Gorenje GV66261 Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Main power switch
1
Auto wash
2
Intensive wash
3
Eco wash
4
Quick wash
5
Rinse
6
SpeedWash
7
Safety instructions ............................................
Before washing for the first time .......................
Loading the dishwasher ....................................
Using the dishwasher .......................................
Settings .............................................................
Care and cleaning ............................................
Troubleshooting ................................................
Installation ........................................................
Service ..............................................................
Information for test institute ..............................
Technical information ........................................
EN
Operating Instructions
Dishwasher
GV66261
Auto open
8
Extra hygiene
9
Delayed start
10
Display
11
Rinse aid indicator
12
Salt indicator
13
2
3
4
5
9
11
13
17
18
19
20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV66261 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gorenje GV66261

Summary of Contents for Gorenje GV66261

  • Page 1: Table Of Contents

    Operating Instructions Dishwasher GV66261 Main power switch Auto open Auto wash Extra hygiene Intensive wash Delayed start Eco wash Display Quick wash Rinse aid indicator Rinse Salt indicator SpeedWash Safety instructions ..........Before washing for the first time ....... Loading the dishwasher ........

  • Page 2: Safety Instructions

    Safety instructions Winter storage/transport General Store the dishwasher where the temperature remains • • Read the operating instructions and keep them above freezing. in a safe place! Avoid long transport distances in very cold weather. • • Never use the dishwasher for any purpose other Transport the dishwasher upright or laying on its back.

  • Page 3: Before Washing For The First Time

    Before washing for the first time The water softener Refill salt indicator In order to achieve good dishwashing results, the When the salt needs topping up, the above symbol lights dishwasher needs soft water (water with low mineral on the display. content).

  • Page 4: Loading The Dishwasher

    Loading the dishwasher Repeatedly lift the basket with both hands to change its Economic dishwashing position. (The upper basket can be set in three Do not start the dishwasher until it is fully loaded to save • positions.) When the upper basket is in the highest energy.

  • Page 5: Using The Dishwasher

    Using the dishwasher Add detergent NOTE! Add the detergent to the detergent compartment. There is Place the dishes in the machine so that the rinse water a compartment for the prewash and one for the main wash. will run off them; this is especially important for plastic. If powder and liquid dishwasher detergents are used, add a small amount of the detergent to the prewash Check that the spray arms can rotate freely.
  • Page 6 programmes and some options cannot be combined The main power switch (available options glow dimly). Press and hold the main power switch until the display lights SpeedWash This option shortens the programme time, but uses more PROGRAMS - Choose programme energy and water.
  • Page 7 Activate the Auto open option. • Allow the dishes to cool before unloading the • dishwasher. Once the programme has finished The end of the programme is indicated by one short signal from the buzzer. The chapter Settings describes how to change this function.

  • Page 9: Settings

    Settings Open the settings menu: First, open the door. Turn off the machine. Press and hold the main power switch until the display lights Within 10 seconds: - press the programme button for Auto wash and the option button for SpeedWash. The display shows the settings menu (current setting and its currently set value).
  • Page 10 Settings Options 3:00 (Off) You can activate this setting when using 3-in-1/ (3-in-1/all-in-one detergent) 3:01 (On) All-in-one detergent. The dishwashing programmes automatically adapt to provide the best possible dishwashing and drying results every time. If this setting is activated there is no need to add rinse aid since this option disables rinse aid dispensing.

  • Page 11: Care And Cleaning

    Care and cleaning In order to inspect the drainage pump, remove the Coarse filter coloured stop on the right in the bottom drain. The coarse filter traps larger food particles, which cannot By inserting your finger into the hole you can turn the get past the drainage pump.
  • Page 12 Spray arms Unscrew the spray arm bearings counterclockwise to remove the spray arm from the upper basket. Holes and bearings can sometimes become blocked. Remove any debris using a pin or the like. The spray arms also have holes underneath. Door When cleaning the edge around the door, use only a slightly To facilitate cleaning you can remove the spray arms.

  • Page 13: Troubleshooting

    Troubleshooting Type of fault on the display Action Overfilling Clear the drainage pump. See the section Care and cleaning. If the problem persists, call the service department. Water Outlet Fault See “Water remains in the dishwasher” in the table “Problem” below. If the problem persists, call the service department.
  • Page 14 Problem Possible causes Action The dishwasher does not start. The door is not properly closed. Check. You have opened the dishwasher to add Close the door and wait. After a while, more dishes while a programme is in the dishwasher continues the progress.
  • Page 15 Problem Possible causes Action Spots or films on the dishes. The water softener is leaking salt. Check that the salt compartment lid is properly tightened. Otherwise call the service department. Incorrect water softener setting. See the section Settings. Incorrect rinse aid dosage setting. See the sections Before washing for the first time and Settings.
  • Page 16 Problem Possible causes Action The dishes are not dry enough. The Auto open option is not activated. Activate the Auto open option. The dishwasher is not fully loaded. Fully load the dishwasher. Rinse aid needs topping up or dosage Top up with rinse add or increase the is set too low.

  • Page 17: Installation

    Installation [mm] 1194 1252* Door length Cover door with slide function fitted, which means the cover door slides upwards when the dishwasher is opened. Setup It is important that you read through and follow the instructions and directions below. Conduct installation and The recess and connection dimensions are included in •...

  • Page 18: Service

    Service No part of the drainage hose may be more than 950 mm Read the chapter Troubleshooting before contacting the above the bottom of the dishwasher. service department. Provide the details on the serial number plate in all contact. Include the article number (1) and the Ensure that the drainage hose has no kinks.

  • Page 19: Information For Test Institute

    Information for test institute Request test institute information via e-mail dishwashers@appliance-development.com. ART. NO. The request should include the details on the serial number SERIAL NO. plate. Include the article number (1) and the serial number (2).

  • Page 20: Technical Information

    Technical information Information on energy labelling Information sheet, in compliance with Commission Delegated Regulation (EU) No. 1059/2010 Gorenje Model designation: GV66261 Number of standard place settings: Energy efficiency class: A+++ Annual energy consumption(AE 233 kWh per year Energy consumption of the standard cleaning cycle(E 0.82 kWh...
