Doc. no. LEF-OM00205
PRODUCT NAME
Electric Actuator /Slider Type
MODEL / Series
LEF Series
<Controller>
LEC Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEF Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Corporation LEF Series

  • Page 1 Doc. no. LEF-OM00205 PRODUCT NAME Electric Actuator /Slider Type MODEL / Series LEF Series <Controller> LEC Series...
  • Page 2: Table Of Contents

    1.2 Controller setting software ............5 1.3 Teaching box ................7 2. Specification ................... 9 2.1 Slider type LEF Series / Ball screw drive Specification..9 2.2 Slider type LEF Series / Belt drive Specification....11 2.3 How to Order ................13 2.4 Construction ................
  • Page 3: Safety Instructions

    LEF Series / Slider type Safety Instructions These safety instructions are intended to prevent hazardous situations and /or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO /IEC), Japan Industrial Standards (JIS)*1) and other safety regulations*2).
  • Page 4 LEF Series / Slider type Safety Instructions Caution The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary.
  • Page 5: Procedure Before Operation/Simple Setting To Use Straight Away4

    1. Procedure before operation/simple setting to use straight away The controller is already set with the data of the actuator. With the simple setting “easy mode”, it can be operated and running parameters can be changed easily. 1.1 Preparation (1) Items to be prepared Please check what is written on the label, and the quantity of accessories, to confirm that it is the product that was ordered.
  • Page 6: Controller Setting Software

    1.2 Controller setting software 1. Installation of software With the controller setting software CD-ROM, install the communication unit software, following the “Software Installation procedure” (PDF) 2. Startup of software After turning on the controller power supply, start up the ACT Controller. Select “Easy Mode”...
  • Page 7 4. TEST Drive / Step No.0 → No.1 → No.0・・・ a. Driving preparation: Servo On → Return to ORIG / Refer to 3.JOG Drive. b. TEST Drive “Step No.0” Operation Procedure 2: → Operation Procedure 1: Select “Drive” Select “Step No.0” You can select anywhere in the row “Step No.1”...
  • Page 8: Teaching Box

    1.3 Teaching box 1. Name (2) JOG key (3)SET key (4) Up and down, right and left key (5)MENU key (1) Number key 2. JOG Drive データ テスト モニタ EXT Inp OFF:YES Operates by (2) JOG key DATA TEST MONITOR Press the (3)SET key JOG+: End side ↓...
  • Page 9 4. Step data change “Step No.0” / Positioning operation / At the time of shipment, Step No.0 is set to positioning operation データ テスト モニタ Change of positioning Below display shows DATA TEST MONITOR stop position the position of 50mm Posn 50 mm →...
  • Page 10: Specification

    2. Specification 2.1 Slider type LEF Series / Ball screw drive Specification (1) Step motor (servo 24VDC) Ball screw drive Model LEFS 16 LEFS 25 LEFS 32 100,200,300,(400),500 Note1) Stroke(mm) 100,200,300,(400) 100,200,300,(400),500, 600 (600,700,800) Horizontal Note2) Work load(kg) Vertical Note2)
  • Page 11 (2) Servo motor (24VDC) Ball screw drive Model LEFS16A LEFS25A Note1) Stroke(mm) 100, 200, 300,(400) 100, 200, 300, (400), 500,(600) Horizontal Note2) Work load(kg) Vertical Note2) Speed(mm/s) 10 to 500 5 to 250 12 to 500 6 to 250 Positioning repeatability(mm) 0.02 Lead(mm) Impact resistance/ vibration...
  • Page 12: Slider Type Lef Series / Belt Drive Specification

    2.2 Slider type LEF Series / Belt drive Specification (1) Step motor (servo 24VDC) Belt drive Model LEFB 16 LEFB 25 LEFB 32 (300), 500, (600, 700), (300),500,(600,700),800,(900), (300),500,(600,700),800,(900), Note1) Stroke(mm) 800, (900), 1000 1000, (1200,1500,1800,2000) 1000,(1200,1500,1800,2000) Note2) Work load(kg)
  • Page 13 (2) Servo motor (24VDC) Belt drive Model LEFB16A LEFB25A (300), 500, (600, 700), 800, (300), 500, (600,700), 800, (900), Note1) Stroke(mm) (900), 1000 1000, (1200, 1500, 1800, 2000) Note2) Work load(kg) Horizontal Note2) Speed (mm/s) 48 to 2000 48 to 2000 Positioning repeatability(mm) Lead equivalent(mm) Impact resistance/ vibration...
  • Page 14: How To Order

    2.3 How to Order <Ball screw drive> LEFS 25 □ □ □ □ Controller mounting Size Screw mounting type Screw mounting type DIN rail mounting type DIN rail mounting type Motor option Without lock Without lock I/O cable length With lock With lock Without cable Without cable...
  • Page 15: Construction

