Mitsubishi AJ65SBT2B-64DA User Manual

Digital-analog converter module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Converter Module
Thank you for purchasing the Mitsubishi programmable controller .
Prior to use, please read this and relevant manuals thorougly to fully
understand the product.
© 2008 MITSUBISHI ELECTRIC CORPORATION
Digital-Analog
AJ65SBT2B-64DA
MODEL AJ65S-64DA-U-HW
MODEL
CODE
IB(NA)-0800418-A(0805)MEE
User's Manual
(Hardware)
13JY75

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi AJ65SBT2B-64DA

Summary of Contents for Mitsubishi AJ65SBT2B-64DA

  • Page 1 Digital-Analog Converter Module User’s Manual (Hardware) AJ65SBT2B-64DA Thank you for purchasing the Mitsubishi programmable controller . Prior to use, please read this and relevant manuals thorougly to fully understand the product. MODEL AJ65S-64DA-U-HW MODEL 13JY75 CODE IB(NA)-0800418-A(0805)MEE © 2008 MITSUBISHI ELECTRIC CORPORATION...

  • Page 2: Safety Precautions

    SAFETY PRECAUTIONS (Be sure to read these instructions before use.) Before using this product, please read this manual and the relevant manuals introduced in this manual carefully and pay full attention to safety to handle the product correctly. The instructions given in this manual are concerned with this product. For the safety instructions of the programmable controller system, please read the CPU module user’s manual.
  • Page 3 [Design Precautions] DANGER Configure a safety circuit so that the safety of the overall system is maintained even if an external power failure or a programmable controller failure occurs. Incorrect output or malfunction can lead to an accident. (1) The status of analog output changes depending on the setting of various functions that control the analog output.
  • Page 4 [Installation Precautions] CAUTION Use the module in an environment that meets the general specifications given in this manual. Operating it in any other environment may cause an electric shock, fire, malfunction, product damage or deterioration. For protection of the switches, do not remove the cushioning material before installation.
  • Page 5 [Wiring Precautions] CAUTION Be sure to shut off all phases of the external power supply used by the system before installation or wiring. Failure to do so may cause a damage to the product and/or malfunctions. Always ground the FG terminal to the protective ground conductor. Failure to do so may result in malfunctions.
  • Page 6 [Wiring Precautions] CAUTION Do not install the control cable(s) together with the communication cable(s). Doing so may cause malfunctions due to noise. When disconnecting the cables from the module, do not hold and pull the cable part. Disconnect the cables after loosening the screws in the portions connected to the module.
  • Page 7 This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

  • Page 8: Table Of Contents

    CONTENTS 1. OVERVIEW ....................1 2. SPECIFICATIONS ..................2 2.1 General Specifications ................2 2.2 Performance Specifications..............4 3. PART NAMES AND SETTINGS ..............6 3.1 Part names ....................6 4. LOADING AND INSTALLATION ..............9 4.1 Handling Precautions ................9 5.
  • Page 9 The following manual is also related to this product. If necessary, place an order. Related Manual Manual Number Manual name (Model code) Digital-Analog Converter Module Type AJ65SBT2B-64DA User's SH-080768ENG Manual (13JZ19) COMPLIANCE WITH THE EMC AND LOW VOLTAGE DIRECTIVES (1) For programmable controller system...

  • Page 10: Overview

    1. OVERVIEW This user's manual explains the specifications, names of the components and wiring for the type AJ65SBT2B-64DA digital-analog converter module (hereafter AJ65SBT2B-64DA) which are used as a remote device station of a CC-Link system.

  • Page 11: Specifications

    2. SPECIFICATIONS 2.1 General Specifications The general specifications for the AJ65SBT2B-64DA are shown in the following table. Table 2.1 General specifications Item Specification Operating ambient 0 to 55 temperature Storage ambient -20 to 75 temperature Operating ambient 10 to 90%RH, condensation not allowed...
  • Page 12 It indicates the device is to be connected to which power distribution part, within the area from the public electricity network to machinery in the premise. Category II applies to devices to which power is supplied from fixed installations. The surge voltage withstand for devices rated up to 300V is 2500V. This is an index showing the degree of the conductive pollution that can occur in the environment where the device is used.

