker at least if You Choose to leave the refrigerator on while You’re one day ahead of time. Away: •...
-
Page 26: Troubleshooting Guide
TROUBLESHOOTING GUIDE First try the solutions suggested here or visit our website to possibly avoid the cost of a service call. WARNING WARNING Electrical Shock Hazard Explosion Hazard Plug into a grounded 3 prong outlet. Use nonflammable cleaner. Do not remove ground prong. Do not use an adapter. Failure to do so can result in death, explosion, or fire. - Page 27 TROUBLESHOOTING GUIDE TEMPERATURE Problem Possible Causes What to Do Freezer, refrigerator too New installation Allow 24 hours following installation for the refrigerator warm to cool completely. Control set too warm. Prolonged door Adjust temperature control. Minimize door openings. openings. A large amount of warm food has Allows several hours for refrigerator to return to normal been recently added.
- Page 28 TROUBLESHOOTING GUIDE Icemaker Problem Possible Causes What to Do The icemaker is not The icemaker is not connected to a Connect refrigerator to water supply and turn water producing ice or not water supply shutoff valve fully open. enough ice (on some A kink in the line can reduce water Straighten the water source line models)
- Page 29 Kenmore For Sears Home Services in-home repair of all Kenmore major appliances. For the replacement parts, accessories and Use & Care Guides that you need to do-it-yourself. For professional installation of major home appliances and items like air conditioners and water heaters.