    2.4 Construction <Ball screw drive> Parts list Description Material Remarks Description Material Remarks Body Aluminium alloy Anodized Motor mount Aluminium alloy Anodized Rail guide Coupling Ball screw Ass’y Motor cover Aluminium alloy Anodized Connector shaft Stainless steel End cover Aluminium alloy Anodized Table Aluminium alloy...
  • Page 16: Product Outline

    3. Product Outline 3.1 System construction Note 1) ●I /O cable ●●Electric actuator Part No:LEC-CN5-∗ /Slider type Note 1) ●Controller Power supply To CN5 24VDC Option Communication cable To CN4 To CN4 Conversion ●Actuator cable unit To CN3 (Robotic type cable) Controller Part No: setting soft ware...
  • Page 17: Setting Function

    3.2 Setting Function Refer to the operation manual of the controller (LEC series) for the detail of the setting function. Easy Mode for simple setting >Select “Easy mode” for instant operation Controller setting software Setting and operation, such as the step data setting, test drive and JOG / fixed-distance moving, can be performed on the same page.
  • Page 18 Normal mode for the detailed setting >Select “Normal mode” if the detailed setting are necessary. Step data can be set in detail. Parameters can be set. Signals and terminal condition can be monitored. JOG and fixed distance movement, return to origin position, test operation and testing of compulsory output can be done.
  • Page 19 Controlled items PC: Controller setting software TB: Teaching box Easy Normal Function Content mode mode PC/TB Movement method Can be selected of absolute/relative position move ○ × ○ Speed Can be set in units of 1mm/s. ○ ○ ○ Position Can be set in units of 0.01mm.
  • Page 20: Step Data Setting

    3.3 Step data setting Refer to the operation manual of the controller (LEC series) for details. This operation manual specifies the electric actuator slider type, if an actuator other than the slider type is used, refer to the operation manual of each type of actuator and controller (LEC series) regarding the description of step data.
  • Page 21 <Items and set values in positioning operation> Step No. 1: Positioning operation Step data Move M Speed Position Accel Decel Pushing F TriggLV Pushing Sp Moving F Area1 Area2 In pos mm/s mm/s2 mm/s2 mm/s 0 Absolute 50.00 3000 3000 48.00 50.00 0.50...
  • Page 22 Example of step data input (1) 〈 Positioning operation - 【INP】output signal, 【AREA】output signal 〉 Step data Move M Speed Position Accel Decel Pushing F TriggLV Pushing Sp Moving F Area1 Area2 In pos mm/s mm/s2 mm/s2 mm/s 0 Absolute 100.00 3000 3000...
  • Page 23 Example of step data input (2) 〈 Positioning operation - Relative 〉 Step data Move M Speed Position Accel Decel Pushing F TriggLV Pushing Sp Moving F Area1 Area2 In pos mm/s mm/s2 mm/s2 mm/s 0 Relative 10.00 3000 3000 10.00 20.00 0.50...
  • Page 24 Operating procedure and input / output signals for each operation The input / output signal and the operation description for operating this electric actuator are as follows. 1) Signals along with the operation procedures In case the operation order is 1.
  • Page 25 2) Signals when Stopped: In the event when “EMG” is used / See 5.1 Warning (9) on p. 29 The operating sequence is 1. “Stop” 2. Release the “Stop” Output signal for the input Procedure Input signal Operation description signal *ESTOP[ Power to the motor is cut by the “Stop EMG: Not energizing...
  • Page 26: Parameter Setting

    3.4 Parameter setting Initial setting for the basic parameters Refer to the controller’s (LEC series) operation manual for detail. As the “basic parameter” is unique data of each actuator, if an actuator other than the “electric actuator / slider type” is used, refer to the operation manual of each actuator and the controller’s (LEC series) operation manual for the basic parameter.
  • Page 27 Initial setting for the ORIG parameters Refer to the controller’s (LEC series) operation manual for detail. As the “ORIG parameter” is unique data of each actuator, if an actuator other than the “electric actuator / slider type” is used, refer to the operation manual of each actuator and the controller’s (LEC series) operation manual for the “ORIG parameters”.
  • Page 28 <Origin offset> The origin offset means the value of the origin. (“Origin offset”=The display value of origin) When the parameter “Origin offset” is changed, the value of “Stroke(+)”, “Stroke(-)” of basic parameter should be checked again. When the parameter “Origin offset” is changed, the display value of origin is changed. The step data should be checked again.
  • Page 29: Wiring Of Cables / Common Precautions

    4. Wiring of cables / Common precautions Warning Adjusting, mounting or wiring change should never be done before disconnecting the power supply to the product. Electrical shock, malfunction and damage can result. Do not disassemble the cables. Use only specified cables. Do not connect or disconnect the wires, cables and connectors when the power is turned on.
  • Page 30: Electric Actuators / Common Precautions