  • Page 13: Performance Specifications

    2.2 Performance Specifications The performance specifications for the AJ65SBT2B-64DA are shown in the following table. Table 2.2 Performance specifications Item AJ65SBT2B-64DA 16-bit signed binary Voltage Digital input (-12288 to 12287, -16384 to 16383, -288 to 12287) value Current 16-bit signed binary(-288 to 12287)
  • Page 14 Table 2.2 Performance specifications Item AJ65SBT2B-64DA Noise voltage : 500Vp-p, tested by noise simulator of noise width of Noise immunity 1 s and noise frequency of 25 to 60Hz Communic ation area, 7-point 2-piece terminal block module 5.2 Tightening torque: 59 to 88N•cm...

  • Page 15: Part Names And Settings

    3. PART NAMES AND SETTINGS 3.1 Part names This section explains the names of the components for the AJ65SBT2B- 64DA. Figure 3.1 Appearance of the AJ65SBT2B-64DA...
  • Page 16 Table 3.1 Part names Name Description On: Power supply on PW LED Off: Power supply off Normal operation Flashing: 0.1s intervals indicate an output range setting error. Normal 0.5s intervals indicate a digital value setting mode error. Off: Indicates that 24V DC power supply interrupted, watchdog timer error occurred, write error for flash memory occured.
  • Page 17 L TER. (Line Turned ON to validate the terminating resistor stored in the AJ65SBT2B- Termination) 64DA. switch Used when the AJ65SBT2B-64DA is used on the network edge. The transmission speed is automatically set depending on the setting of the master module.

  • Page 18: Loading And Installation

    4. LOADING AND INSTALLATION 4.1 Handling Precautions The following is an explanation of handling precautions of the AJ65SBT2B-64DA. CAUTION Do not touch the terminals while the power is on. Doing so may cause malfunction. Take care to prevent foreign matter such as dust or wire chips from entering the module.
  • Page 19 When installing a DIN rail, tighten the screws at a pitch of 200mm or less. (3) When mounting the AJ65SBT2B-64DA to the DIN rail, press with your finger the centerline of the DIN rail hook at the bottom of the module until it clicks.

  • Page 20: Data Link Cable Wiring

    AJ65SBT2B-64DA. 5.2 CC-Link Dedicated Cable Connection Method The following shows how to connect the AJ65SBT2B-64DA to a master module and a remote module with CC-Link dedicated cables. Master module I/O module, etc.

  • Page 21: Wiring

    The precautions when performing external wiring are as follows: (1) Use separate cables for the AC control circuit and the external output signals of the AJ65SBT2B-64DA or the external power supply to avoid the influence of the AC side surges and induction.
  • Page 22 (2) For current output Motor drive module, etc. conversion DC/DC Filter converter Figure 6.2 Wiring for current output Use a twisted two core shielded wire for the power wire. If there is noise or ripples in the external wiring, connect a 0.1 to 0.47 F capacitor (25V or higher voltage-resistant product) to the output terminals of the external device.

  • Page 23: External Dimensions

    7. EXTERNAL DIMENSIONS The external dimensions of the AJ65SBT2B-64DA is shown below. 122 (4.80) 109.5 0.5 (4.31 0.02) 7.9 (0.31) 2-4.5 5.1 M4 DIN rail center Unit: mm (inch)
  • Page 24 Warranty Mitsubishi will not be held liable for damage caused by factors found not to be the cause of Mitsubishi; machine damage or lost profits caused by faults in the Mitsubishi products; damage, secondary damage, accident compensation caused by special factors unpredictable by Mitsubishi;...
