Mediastar Evolution 779-S-SD Quick Start Manual

Quick Start Guide
Getting started with the MediaStar 779
Multi Format Input SD-HD Encoder
Models: 779-S-SD, 779-S-HD, 779-D-SD, 779-D-HD
the MediaStar Evolution 779 Encoder is a standalone
MpEG2 or MpEG4-10/H264 video and audio encoder.
It can take the video input from a variety of different
source formats (Composite, S-Video, Ypbpr, rGB, VGa
or HDMI) and will scale the images to either SD or
HD resolutions. the video and accompanying audio is
then encoded into MpEG2 or H264 data, and is then
streamed onto a Lan. Separate decoder units or pC
software clients can then display the video and audio
at any network enabled location.
the unit has a front panel mounted LCD and push buttons
to allow easy network setup and source selection,
with an embedded http web page server providing
confi guration web pages for more advanced features.
the 779 unit may be purchased with a single or dual
set of video inputs (779-S-xx and 779-D-xx units), and
also with either an SD output stream resolution, or a
selectable SD/HD output stream resolution (779-x-SD
or 779-x-HD).

Important Safety Instructions

1. read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves or other apparatus (including
amplifi ers) that produce heat.
9. this unit must be installed using a mains (aC
supply) plug and socket that contains a protective
earth (ground) connection. the mains socket must be
located near the equipment, remain operable and be
easily accessible to disconnect the unit in the case of
an emergency.
10. Do not defeat the safety purpose of the polarised or
grounding-type plug. a polarised plug has two blades
with one wider than the other. a grounding type plug
has two blades and a third grounding prong. the wide
blade or the third prong are provided for your safety. If
779QSG_v3
What's in the box
• 779 Encoder unit
• aC mains cable
• 2m Cat-5 patch lead
• 1.5m HDMI cable
• 1.5m Ypbpr component video cable
• 2m SVGa cable (15 way HDD plugs)
• 1.2m 3.5mm Jack to 2 x phono (audio) cable
• Ir Blaster assembly (part 911-4153)
Please note: 779-D-xx units have two sets of video/
audio input cables included.
the provided plug does not fi t into your outlet, consult
an electrician for replacement of the obsolete outlet.
11. protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
12. only use attachments/accessories specifi ed by the
manufacturer.
13. Use only with the cart, stand tripod, bracket,
or table specifi ed by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
14. Unplug this apparatus during lightning storms or
when unused for long periods of time.
15. refer all servicing to qualifi ed service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
Warning: There are no user serviceable parts within
the Mediastar 779 Encoder unit.
part no. 200-2410 v3