    5. Electric actuators / Common precautions 5.1 Design and selection Warning 1. Be sure to read the operation manual (this manual and the one for the controller: LEC series). Handling or usage/operation other than that specified in the Operation Manual may lead to breakage and operation failure of the product.
  • Page 31: Mounting

    It cannot be done during positioning operation, pushing operation and pushing. Refer to a common auto switch /matter (Best Pneumatics No 2) when an auto switch is built in and used. 5.2 Mounting Warning 1. Install and operate the product only after reading the Operation Manual carefully and understanding its contents.
  • Page 32: Operating Environment

    a) Damage to electric driving line and signal line. b) Looseness of the connector to each power line and signal line. c) Looseness of the actuator /cylinder and controller /driver mounting d) Abnormal operation e) Emergency stop of the total system When more than one person is performing work, decide on the procedures, signals, measures and resolution for abnormal conditions before beginning the work.
  • Page 33: Maintenance

    harmful gas or liquid. 2. Store in an area that is shaded from direct sunlight and has a temperature and humidity within the specified range (-10°C to 60°C and 35 to 85% No condensation or freezing). 3. Do not apply vibration and impact to the product during storage. 5.5 Maintenance Warning Do not disassemble or repair the product.
  • Page 34: Electric Actuators / Slider Type Common Precautions

    6. Electric actuators / Slider type Common precautions 6.1 Design and selection Warning Do not apply a load in excess of the actuator specification. A product should be selected based on the maximum work load and allowable moment. If the product is used outside of the operating specification, eccentric load applied to the guide will become excessive and have adverse effects such as creating play in the guide, reduced accuracy and reduced product life.
  • Page 35: Mounting

    6.3 Mounting Caution Keep the flatness of mounting surace to within 0.1mm or less. Insufficient flatness of the work piece or the surface onto which the actuator body is to be mounted can cause play in the guide and increased sliding resistance. When mounting the workpiece or other device to the actuator tighten the fixing screws with adequate torque within the specified torque range.
  • Page 36 [Items for visual appearance check] 1. Loose screws. Abnormal dirt. 2. Check of flaws/faults and cable connections. 3. Vibration, noise. [Items for internal check] 1. Lubricant condition on moving parts. 2. Loose or mechanical play in fixed parts or fixing screws. [Items for belt check] Check the belt regularly as shown in “maintenance frequency”.
  • Page 37: How To Detach And Attach The Dust Seal Band

    How to detach and attach the dust seal band For the internal-check as the maintenance, the method of detaching and attaching the dust seal band is shown as the following. <Dis-assembly> 1. Loosen the fixing bolts of end side of the “Band holder”. (The picture shows LEFB, but LEFS is same instruction as LEFB.) Pay attention to not cut hand on the edges of the "Dust seal band".
  • Page 38: Troubleshooting

    7. Troubleshooting Alarms below are abstract of representative examples. For other alarms, see operation manual of controller. Phenomenon Cause Countermeasure Fail to operate 1) The cable is not connected Check if the cable is properly installed / / Initial stage or has been disconnected.
  • Page 39 Phenomenon Cause Countermeasure Operation not completed 1) Added excessive external Operate within the specified range. / Operation continue force (including vibration) or /See 2.1 Specifications on p.9 impact load. Check the power consumption for Alarm for “Posn failed/code: 2) The Power supply does not each actuator and controller: 1-149”...
  • Page 40 Phenomenon Cause Countermeasure Operation not completed 1) If the power supply is an Replace the power supply with a non / Operation continue “inrush-current restraining type”, “inrush-current restraining type” the alarm may be generated due power supply. to voltage drop. / Refer to the LEC controller Alarm for “Over motor Vol operation manual.
  • Page 41 Phenomenon Cause Countermeasure 5) The cable is not connected Confirm that the cable is connected or has been disconnected. correctly. /See 4. Wiring of cable on p.28 Operation not completed 1) Command invalid Check if the step data is valid / During operation (unregistered) step data.
  • Page 42 Phenomenon Cause Countermeasure “INP” output signal is unstable. 1) The value of [In position] in Increase [In position] value as the “INP” output signal is unstable step data is too small. following. even after the positioning LEFS: [0.5] or more operation is completed.
  • Page 44 Revision history SMC Pneumatics (Hong Kong) Ltd. 廣州市新越液壓氣動器材有限公司 香港九龍長沙灣道 778-784 號香港中心 29 樓 中國廣州市荔灣區和平中路 106 號之一 電話:8620-81888778 傳真:8620-81863966 電話:852-27440121 傳真:852-27851314 網址:http://www.smcgz.com 電郵:xydcp888@163.com 網址:http://www.smchk.com.hk 電郵:smchk@smchk.com.hk 16-8-2012 2012...
