6. If you see this screen then simply press
Type Try DHCP Again
. Enter
7. On your smart device WIFI connected to the Tenda network, open a browser and type in the IP address.
5. Configuring the 2300 via the Web Interface
Enter
not using a network, in n n
page address will look something like http://192.168.1.7. A login dialog box will appear, asking for user name
and password.
The password is used on the web to restrict access to administration functions to the system. The default
admin
username is , and the default password is
The 2300 and the probes are configured using the five buttons along the top of this screen. Their functions and
their submenus are described below in Table 2. Note that there are two other levels of password protection, that
ng that the admin level does. See Section5.5 for a description of user levels.
Table 2 - Menu Items Available to an Administrator
Menu Item
Probe Status
Remote Display
Logs
Data Logs
Alarm Logs
System Logs
Setup
Probe Configuration
User Maintenance
Data Logging Config
Network Setup
Enter
.
admin
Function
Displays the current values of the sensors along with recent history and
action status.
Displays a simulated image of the current front panel of the 2300 with
active buttons. Clicking on one of the 8 navigation buttons changes the
screens and moves the cursor just as if these buttons were being pushed
on the actual unit. These actions update the unit accordingly, which in
turn updates the simulated display. Try to remember to leave the
Remote Display in RUN mode!
Brings up the list of daily data logs in memory, allowing data to be
emailed, downloaded, or deleted. Also does setting of the period for
logging
Brings up the list of alarm logs in memory, can be saved or deleted
Brings up the list of system logs in memory, including errors, jscripts,
and system access. These can be viewed, saved, or deleted
Set up sensors, alarms, relays, and notifications.
Set up users and passwords.
Set up data logging parameters
Set up web server, TFTP server, and emails.
. You will then see a screen with the title
aquametrix
connected to the same network as the 2300 Controller or, if
e 2300 Controller via the Ethernet cable. A web
aquametrix
.
Select Network
Page 23
