TRX7 Hardware.

17
18
19
20
21
13
16
1. Microphone
2. Touchscreen
3. Lanyard attach point
4. POWER button
5. Volume buttons
6. MUTE button
7. RESET button (unused)
8. Camera button*
1
9. BACK button
10. HOME button
11. MENU button
12. Cradle screws
13. Speakers
14. Cradle connections
15. Mount Plate
16. Mini-USB Power port**
*available on select models.
**use caution when opening to avoid damaging covers.
***inactive on TRX7.
2
8
9
10
11
12
13
14
15
17. Headphone jack**
18. USB port***
19. Memory card slot
20. Cover latch
21. Camera lens*
6
3
4
5
6
7
