EN
OPERATING
INSTRUCTIONS
DISHWASHER
www.gorenje.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV63160 and is the answer not in the manual?

Questions and answers

Related Manuals for Gorenje GV63160

Summary of Contents for Gorenje GV63160

  • Page 1 OPERATING INSTRUCTIONS DISHWASHER www.gorenje.com...

  • Page 2: Table Of Contents

    Contents Front panel ....................Safety instructions ..................Before washing for the first time ............... Loading the dishwasher ................Using the dishwasher ................Settings ..................... Care and cleaning ..................Troubleshooting ..................Installation ....................Service ...................... Information for test institute ............... Technical information ................Front panel Main power switch SpeedWash...

  • Page 3: Safety Instructions

    Safety instructions General Winter storage/transport • Read the operating instructions and keep them Store the dishwasher where the temperature remains • in a safe place! above freezing. Avoid long transport distances in very cold weather. • • Never use the dishwasher for any purpose other Transport the dishwasher upright or laying on its back.

  • Page 4: Before Washing For The First Time

    Before washing for the first time The water softener Refill salt indicator In order to achieve good dishwashing results, the When the salt needs topping up, the above symbol lights dishwasher needs soft water (water with low mineral on the display. content).

  • Page 5: Loading The Dishwasher

    Loading the dishwasher Energy-efficient dishwashing Raising and lowering the upper basket Pull out the upper basket. (The basket must be empty.) Do not start the dishwasher until it is fully loaded to save • energy. Turn the basket catch outwards at the end of both runners.

  • Page 6: Using The Dishwasher

    Using the dishwasher Add detergent The main power switch Press to open Press and hold the main power switch until the display turns on. Also check that the water tap is on. PROGRAMS - Choose programme Choose a programme to suit the type of dishes and how dirty they are.

  • Page 7: Unloading The Dishwasher

    How to get the best drying results Extra dry Fully load the dishwasher. • A higher temperature in the final rinse improves the drying Angle dishes with hollows, such as cups, so that the • results if you activate this option. Energy consumption is rinse water will run off.

  • Page 9: Settings

    Settings Open the settings menu: First, open the door. Turn off the machine. Press and hold the main power switch until the display lights up. Within 10 seconds: - press the Programme selector and the option button for SpeedWash. The display shows the settings menu (current setting and its currently set value). (Exit the menu by browsing through the menu or pressing the main power switch.) Navigate the settings menu: Press to save the set value and continue to the...
  • Page 10 Settings Options 3:00 (Off) You can activate this setting when using 3-in-1/ (3-in-1/all-in-one detergent) 3:01 (On) All-in-one detergent. The dishwashing programmes automatically adapt to provide the best possible dishwashing and drying results every time. If this setting is activated there is no need to add rinse aid since this option disables rinse aid dispensing.

  • Page 11: Care And Cleaning

    Care and cleaning Coarse filter Spray arms The coarse filter traps larger food particles, which cannot Holes and bearings can sometimes become blocked. get past the drainage pump. Empty the coarse filter as Remove any debris using a pin or the like. The spray arms necessary.
  • Page 12 Front panel NOTE! Keep the buttons clean and free from grease. Wipe them Do not forget to replace the drainage pump stop. clean with a dry or slightly damp cloth. Never use cleaners – they can scratch the surface. Use the main power switch to turn off the dishwasher before cleaning the buttons to Unblocking the inlet hose filter avoid activating any buttons unintentionally.

  • Page 13: Troubleshooting

    Troubleshooting Type of fault on the display Action Overfilling Clear the drainage pump. See the section Care and cleaning. If the problem persists, call the service department. Water outlet fault See “Water remains in the dishwasher” in the table “Problem” below. If the problem persists, call the service department.
  • Page 14 Problem Possible causes Action The dishes are not clean. The spray arms do not rotate. Remove the arms and clean them. Check that the dishes are not blocking the spray arms. Old detergent. Detergent is a perishable Avoid large packages. product.

  • Page 15: Extra Dry

    Problem Possible causes Action Rattling sound when dishwashing. The dishes are not correctly placed or Check that the dishes are placed the spray arms are not rotating. securely. Spin the spray arms to make sure they can rotate. Water remains in the dishwasher. The filters are blocked.

  • Page 16: Installation

    Installation [mm] 1194 Door length Nominal dimensions. Actual measurements may vary. It is important that you read through and follow the Setup instructions and directions below. Conduct installation and The recess and connection dimensions are included in • connection in accordance with the separate installation the separate installation instructions.

  • Page 17: Connection To Water Supply

    NOTE! NOTE! When the drainage hose is routed to a connection nipple Repairs and maintenance relating to safety or on the sink unit's water trap (see illustration 1), please performance must be carried out by a qualified note that the hose must be attached at the same height professional.

  • Page 18: Service

    The request should include the details on the serial number www.gorenje.com. plate. Include the article number (1) and the serial number When making contact, provide the details on the serial (2).
  • Page 19 Your notes...

  • Page 20: Technical Information

    Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1059/2010 Gorenje Model designation: GV63160 Number of standard place settings: Energy efficiency class: Annual energy consumption(AE 295 kWh per year Energy consumption of the standard cleaning cycle(E 1.04 kWh...
