Summary of Contents for Aiwa HS-TA303
- Page 1 HS-TA303 YJ,YL,YZ SERVICE MANUAL STEREO RADIO BASIC TAPE MECHANISM : 4ZM-2 P3N CASSETTE PLAYER S/M Code No. 09-99C-423-2R1...
-
Page 2: Specifications
SPECIFICATIONS Frequency range: FM: 87.5 – 108MHz AM: 530 – 1710kHz <YL> AM: 530 – 1605kHz <YZ, YJ> Maximum output: 15 mW + 15 mW (EIAJ/32 ohm) <YL> 4 mW + 4 mW (EIAJ/16 ohm) <YZ, YJ> Power source: DC 3V using two R6 (size AA) batteries Maximum dimensions: 92.0 (W) x 116.4 (H) x 37.6 (D) mm in.) Weight:... -
Page 3: Electrical Main Parts List
TRANSISTOR ILLUSTRATION ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C307 87-A11-596-080 C-CAP,S 0.068-16 K B C308 87-A11-596-080 C-CAP,S 0.068-16 K B 87-A21-387-040 C-IC,TA2145F C309... - Page 4 WIRING...
-
Page 5: Schematic Diagram
SCHEMATIC DIAGRAM... - Page 6 MECHANICAL EXPLODED VEW 1/1 ADJUSTMENT A MAIN C.B VOLUME L104 PVC1 PVC 101 L102 TC101 TC104 TC102 L103 SFR51 TC103 SFR 1 L105 PHONES P HEAD L101 BAR ANT <TUNER SECTION> <TAPE PLAYER SECTION> 1. AM IF Adjustment 6. Tape Speed Adjustment L105 ..............
-
Page 7: Mechanical Parts List
MECHANICAL PARTS LIST 1/1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8A-HG8-005-010 CAP, MSP 2 8A-HRJ-002-010 PANEL,MSP<[S]YL1,[S]YL> 2 8A-HRJ-012-010 PANEL,MSP YZ<EXCEPT [S]YL1,[S]YL> 3 8A-HRJ-003-010 KNOB,RTRY MSP 4 8A-HRJ-005-010 RING,MSP 5 8A-HRJ-201-010 RACK,MSP 6 86-HRM-205-010 SPR-T,CLICK 7 8A-HRJ-001-010 LID,CASS<[S]YL1,[S]YL,YJ>... -
Page 8: Tape Mechanism Exploded View
TAPE MECHANISM EXPLODED VIEW 1/1 FRAME,CENTER... -
Page 9: Tape Mechanism Parts List
TAPE MECHANISM PARTS LIST 1/1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 84-ZM2-012-010 LEVER,PLAY G 84-ZM2-211-01K GEAR,CONNECT 84-ZM2-222-010 SPR-T,PLAY 84-ZM2-015-010 LEVER,STOP G 84-ZM2-014-010 LEVER,REW G 84-ZM2-013-010 LEVER,FF G 84-ZM2-223-010 SPR-T,REW STOP 84-ZM2-232-010 BELT,MAIN 84-ZM2-221-010 FLY-WHL,P2 84-ZM2-230-010 CAPSTAN,P 1.8-25 84-ZM2-220-01K... - Page 10 2-11, IKENOHATA 1-CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 9920594 0 2 5 1 4 3 1 9630472 3111 Printed in Singapore...
