If you need more than 10 ft length of the power cable on the AC adapter, you
could skip the AC adapter and instead power the camera with PoE. That would
allow you to use inexpensive Cat5e network cable to supply power from up to 300
ft away. Cat5e network cable with the required connectors is available at Home
Depot in convenient rolls of 15 ft, 25 ft, 50 ft and 100 ft.

2.5 Mount the weatherproof junction box

Before physical installation, please ensure wireless settings are completed and
operational – to set wireless up, you need to connect the camera directly to your
router with an Ethernet cable.
The included Weatherproof Junction Box provides a neat and waterproof
termination of connections to the Phylink Bullet HD outdoor camera.
When connecting outdoors, the use of this junction box will ensure weather
protection and prevent power and signal faults due to water ingress at the
connections.
When you use this junction box, you only need to drill a small hole in the wall to
run the extension cabling to an indoor power outlet and network.
A roughly 1/4 inch diameter hole will be required for either a network cable or the
DC plug at the end of the power adapter cord to pass through.
Outdoor
Weatherproof
Junction Box
Figure 1
Indoor
Building wall
Power adapter cord
Network cable
7
