Mediastar Evolution 785 Quick Start Manual

Quick Start Guide - MediaStar Evolution 785 HD Video Encoder
The MediaStar Evolution 785 encoder allows a video and audio
signal to be streamed to an unlimited number of users across
an IP network in real-time. The remote users can use software
or hardware based decoders to watch the live video and audio.
This Encoder is a standalone unit that has a variety of standard
video and audio inputs. It can be setup to use a particular
video input or it can scan all inputs and start streaming the
first video signal it detects. Basic configuration/control can be
made using an on-board display and selection buttons, while
the full range of controls can be accessed via simple-to-use
web pages.
The encoder has a variety of other features that make it
anessential part of any sophisticated AV switching system.
These include IP/RS232 control commands, network sourced
IR blasting, and an IP to RS232 pass-through comms link. It is
powered from a mains-DC plug-in power supply or via802.3af
Power-over-Ethernet (PoE). There are no moving parts within
the encoder, and it can operate reliably in all dry environments
from 0-40°C (32-104°F).

Important Safety Instructions

1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarised or
grounding-type plug. A polarised plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
785_QSG_Ve
What's in the box
• 785 Encoder
•
CAT5 patch cable
• HDMI lead
•
3 phono video lead
• 3.5mm plug to 2 phono audio lead
• RS232 lead
12. Use only with the cart, stand tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
WARNING: THERE ARE NO USER SERVICEABLE PARTS
WITHIN THE MEDIASTAR 780 UNIT.
Part No. 200-2430 – v4 1
